Panasonic SA-PT980GA Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Home Theater System
  5. SA-PT980GA
  6. Service manual
Panasonic SA-PT980GA Service Manual

Panasonic SA-PT980GA Service Manual

Dvd home theater sound system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Note: Please refer to the original service manual for:
DVD Mechanism Unit (DLS6E), Order No. PSG0909002AE
Speaker system SB-BT735EG-K, Order No. PSG1003007CE

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. GENERAL GUIDELINES -------------------------------- 3
1.2. Before Use -------------------------------------------------- 3
1.3. Before Repair and Adjustment ------------------------- 3
1.4. Protection Circuitry ---------------------------------------- 5
1.5. Safety Parts Information --------------------------------- 5
2 Warning -------------------------------------------------------------- 7
2.2. Precaution of Laser Diode------------------------------- 8
DVD Home Theater Sound System
Model No.
Product Color: (K)...Black Type
PAGE
3 Service Navigation --------------------------------------------- 12
3.1. Service Information -------------------------------------- 12
4 Specifications ---------------------------------------------------- 13
5.2. Main Unit Key Button Operations -------------------- 16
5.3. Speaker Connection------------------------------------- 16
5.5. Using of iPod/iPhone------------------------------------ 19
5.6. Disc Information ------------------------------------------ 20
6.1. Cold-Start -------------------------------------------------- 22
6.2. Service Mode Table ------------------------------------- 22
