- Page 1 Assembly instructions (translation) Manual rotary adjuster MDV 160/200 1605490 Version 01...
- Page 2 This documentation is intended only for the operating company and its personnel. The copyright of this documentation is owned by IEF-Werner GmbH. The content (texts, figures, drawings, graphics, plans, etc.) may not be reproduced or distributed, as a whole or in part, in printed or electronic form, without our prior written consent.
-
Page 3: Table Of Contents
Table of contents Table of contents 1 About this manual ..........................1.1 General information ........................... 1.2 Customer service department........................1.3 Change history............................. 1.4 Other applicable documents ........................2 Description ............................. 2.1 Overview ............................... 2.2 Technical data and ambient conditions ....................2.3 Type plate / identification of the product .................... -
Page 4: About This Manual
About this manual | 1 1 About this manual 1.1 General information This manual is part of the machine/product and provides information concerning safe handling. The manual must therefore be kept on hand for the entire life cycle and must be accessible at all times. -
Page 5: Description
Description | 2 2 Description 2.1 Overview Function The rotary table is used for the rotary positioning of workpieces and devices around a fixed centre point. The rotary table is adjusted manually. Fig. 1: Overview: rotary table 1 Rotary plate 2 Reference switch connection option 3 Housing 4 Drive shaft 5 Bearing support Floating bearing... -
Page 6: Type Plate / Identification Of The Product
2 Serial number 3 Product designation 4 Ratio 2.4 Scope of delivery and accessories Scope of delivery Required accessories Optional accessories MDV 160/200 depending Clamping lever on the order with Handwheel Handwheel with di- gital display Tab. 3: Scope of delivery and accessories... -
Page 7: Handwheel / Rotary Knob With Digital Display
Description | 2 2.5 Handwheel / rotary knob with digital display The digital display enables easy and clearly visible reading of the position. Display / resolution [degrees] Absolute position Battery-buffered Display accuracy 1 decimal place Battery type CR2032 Lithium 3 V Battery life [years] Protection class IP51... - Page 8 Description | 2 Set calibration value Press and hold key [2]. ð The calibration value input symbol [6] lights up. ð The display shows the current calibration value. To exit the calibration values menu without making any changes: Press and hold key [2].
-
Page 9: Transport
Transport | 3 3 Transport Important notes regarding transport Wear suitable protective clothing such as a protective gloves and safety shoes. Unpacking Immediately after delivery, check the machine/product for transport damage. Notify the shipping company, insurance company and manufacturer immediately of any transport damage. -
Page 10: Installation
Installation | 4 4 Installation 4.1 Installation The following points must be complied with during assembly: Any position (horizontal and vertical) possible. Installation position 0.1 mm/m² Flatness of the mounting surface Do not drill any additional holes. Further points The component must be mounted without distortion and bending. WARNING Risk of injury (crushing, impact) In the case of vertical/inclined installation position, moving parts can... - Page 11 Installation | 4 Mounting the payload on the rotary table 0,01 Fig. 6: Drilling pattern Attach payloads to the rotary table according to the holes in the drilling pattern. MAN_MDV_160-200_1605490_V01_en | Version 01 11 / 20...
-
Page 12: Installation Accessories (Optional)
Installation | 4 4.2 Installation accessories (optional) If the component was ordered with accessories, all accessories are fitted on delivery. 4.2.1 Clamping lever The set position can be fixed using the clamping lever. The clamping lever can also be mounted mirror-inverted. Fig. 7: Mounting clamping lever 1 Screw (M5 x 20) 2 Clamping block... -
Page 13: Maintenance
Maintenance | 5 5 Maintenance 5.1 Spare parts and wear parts Only use faultless, suitable tools and original spare parts or series production parts ex- pressly approved by the manufacturer for repairs. See the supplied lists of spare/re- placement parts for information and provision these parts according to requirements and experience. -
Page 14: Adjusting The Play Of The Worm Gear
Maintenance | 5 * For special requirements: Observe the label with information on the lubricant on the component. E.g. for food and medical technology: Grease gun – BERULUB FG-H 2SL (part no.: 1315987) 5.3 Adjusting the play of the worm gear The play adjustment is carried out at the factory. - Page 15 Maintenance | 5 Without setting aid Fig. 10: Backlash: Drive shaft 1 Drive shaft Check the current backlash. It serves as a reference. Fig. 11: Backlash: Loosen screws 1 Screws on the bearing mount 2 Screws on the axial bearing (floating bearing) 3 Adjusting screws Slightly loosen the screws of the bearing holder and the screws of the axial bearing.
-
Page 16: Changing The Battery (Only For The Digital Position Indicator)
Maintenance | 5 If the worm gear is jammed: Slightly loosen the screws of the axial bearing. Turn the adjusting screws anti-clockwise. Move the drive shaft. If the backlash is set correctly (minimum): Tighten the screws of the axial bearing and then tighten the screws of the bearing mount. -
Page 17: Fault Rectification
Fault rectification | 6 6 Fault rectification The troubleshooting measures described here are only intended to provide assistance to qualified specialists. Contact the manufacturer’s service department, if necessary. Exploded-view drawings and parts lists can be downloaded from the homepage. Backlash / position loss Assembly Reason Fault rectification... -
Page 18: Dismantling And Disposal
Dismantling and disposal | 7 7 Dismantling and disposal Disposal The disposal of all replacement parts and in particular the operating materials used, such as lubricants or other environmentally hazardous substances, such as electronic scrap or batteries, must be carried out by specialist companies in accordance with the applicable statutory regulations. - Page 19 Dismantling and disposal | 7 MAN_MDV_160-200_1605490_V01_en | Version 01 19 / 20...
- Page 20 IEF-Werner GmbH Wendelhofstraße 6 Germany-78120 Furtwangen Telephone: +49 7723-925-0 info@ief-werner.de...
