Please scan the QR code to obtain the electronic
version of the quick installation guide and instructions
DTSU666 Smart Power Sensor
for C&I
Quick installation Guide
Add: Wenzhou Daqiao Industrial Park,Yueqing City, Zhejiang
Province, China
Tel.: 0086-577-62877777
Fax: 0086-577-62891577
Web: aiot.chint.com
Advertisement
Related Manuals for CHINT DTSU666
Summary of Contents for CHINT DTSU666
- Page 1 DTSU666 Smart Power Sensor for C&I Quick installation Guide Please scan the QR code to obtain the electronic version of the quick installation guide and instructions Add: Wenzhou Daqiao Industrial Park,Yueqing City, Zhejiang Province, China Tel.: 0086-577-62877777 Fax: 0086-577-62891577 Web: aiot.chint.com...
-
Page 2: System Networking
Requirement for C&I Power Sensor System Networking Notes： 1. For the installation location and wiring of the power sensor, please refer to networking diagram and the wiring guide, or consult our engineer. 2. For voltage sampling, if the grid L-L voltage is ≤480V, you can connect the wires directly; if it is >480V, you need to connect PT 3. -
Page 3: Wiring Guide
Sampling Voltage ≤ 480Vac (3P4W) Wiring Guide CT Ratio Setup Guide 1. Initial interface after power 2. Press ‘SET’ for 3s to enter 3. Press ‘SET’ and ‘➡’ to enter the password input interface the password (default 701) 4. Press ‘SET’ for 3s to 5.Press ‘SET’... - Page 4 Sampling Voltage ≤ 480Vac (3P3W) Wiring Guide 3P3W net Setup Guide 1. Initial interface after power 2. Press ‘SET’ for 3s to enter 3. Press ‘SET’ and ‘➡’ to enter the password input interface the password (default 701) 4. Press ‘SET’ for 3s to 5.
- Page 5 Sampling Voltage ＞ 480Vac (3P3W) Wiring Guide PT Ratio Setup Guide 38 11 12 3 8 1 1 1 2 1. Initial interface after power 2. Press ‘SET’ for 3s to enter 3. Press ‘SET’ and ‘➡’ to enter the password input interface the password (default 701) (Blue) 2 4 25...
