- Page 1 INSTALLATION MANUAL LED TV* * LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. UM7** UM6** www.lg.com *MFL72005101* Copyright © 2023 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Table of contents Pro:Centric - Server Type - Installation Code Server Type - Installation Code - Mode Location and Function of Controls - Secure Connection Parts and Button - WORF Basic functions - Room Number Setting - Media Type - Receive Data First Use Wizard General Basic Settings... - Page 3 IR Codes External control device Setup RS-232C Setup Phone jack Type Type of Connector : D-Sub 9-Pin Male RS-232C Configurations Communication Parameters IR OUT Using Guide - Suitable / Not Recommend remote-controller data format - IR Receiver specifications Command Reference List Transmission / Receiving Protocol...
-
Page 4: Location And Function Of Controls
Location and Function of Controls Parts and Button Basic functions Power On (Press) Power Off (Press and Hold) Menu Control (Press Menu Selection (Press and Hold All running apps will close. You can access and adjust the menu by pressing the button when the device is on. You can use the function when you access menu control. -
Page 5: First Use Wizard
First Use Wizard * Image shown may differ from your device. (Depending on model) • There are four options - Basic Settings, Data Cloning, Solution Settings, and Installation Menu Settings. Each menu can access by START button. (Normal Configuration is the default focus item.) -
Page 6: Basic Settings
Basic Settings * Image shown may differ from your device. This menu is for Basic Settings related to language, network, portal, voice service coverage and channel tuning without SI (Pro:Centric) setting. There are four steps for it. Language & Location (Depending on model) •... -
Page 7: Network Settings
Network Settings (Depending on model) • Set Network connection. You can connect easily to wired/wireless network. (”Network” on page 30) Wireless (Auto Wi-Fi) : Connect a default hidden SSID/PW. (SSID : lgwebostv, PW : procentric, Security : WPA/WPA2 PSK) -
Page 8: Legal Notice
Legal Notice (Depending on model) These are the terms and conditions related to use of the Smart device service and protection of privacy. -
Page 9: Portal Settings
Portal Settings (Depending on model) • Set the Portal Mode and Portal Auto Start. Portal Mode (Depending on model) • You can select ‘Default Portal’ (Use webOS default portal), ‘Customizable Portal’ (Use editable Portal), or ‘None’ (Do not use portal). Portal Auto Start •... -
Page 10: Voice Service Coverage
Voice Service Coverage (Depending on model) • Set the voice service coverage. You can set LG Service Country and Service Area Postcode for voice service. -
Page 11: Data Cloning
Data Cloning (Depending on model) Access Data cloning menu of TV Manager application for applying cloning file. Solution Settings (Depending on model) The Pro:Centric Platform enables you to simply install, manage and use guest-centric solutions. The default Domain “procentric.local” and IP Server Address are needed to be registered in DNS. -
Page 12: Tv Configuration Options
TV Configuration Options (Depending on model) From the TV Configuration Options screen, you can choose how to proceed with the configuration. Whether you will configure the device for Pro:Centric operation via the wizard or use a USB memory device to configure the device, you may first wish to set the Room Number. Also, you can configure the network environment. - Page 13 • If you intend to apply the files via USB, use USB Configuration option to access TV Manager app. (“TV Manager” on page 56) • If you intend to set network, use the Network Settings option. You can connect easily to wired/wireless network by this option. (”Network” on page 30) Wireless (Auto Wi-Fi) : Connect a default hidden SSID/PW.
-
Page 15: Configure Pro:centric Server
Configure Pro:Centric Server (Depending on model) You can select two options. • Standard Pro:Centric Server Settings : Default Automatic / Manual Pro:Centric Server Configuration • Installation Code Settings : Installation Code based simple installation for Cloud solution... -
Page 16: Standard Pro:centric Server Settings
Standard Pro:Centric Server Settings (Depending on model) Automatically for Setup This step automatically searches for the Pro:Centric Server. If was found the Pro:Centric data programme, select the Next. - Page 17 Downloading the Pro:Centric application files takes few minutes. After the installation is completed, the following screen will be displayed.
-
Page 18: Manually For Setup
Manually for Setup Please select the Manual Pro:Centric. Configure the appropriate Pro:Centric settings. (Taiwan does not support RF) - Page 20 Downloading the Pro:Centric application files takes few minutes. After the installation is completed, the following screen will be displayed.
-
Page 21: Installation Code Settings
From the Installation Code Settings screen, You can input the installation code that was issued from Cloud Portal. Server Searching 1) LG Pro:Centric Cloud • Server search succeed : The message “Server Found [property name]” is displayed. And the search button changes to the next button. - Page 22 2) LG QI Server • Server search succeed : The message “Server Found” is displayed. And the search button changes to the next button. • In case of error : The message “Server Not Found” is displayed.
- Page 23 Download Pro:Centric App • After clicking the next button, Downloading the Pro:Centric application files takes few minutes. Download Complete • After the installation is completed, the following screen will be displayed.
-
Page 24: Installation Menu Settings
Installation Menu Settings (Depending on model) Access Installation menu for commercial feature settings. -
Page 25: Installation Menu
Installation Menu * Image shown may differ from your device. Introduction The abundant functions linked with software installation can be projected on OSD as ‘Installation Menu’ . The wide range of hotel features can be performed simply on additional window to enhance easy installation and convenient operation for Hotelier and System Integrators. -
Page 26: Public Display Settings
Public Display Settings - When Public Display Settings is set to On, all functions of Public Display Settings apply. Power On Status • Decide to select working status when the main power is turned on. • You can select PWR, STD, LST. •... -
Page 27: Volume
- Manage key usability of Local(Front) Key and Remote Control. IR Operation • Decide whether work the LG remote control or not. - When set to ‘Normal’ , all remote keys are available. - ‘Use PWR Only’ blocks all remote keys except power key. -
Page 28: Limited Mode
Limited Mode • Configure function’s limitation. When selected to ‘On’ , following sub-menus will be worked by below. Setup Menu • Permit to tune and manage Channels. Channel Change • Decide to change channel or not. Menu Display • Function to decide whether work with menu of control key or not. - Although select Off, the action that press a Menu button for 5 seconds to enter ‘Installation Menu’... -
Page 29: Dtv Channel Update
DTV Channel Update • It is a mode to set whether to update DTV Channel automatically or not. • When set to ‘Auto’ , update Channel map according to DTV Channel’s stream information. • When set to ‘Manual’ , keep Channel map even though DTV Channel’s information is changed. Power On Default •... -
Page 30: Network
Network (Depending on model) MAC Address • Displays the MAC address (not customizable). Network Setting One-click network connection • Connects easily to a network. • This menu supports to connect to an available network. -
Page 31: Ip Stream Control
IP Stream Control (Depending on model) Audio PTS Offset • Controlling output stream timing of audio. Video PTS Offset • Controlling output stream timing of video. IGMP • You can set IGMP version. (2 or 3) Wake On LAN • Sets the Wake On LAN function. - The Wake On LAN feature enables the device to receive software updates and/or be powered ON upon receipt of Magic Packet data via the wired LAN. -
Page 32: Pro:centric
• If you input the 6-digit installation code when ‘Type’ is ‘LG Pro:Centric Cloud’ , the server is automatically searched. • If you input the 8-digit installation code when ‘Type’ is ‘LG QI Server’ , , the server is automatically searched. -
Page 33: Worf
WORF • When set to ‘Enable’ , time setting item is enabled and then the Update Event function is enabled. • When set to ‘Disable’ , time setting item is disabled and then the Update Event function is disabled. Room Number Setting •... -
Page 34: General
General Configuration Setup Select RCU • It is a mode to set whether to use Select RCU or not. When set to ‘Enable’ , You can adjust ‘Number of RCU’ menu. Number of RCU • Number of RCU value range 1~16. (When ‘Select RCU’ is set to ‘Enable’) •... - Page 35 RS232 DC Power Outlet (Depending on model) • It is a mode to decide whether to output DC or not for power supply to IB Box in Installation Menu. We offer a output terminal in one Pin of RS232C Jack for the use of communication. •...
- Page 36 One Channel Map (Depending on model) • If set to ‘Enable’ , the device will operate as below. - A. When the device is auto-scanning, it searches both air and cable channels. - B. User can assign a channel number him/herself by manual scan. - C.
-
Page 37: Auto Sensing
DVB-C (Depending on model) • DVB-T/C programmes are searchable and selectable if DVB-C is “Enable”. DVB-C Bandwidth (Depending on model) • If country is ‘Philippines’ , ‘DVB-C Bandwidth’ menu will be shown. • Select the bandwidth of cable tuning (6 MHz/8 MHz). The default is 6 MHz. Additional Pixel Refresher (Depending on model) •... -
Page 38: Always On Display
Always on Display (Depending on model) • Even when the device has not been used, it provides optimized wallpaper. When the device is turned off, it switches to Always on Display to display the selected screen wallpaper. • This function is supported when instant on is set to instant on mute. •... -
Page 39: No Signal Image
No Signal Image (Depending on model) • You can set to ‘Off’ , ‘Default Image’ or ‘Downloaded’ . • It is a mode to decide whether to use no signal image when there is no signal. • When set to ‘Off’ , do not use no signal image. •... -
Page 40: Screen Saver
• You can configure the Sound Out to be set after power on. • You can select Off, TV Speaker, Optical, LG Sound Sync., HDMI ARC • If you set this option to Off, the device maintains Sound Out after power on. -
Page 41: External Speaker
External Speaker (Depending on model) Volume Control • Selects the volume control method of an external speaker. • You can select ‘Off’ , ‘Int Variable’ , ‘Fixed’ or ‘Ext Variable’ . (Depending on model) • Ext Variable uses the External Vol Up/Down Control Line to change the volume up to 2 Watts. •... -
Page 42: Power Saving
Power Saving Static Saving • It is the item for setting the level to reduce the backlight control from the items for saving the consuming power, which is increased or decreased by 10 steps from 0 to 100. 100 makes the consuming power set to the same one from the device. 0 reduces the consuming power to the minimum. -
Page 43: Clock Setup
Clock Setup (Depending on model) Mood Display Setup (Depending on model) • You can setup Mood Display features. Clock Display (Depending on model) • You can select ‘Enable’ or ‘Disable’ . • After selecting ‘Enable’ , you can see the LED Clock. Dimming Standby (Depending on model) •... -
Page 44: Welcome Video Mode
Welcome Video Mode (Depending on model) • You can set to Off, Once or Repeat. Operation • The video displays after your device is turned on and the boot logo appears. • If Welcome Video is enabled and a video is downloaded on the device, the video plays. •... -
Page 45: Crestron
Crestron (Depending on model) Crestron Connected • The connection status of the server type shall be indicated by pictures and phrases. (Disconnected, Connecting, Connected) • Type: You can select the server type you want to connect to (Off, Control System, Virtual Control, Fusion) •... -
Page 46: Developer Mode
Developer Mode (Depending on model) • This feature provides great convenience to the app developers. • Set up to install the Developer mode app. Security Port Control (Depending on model) • Unused ports can be blocked for network security Lock Mode •... -
Page 47: Portal Settings
Portal Settings (Depending on model) Portal Mode (Depending on model) • You can select ‘Default Portal’ (Use webOS default portal), ‘Customizable Portal’ (Use editable Portal), or ‘None’ (Do not use portal). Auto Start (Depending on model) • You can select ‘Off’ , ‘Website Shortcut’ , ‘Portal Mode’ , or ‘App’ . •... -
Page 48: Website Shortcut
Website Shortcut (Depending on model) Shortcut • Sets Enable or Disable. When it is set to Enable, Website Shortcut app is displayed at launcher bar. Shortcut Name • You can set Website Shortcut app name (title). Shortcut URL • Sets URL to connect when excute Website Shortcut app. Shortcut Icon •... -
Page 49: Hotel Directory
Hotel Directory (Depending on model) • Set the information to display at Hotel Directory app. Facility or Service Name • Set the facility or service name. Details or Extension • Set the detailed information. Related Photo • You can select None, downloaded images or Download (Go to TV Manager). •... - Page 50 • Edit Template - Vertical » You can set Vertical when selecting focus. Select between Hotel or Hospital. - Template » You can set Template when selecting focus. Select between Bar Type or Tile Type. - Video » You can set this mode to On/Off when selecting Customizable Portal. »...
-
Page 51: Portal Manager
Portal Manager (Depending on model) This feature enables you to group together multiple monitor sets on a single network into the same group and copy portal setting data on a group basis. This feature has two modes, Master and Slave. Master •... -
Page 52: Group Management
» Hotel : you must do one of the things listed below. i. Enable SmartShare(dlna) reboot ii. Enable DIAL reboot iii. Enable Media Renderer(DMR) reboot iv. Enable LG connect reboot • It may not work properly in wireless network environments. It is recommended you use a wired network. -
Page 53: Media Share
Media Share (Depending on model) SmartShare (Depending on model) • Smart Share enables DLNA function. If this value is enabled, the device acts as Media Player and displays Media Server contents through Smart Share app. Screen Share (Depending on model) •... - Page 54 Use Default • If you want to use default password(this password was generated randomly), you must select ‘Enable’ in this item. Security Key • If you want to change default password, you need to change ‘Use Default’ value into ‘Disable’ . Wi-Fi Signal Strength •...
-
Page 55: Beacon
Beacon (Depending on model) • This option enables BLE Beacon, one of Bluetooth 4.0’s features. • Beacon Mode (On/Off Toggle): enables the Beacon feature. • The iBeacon/Eddystone Type Beacon features are supported. iBeacon • Beacon UUID (hex): Set the UUID. - Field1: 4byte hex value (8 digits) - Field2: 2byte hex value (4 digits) - Field3: 2byte hex value (4 digits) -
Page 56: Tv Manager
TV Manager * Images shown may differ from your device. You can update files from a USB memory device to the device through the TV manager. Diagnostics (Depending on model) • Sets Enable or Disable. When it is set to Disable, user can’t control the device via RMS. The changed setting is applied after reboot. - Page 57 Ez Download • Ez Download is a function that enables users to download the desired items all at once, such as EPK (software update file), TLL, Media files, Micom, Pro:Idiom M Key. (Depending on model) - Media files, Pro:Idiom M Key files, and Software Update files must be stored in a folder named “LG_DTV” in the root directory of the USB memory device.
- Page 58 • Press button to display storage usage information. • Press the “Clear Storage” button to delete the downloaded media files.
-
Page 59: Image Download
Image Download (Depending on model) • The download sequence is Image Download Select Image(s) Download. • The image files must be stored in a folder named “LG_DTV” in the root directory of the USB memory device. • Press the “Clear Storage” button to delete the downloaded images. - Boot Logo Image (Depending on model) »... - Page 60 Icon Download (Depending on model) • If you updates the images, original images will be removed. • The download sequence is Icon Downalod Select Images Download. • Icon update function supports only JPG, JPEG, PNG format file. • Press the Clear Storage button to delete the downloaded icons. - Hotel Icon on Portal, Website Shortcut, Input Shortcut »...
-
Page 61: Video Download
Video Download (Depending on model) • The video files must be stored in a folder named “LG_DTV” in the root directory of the USB memory device. • The download sequence is Video Download Select video file Download. • Video files can only download one file each. •... -
Page 62: Data Cloning
Data Cloning Import Clone File • Once the internal device data and its programme map information are written to the USB memory device, the user can perform “Import Clone File” with a clone (.tll) file located in the root directory of the USB memory device. The user should not turn the device off nor unplug the USB device while processing. - Page 63 Export Clone File • “Export Clone File” creates a clone (.tll) file in the root directory of the USB memory device. The user must not turn the device off nor unplug the USB device while processing.
-
Page 64: Usb Download Menu
USB Download Menu USB Cloning • An Installation can quickly set up and clone multiple devices at a property. These cloned devices will all have the same Master device Setup: Installation Menu settings, User A/V settings and the programme Map. This newer procedure significantly decreases the installation time that would be necessary if the standard RS-232C method were used instead. -
Page 65: Software Update
Software Update ► Update TV Software • This feature updates the device software using the EPK file contained in a folder named “LG_DTV” in the root directory of the USB memory device. • The download sequence is Software Update Update TV Software Select file(EPK) Update. -
Page 66: Ir Codes
IR Codes • This feature is not available for all models. ► A Type Code (Hexa) Function Code (Hexa) Function (POWER) (BACK) Number Key 0-9 Alphabet buttons 10-19 (Space) - Page 67 ► B Type Code Code Function Function (Hexa) (Hexa) (Power) (Back) 10-19 Number Key 0-9...
- Page 68 ► C Type Code Code Function Function (Hexa) (Hexa) (Green) (Red) (Yellow) (Blue) (Power) 10 - 19 Number Key 0 - 9, (Space) (Back) (Dash)
-
Page 69: External Control Device Setup
External control device Setup Phone jack Type (TV) (PC) (Depending on model) • You need to purchase the phone-jack to RS-232C cable required RS-232C Setup RS-232C IN (CONTROL & SERVICE) for the connection between the PC and the device, which is ENTRÉE RS-232C (TV) (PC) -
Page 70: Rs-232C Configurations
• Baud rate: 9,600 bps (UART) automatically by IR receiver. • Data length: 8 bits • In this case, LG does not guarantee IR working function. • Parity : None • To make sure of this matter, here are two methods as •... -
Page 71: Command Reference List
Command Reference List (Depending on model) Data Command1 Command2 (Hexadecimal) 01. Power 00 to 01 02. Aspect Ratio (See p. 72) 03. Screen Mute (See p. 73) 04. Volume Mute 00 to 01 05. Volume Control 00 to 64 06. Contrast 00 to 64 07. -
Page 72: Transmission / Receiving Protocol
Transmission / Receiving Protocol 1 Power (Command: k a) ►To control Power On/Off of the set. (Depending on Model) Transmission [k][a][ ][Set ID][ ][Data][Cr] Transmission Data 00 : Off Data 01 : On [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command1] : First command to control the device. (j, k, m or x) [a][ ][Set ID][ ][OK/NG][Data][x] [Command2] : Second command to control the device. - Page 73 3 Screen Mute (Command: k d) 6 Contrast (Command: k g) ►To select screen mute on/off. ►To adjust screen contrast. You can also adjust contrast in the picture settings. Transmission [k][d][ ][Set ID][ ][Data][Cr] Transmission [k][g][ ][Set ID][ ][Data][Cr] Data 00 : Screen mute off (Picture on) / Video mute off Data 01 : Screen mute on (Picture off) Data Min : 00 to Max : 64 Data 10 : Video mute on...
- Page 74 10 Sharpness (Command: k k) 13 Balance (Command: k t) ►To adjust the screen sharpness. ►To adjust balance. You can also adjust sharpness in the picture settings. You can also adjust balance in the audio settings. Transmission Transmission [k][k][ ][Set ID][ ][Data][Cr] [k][t][ ][Set ID][ ][Data][Cr] Data Min : 00 to Max : 32 Data L : 00 to R : 64...
-
Page 75: Power Saving Function
15 Energy Saving (Command: j q) 17 Equalizer (Command : j v) ►To reduce the power consumption of the device. You can also adjust ►To adjust equalizer. Energy Saving in picture settings. Transmission Transmission [j][v][ ][Set ID][ ][Data][Cr] [j][q][ ][Set ID][ ][Data][Cr] Power Saving Level Function... - Page 76 19 Program Skip/Add (Command: m b) 22 Input select (Command: x b) (Main Picture Input) ►To set skip status for the current Channel. ►To select input source for main picture. Transmission Transmission [m][b][ ][Set ID][ ][Data][Cr] [x][b][ ][Set ID][ ][Data][Cr] Data 00 : Skip Data Structure Data 01 : Add...
- Page 77 23 Channel(Programme) Block/Unblock (Command :m d) 24 Fail Over Mode (Command: m i) ►This command may work differently depending on model and ►Selects the Fail Over mode. signal. Transmission [m][i][ ][Set ID][ ][Data][Cr] ►For South Korea, North/Latin America except Colombia Model Data 00: Off Transmission Data 01: Auto...
- Page 78 26 Internal storage media contents play (Command: s n, a8) ►Plays media stored in the internal memory. ►This command may work differently depending on model and signal. Transmission [s][n][ ][Set ID][ ][a][8][ ][Data][Cr] Data 01 : media contents play Acknowledgement [n][ ][Set ID][ ][OK/NG][a][8][ ][Data][x] * Real data mapping 00 :...
