ENGLISH

Easy Setup Guide

Please read this manual carefully before operating your set and retain it for future reference.

ESPAÑOL

Guía Rápida de Configuración

Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.

FRANÇAIS

Guide de configuration rapide

Avant d'utiliser l'appareil, veuillez lire attentivement ce manuel et le conserver pour pouvoir vous y reporter

ultérieurement.

www.lg.com

X 4

(M4 X L20)

Depending upon model / Según el modelo / Selon le modèle

X 4

(M5 X L30)

Printed in Korea / Imprimé en Corée

LED TV

65UM670H0UG

65UM650H0UG

Table of Contents

Need help?

Do you have a question about the 65UM670H0UG.AWF and is the answer not in the manual?

Questions and answers

Summary of Contents for LG 65UM670H0UG.AWF

Page 1 Avant d’utiliser l’appareil, veuillez lire attentivement ce manuel et le conserver pour pouvoir vous y reporter ultérieurement. (M4 X L20) (M5 X L30) Depending upon model / Según el modelo / Selon le modèle www.lg.com Printed in Korea / Imprimé en Corée...
Page 2 ENGLISH Read Safety and Reference. WARNING : To prevent injury, this apparatus must be securely attached to the desk/wall in accordance with the Safety and Reference. ESPAÑOL Leer Seguridad y Consultas. ADVERTENCIA : Para prevenir daños, este aparato debe ser instalado a la mesa/pared de acuerdo a la guía de Seguridad y Consultas. FRANÇAIS Lisez Sécurité...
Page 6 TV-LINK CFG...
Page 9 90° 65UM670H0UG 1,454 1 454 57.7 57,7 22.9 22,9 21.5 21,5 190 W 65UM650H0UG (57.2) (57,2) (35.7) (35,7) (13.3) (13,3) (32.9) (32,9) (2.2) (2,2) (50.4) (50,4) (47.3) (47,3) AC 120 V~ 50 / 60 Hz...
Page 13 OWNER’S MANUAL Safety and Reference LED TV* * LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 43UM670H0UA 43UM650H0UA 50UM670H0UA 55UM650H0UA 55UM670H0UA 65UM650H0UG 65UM670H0UG 86UM670H0UD www.lg.com...
Page 14: Important Safety Instruction
Important Safety Instruction • Read these instructions. • Keep these instructions. • Heed all warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. •...
Page 15 Warning! Safety instructions - Near flammable objects such as gasoline or candles, or expose the TV to direct air conditioning. - Do not install in excessively dusty places. Otherwise, this may result in fire, electric shock, CAUTION combustion/ explosion, malfunction or product deformation.
Page 16 • Use only an authorized attachments / accessories - TV with a three-prong grounded AC plug must be approved by LG Electronics. Otherwise, this may connected to a three-prong grounded AC outlet. result in fire, electric shock, malfunction, or product Ensure that you connect the earth ground wire to damage.
Page 17 Preparing • Batteries - Store the accessories (battery, etc.) in a safe location out of the reach of children. • When the TV is turned on for the first time after - Do not short circuit, disassemble, or allow the being shipped from the factory, initialization of the batteries to overheat.
Page 18: Optional Extras
Optional Extras Lifting and Moving the TV Optional extras can be changed or modified for When moving or lifting the TV, read the following to quality improvement without any notification. prevent the TV from being scratched or damaged and Contact your dealer for buying these items. for safe transportation regardless of its type and size.
Page 19: Mounting On A Table
Mounting on a Table Using the Kensington Security System (optional) (Depending upon model) (Depending upon model) 1 Lift and tilt the TV into its upright position on a The Kensington security system connector is located table. at the rear of the TV. For more information of - Leave a 10 cm (4 inches) (minimum) space from installation and using, refer to the manual provided the wall for proper ventilation.
Page 20: Attaching The Tv To A Desk
Attaching the TV to a desk (TYPE B) (Depending upon model) If mounting the TV on a table, make sure it is installed according to the method outlined in ‘Attaching the TV to a desk’ . The TV should be attached to a desk so it cannot be pulled in a forward/backward direction, potentially causing injury or damaging the product.
Page 21: Mounting On A Wall
Detailed instructions will be included with the wall mount. We recommend that you use an LG brand wall mount. The LG wall mount is easy to adjust or to connect the cables. When you do not use LG’s wall mount bracket, use a wall mount bracket where the device is adequately secured to the wall with enough space to allow connectivity to external devices.
Page 22: Other Connections
Connections Other connections Connect your TV to external devices. For the best You can connect various external devices to the TV. picture and audio quality, connect the external device For more information on external device’s connection, and the TV with the HDMI cable. refer to the manual provided with each device.
Page 23 External Speakers Method of volume control port (Depending upon model) (Depending upon model) • Cable Spec. Each up/down pins are connected to CPU with pull up resistor respectively. EXTERNAL SPEAKER OUT SORTIE HAUT-PARLEUR GND / UP / DOWN EXTERNE CPU detects transition from 3.3 V to GND SPEAKER OUT level for volume...
Page 24: Network Setup
Using the Button Network setup (Depending upon model) You can simply operate the TV functions, using the button. Wired network connection This TV can be connected to a Pro:Centric server via the port. After making the physical connection, the TV needs to be set up for network communication.
Page 25: Adjusting The Angle Of The Tv To Suit View
Adjusting the Angle of the TV to suit view (Depending upon model) Swivel 20 degrees to the left or right and adjust the angle of the TV to suit your view. 20˚ 20˚ • When adjusting the angle of the product, watch out for your fingers.
Page 26 (Power) Turns the TV on or off. These access special functions in some menus. Accesses the Smart menu. , , , Control buttons for media contents Selects the remote’s operating mode: TV. Feature can only be enabled or disabled by Selects the remote’s operating mode: DVD.
Page 27: Troubleshooting
TV. Those dots are deactivated pixels and performance. The customer is responsible to ensure do not affect the performance and reliability of the compatibility of their equipment with any LG the TV. Electronics software. If needed, please consult with...
Page 28: Selecting Picture Mode
Settings Adjusting the Brightness of a Picture (Depending upon Model) [Picture] [Advanced Settings] [Brightness] Selecting Picture Mode Adjust the brightness of the entire screen. • [Panel Brightness] Controls the level of screen brightness by adjusting the backlight. [Picture] [Select Mode] •...
Page 29: Specifications
Specifications Product specifications may be changed without prior notice due to upgrade of product functions. Estimated yearly energy consumption indicated on the FTC label is measured in accordance with the Test Procedures for Television Sets (USA only). The actual energy consumption depends on the usage environment (The content watched, TV settings, etc.). Broadcasting Specifications Television system Terrestrial / Cable / Satellites Digital TV...
Page 30: Open Source Software Notice Information
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by LG Electronics Inc. is under license. Other trademarks and trade names are those of their respective owners.
Page 31: Fcc Notice
Regulatory FCC Radio Frequency Interference Requirements (for UNII devices) (For USA) FCC Notice High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. (For USA) These radar stations can cause interference with and/ This equipment has been tested and found to or damage this device.
Page 32: Industry Canada Statement
Industry Canada Statement RSS-247 Requirement (For Canada) (For Canada) [For having wireless function (WLAN, Bluetooth,...)] [For product having the wireless function using 5 GHz frequency bands] This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and (1) The device for operation in the band 5150–5250 Economic Development Canada’s licence-exempt MHz is only for indoor use to reduce the potential for RSS(s).
Page 33 - ALWAYS use cabinets or stands or mounting (For USA) methods recommended by the manufacturer of the LG Electronics offers a customized e-waste take- television set. back & recycling service that meets local needs - ALWAYS use furniture that can safely support the and requirements in the countries where e-waste television set.
Page 34: Disposal Of Your Old Appliance
3 You can take your appliance to any of the authorized centers for collection, If you want to know an updated list of countries that have this service, visit the page https://www.lg.com/global/take-back- recycling-global-network-south-america Eliminación de su viejo electrodoméstico...
Page 36 Supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632 E-mail lg.environmental@lge.com LG Customer Information Center The model and serial number of the product are located on the back and on one side of the product.
