Installation and Operating Handbook
ICLH Combiner
ISLH Splitter
Covers single and multi-channel ICLH / ISLH units
th
Handbook Issue 1.30, 9
September 2021
1997
EN 55022 CLASS B
EN 50082-1
EN 60950
PEAK COMMUNICATIONS Ltd.
Unit 1, The Woodvale Centre, Woodvale Road,
Brighouse, West Yorkshire
HD6 4AB, England
Phone 01484 714200
Fax 01484 723666
IMPORTANT NOTE: THE INFORMATION AND SPECIFICATIONS CONTAINED IN THIS
DOCUMENT SUPERCEDE ALL PREVIOUSLY PUBLISHED INFORMATION CONCERNING
THIS PRODUCT
PEAK COMMUNICATIONS Ltd maintains a continuing programme of product improvement
and therefore reserves the right to change specifications without notice
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PEAK COMMUNICATIONS ICLH
Summary of Contents for PEAK COMMUNICATIONS ICLH
- Page 1 Fax 01484 723666 IMPORTANT NOTE: THE INFORMATION AND SPECIFICATIONS CONTAINED IN THIS DOCUMENT SUPERCEDE ALL PREVIOUSLY PUBLISHED INFORMATION CONCERNING THIS PRODUCT PEAK COMMUNICATIONS Ltd maintains a continuing programme of product improvement and therefore reserves the right to change specifications without notice...
-
Page 2: Table Of Contents
Alarms ....................................6 Ethernet....................................6 OPERATION ................................... 7 Menu Structure ................................. 7 REMOTE CONTROL ................................13 Serial Communications RS232/ 485 ........................... 13 Ethernet..................................... 14 EXAMPLE FRONT / REAR PANELS ..........................16 Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 2... -
Page 3: Introduction
VDE 0871 and FCC 20708, providing at least 40 dB of attenuation from 30 MHz to 1 GHz. Connecting cables must be of the shielded type Operation of the equipment in a non standard manner will invalidate compliancy to these standards. Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 3... -
Page 4: Safety
60950. This is a system that has separate earth, line and neutral conductors. The equipment is not designed to operate with an IT power system which has no direct connection to earth. Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 4... -
Page 5: Unit Description
An Internal alarm is caused by Power failure, Amplifier failure or Unit out of lock. REAR PANEL DESCRIPTION (GENERIC) EXT. Ref External Reference input. Remote RS232/RS485 output for remote monitor and control of the unit. Alarms Alarms connection. Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 5... -
Page 6: Rear Panel Pinouts
Not used GROUND Not used If the mute option is fitted then the unit will be muted unless the above Ext. Mute pin is joined to GROUND. Ethernet RJ45 8P8C female connector Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 6... -
Page 7: Operation
This menu shows an immediate summary of all settings and alarm conditions, more details may be available by pressing the down arrow. For multi-channel units, each channel has its own screen, available by pressing left / right keys. Figure 2 Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 7... - Page 8 Allows the amp selection to be controlled manually or automatically. In automatic mode, if the current amps consumption goes out of range then the other amp will be selected. In manual mode, the amps can be changed over manually. Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 8...
- Page 9 3 Min Alarm Limit – This menu allows the user to set the minimum alarm limit. 4 Max Alarm – This Enables / Disabled the maximum alarm. 5 Max Alarm Limit – This menu allows the user to set the maximum alarm limit. Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 9...
-
Page 10: Remote Control
2 SETUP RS485 - Allows the selection of RS485 UNIT ADDRESS and BAUD RATE. 3 SETUP RS232 - Allows selection of BAUD RATE for RS232 communication. Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 10... - Page 11 Set Options in figure 12 is used to set the Ethernet data all at once on the device, this must be used when trying to change the Ethernet settings. Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 11...
- Page 12 4 Time And Date - Allows setting of current time and date 5 RESET - Forces a software reset of the unit. 6 Fan – Allows control of the internal cooling fan (if fitted) Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 12...
-
Page 13: Remote Control
19200, 9600, 4800, 2400, 1200 or 300. Note that all numeric values are shown as decimal. For the specific remote control instructions for a given unit please see the appropriate unit’s remote control manual. Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 13... -
Page 14: Ethernet
The IBDH/IBUH series units fitted with Ethernet, have a built-in SNMP (Simple Network Management Protocol) agent software. It supports SNMP Trap, RFC1155, 1157, 1212, 1213, 1901 & 1906, as well as the Peak MIBS. Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 14... - Page 15 The Peak SNMPv2 MIB files are available from Peak Communications Ltd website, below is a quick overview of them. The Peak Enterprises node is essentially split into three main areas: Converters - In this node there is a peakxxxxxxxxxxxxxxxModule showing a table of the Converter module(s), this is where the band of the unit can be checked/changed.
-
Page 16: Example Front / Rear Panels
EXAMPLE FRONT / REAR PANELS ICLH04A: ISLH04A: I2SLH04A: Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 16... - Page 17 YES / ENTER STATUS NO / CANCEL ISLH032 32 WAY L-BAND SPLITTER Output Alarms 115/230 VOLTS AC 50/60 Hz Max 60 Watts MODEL NO.: SERIAL NO.: PSU1 Input Ethernet Remote Redundancy PSU2 Issue 1.30 ICLH/ISLH Installation and Operation Handbook Page 17...
