PEAK COMMUNICATIONS P7 R Series Installation And Operating Handbook

Hide thumbs

Advertisement

Quick Links

Download this manual
Installation and Operating Handbook
P7xxxR Converters
rd
Handbook Issue 1.04, 3
April 2024
PEAK COMMUNICATIONS Ltd.
Unit 1, The Woodvale Centre, Woodvale Road,
Brighouse, West Yorkshire
HD6 4AB, England
Phone +44 (0)1484 714200
IMPORTANT NOTE: THE INFORMATION AND SPECIFICATIONS
CONTAINED IN THESE DOCUMENTS SUPERSEDE ALL PREVIOUSLY
PUBLISHED INFORMATION CONCERNING THESE PRODUCTS
Page 1
P7xxxR Series Converters

Advertisement

loading
Need help?

Need help?

Do you have a question about the P7 R Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PEAK COMMUNICATIONS P7 R Series

Summary of Contents for PEAK COMMUNICATIONS P7 R Series

  • Page 1 Installation and Operating Handbook P7xxxR Converters Handbook Issue 1.04, 3 April 2024 PEAK COMMUNICATIONS Ltd. Unit 1, The Woodvale Centre, Woodvale Road, Brighouse, West Yorkshire HD6 4AB, England Phone +44 (0)1484 714200 IMPORTANT NOTE: THE INFORMATION AND SPECIFICATIONS CONTAINED IN THESE DOCUMENTS SUPERSEDE ALL PREVIOUSLY...
  • Page 2 Table of Contents PRODUCT COMPLIANCE .......................... 3 Safety ............................... 3 EMC ................................4 1. INTRODUCTION ............................4 1.1 General product overview ........................4 1.2 Functional description ......................... 6 1.3 Review of P7xxxR series generic specification parameters ............... 6 1.3.1 UpConverter IF Input ........................6 1.3.2 UpConverter L / S / UHF-Band Output ..................
  • Page 3 You can also contact us via our website at www.peakcom.co.uk To return a Peak Communications product for repair: 1. Contact the Peak Communications support department and request a Return Material Authorisation (RMA) number. 2. You will be required to provide to our support representative the model number, serial number and a detailed description of the problem.
  • Page 4 To ensure safety of operator the P7xxxR series of converters have been designed to comply with the following safety standard; EN 60950: Safety of information technology equipment, including electrical business machines Operation of the equipment in a non standard manner will invalidate compliance to this standard.
  • Page 5 This manual covers the installation and operation of the P7xxxR Up and Down frequency converters. A sample specification and review of generic specification parameters is incorporated in this manual, but is not guaranteed to be the latest specification or to represent all products covered by this manual, so please visit our website www.peakcom.co.uk for exact up to date specifications of the unit in question.
  • Page 6 1.2 Functional description The P7xxxR series will UpConvert a 70 ±18MHz (optionally 140MHz ±36MHz) signal to a frequency within the L-Band range of 950-1750 MHz or S-Band range of 2.025- 2.120GHz) and will DownConvert signals within the L-Band range of 950-2150MHz or S-Band range of 2.2-2.3GHz to 70 ±18MHz (optionally 140MHz ±36MHz).
  • Page 7 950-2150MHz (2200-2300MHz for S-Band, 390-450MHz for UHF-Band) range of limit of input. 1.3.5 Frequency Resolution 1 Hz Output frequency step size. 1.3.6 Phase noise (dBc/Hz) -65dBc/Hz @ 10Hz; -75dBc/Hz @ 100Hz; -80dBc/Hz @ 1kHz; -85dBc/Hz @ 10kHz; -95dBc/Hz @ 100kHz; -110dBc/Hz @ 1MHz. Typical depending on model At 100Hz away from the carrier the average relative intensity of the carrier in CW mode at that point is 75dB lower than the centre frequency...
  • Page 8 Gain; +30dB ±1dB Attenuation; 0-30dB, stepped 0.1dB The gain of the converter can be set to have no gain (0dB) at maximum attenuation or a gain of 30dB at minimum attenuation. The finite gain set is specified to be within 2dB of the setting and the step size is 0.1dB. 1.3.10 Gain flatness ±1.5dB full band, ±0.5dB, across any 36MHz in band The slope and variation of power across the L/ S-Band should be within 2dB top...
  • Page 9 mixing with the input to give an interfering signal (4.9-3.4=1.5). A 5.15GHz LO is therefore used to avoid this problem and consequently the L-Band to 70MHz converter (P7xxxR) has to have INVERT enabled to preserve the spectrum. It is not normal to transmit inverted. 1.3.14 Auxiliary DC output.
  • Page 10 P7001R Remote Mount IF Downconverter Page 10 P7xxxR Series Converters...
  • Page 11 Operation Remote control is available from the front face connections in RS232/RS485 or with optional ethernet control. All internal oscillators are fed from a single internal reference, which can also be locked to an externally provided 10MHz reference frequency to ensure the system is stable and the changeover from one converter to another, minimizes traffic interruption.
  • Page 12 POWER / ALARMS 16 pin connector with connections as below. The cable used must be rated for 1Amp continuous use. Pin number Function Description Chassis Gnd RS232 Rx RS232 Communication Rx RS232 Tx RS232 Communication Tx RS485 Y RS485 Communication Tx + RS485 Z RS485 Communication Tx - RS485 B...
  • Page 13 REDUNDANCY INTERFACE 12 pin connector with connection as below. The cable used must be rated for 1Amp continuous use. Pin number Function Can Bus Low Power A Power B Can Bus High Tellback A Tellback B Not Used Not Used Not Used Ethernet Reset STATUS...
  • Page 14 1.7 Fault philosophy Fault conditions are divided into two categories; a) MAIN UNIT COMMON FAULTS; Faults with internal items that effect the overall unit (Main power supply assembly etc). b) DEVICE SPECIFIC FAULTS; Faults that are specific to the Up or DownConverter assemblies.
  • Page 15 MAIN UNIT COMMON FAULTS: Fault Name MUTED SUMMARY ALARM Primary DC Power Supply Over/Under Temperature External Reference Fault Crystal Fault Redundancy Coax Switch DEVICE SPECIFIC FAULTS; UPCONVERTER: Fault Name MUTED SUMMARY ALARM +3 VDC Power Supply +5 VDC Power Supply +15 VDC Power Supply Primary DC Power Supply LO Fault...
  • Page 16 • P700XR series product. • Operation Manual. • Test Results. • Spares Kit. If you suspect that any item is missing, please contact Peak Communications immediately. 2.1.3 Storage Store the product in the normal horizontal orientation, in its outer carton until it is required for use.
  • Page 17 2.2.1 Mounting The product can be mounted using the multiple mounting holes supplied on the bracket. Alternatively the mounting brackets may be removed and the unit mounted using the 4 hole on the base of the unit, hoever the correct length of screw must be used to prevent damage to the unit 2.2.2 Cooling Unit must be mounted in a position to minimise solar gain and provide cooling via the...
  • Page 18 2.3.2 Earthing An external protective earth, providing protection against RF and transient currents, should be connected to the mounting bracket. 2.4 Other Interface Connections 2.4.1 L / S / UHF-Band Connections These are provided on the front face and have the following characteristics; Converter Type Connection Panel Label...
  • Page 19 The IF input frequency should be within the range 50 to 90 MHz (100 to 180MHz with the 140MHz option). 2.4.4 External Reference Input Connections These are provided on the front face and have the following characteristics; Converter Type Connection Panel Impedance Notes.
  • Page 20 If the units are in Manual redundancy mode then the units will stay in their online/offline positions no matter what the state of the other unit. In redundancy either mode the standby unit can be made to go online by the changeover option in the menu.
  • Page 21 1 for N Redundancy For 3+1 to 8+1 switched redundant operation the RCU1000 series of redundancy units are available (see appropriate data sheet for specification). Page 21 P7xxxR Series Converters...
  • Page 22 5. REMOTE CONTROL The unit transmits and receives data serially in an asynchronous format using the standard ASCII character set. The serial data consists of message frames composed of the following message characters: STX, BYTE COUNT, DEVICE ADDRESS, INSTRUCTION, BODY, CHECKSUM, ETX. All characters are compulsory except for the message body.
  • Page 23 Instruction Number List: (in decimal) (P7xxxR): To P7xxxR unit From P7xxxR unit Description Requests Ethernet settings status Responds with Ethernet settings status Requests Rx/Tx Status Responds with Rx/Tx Status Requests Rx/Tx setting changes Set Remote/Local Mode request Serial Communications Configuration Asks for the main Unit settings Replies with the Unit Settings Requests redundancy status...
  • Page 24 Ethernet Settings Status Message This message is sent to the unit, when the host computer wishes to query the Ethernet settings. These Ethernet messages have an Instruction number as well as a subinstruction. Instruction 4, Subinstruction 1 (Ethernet Status Request): Message Set Value / Length...
  • Page 25 Ethernet Configure Message This message is sent to the unit, when the host computer wishes to change the Ethernet settings of the unit, subject to the fitting on the Ethernet option. The unit does not need to be in remote mode for this to be achieved.
  • Page 26 TCP Port Status Message This message is sent to the unit, when the host computer wishes to query the TCP port number, subject to the fitting of the Ethernet option. Instruction 4 Subinstruction 2 (TCP Port Status Request): Message Set Value / Length Description Byte No.
  • Page 27 Instruction 20 (Rx/Tx Status Request): Message Set Value / Length Description Byte No. (example) (bytes) No of bytes in message Address Message instruction (‘R’) Device we are asking the information for: ‘R’ = Receive ‘T’ = Transmit Checksum Instruction 21 (Rx/Tx Status Request Reply): Message Set Value / Length...
  • Page 28 Rx : 1ST LO Fault Tx: 1ST LO Fault ‘0’ = OK ‘1’ = FAULT (‘0’) ✓ ✓ External Alarm Fault ‘0’ = OK ‘1’ = FAULT ✓ ✓ (‘0’) External Mute ‘0’ = OK ‘1’ = MUTED ✓ ✓ (‘0’) Internal Communications Fault ‘0’...
  • Page 29 Instruction 22 (Rx/Tx Reconfiguration Request): The message body for this message is a truncated form of the Rx/Tx Status Request Reply (instruction 21) i.e. no information after the SHF Gain I/P power parameter is sent. Not all parameters have to be set, if the user doesn’t wish to change a particular parameter then a number of ‘x’’s can be sent in the parameter’s place.
  • Page 30 Instruction 24 (Set Remote/Local Mode): Message Set Value / Length Description Byte No. (example) (bytes) No of bytes in message Address Message instruction (‘R’) ‘R’ = Remote Mode ‘L’ = Local Mode Checksum Serial Communications Configuration Message Due to the lack of a front panel on these converters it is possible to change their address, baudrate and whether they use RS232 or RS485 communications via a serial message.
  • Page 31 The unit MUST be in remote mode to allow reconfiguration of parameters via the remote control. Instruction 40 (Unit Status Request): Message Set Value / Length Description Byte No. (example) (bytes) No of bytes in message Address Message instruction Checksum Instruction 41 (Unit Status Request Reply): Message Set Value /...
  • Page 32 Instruction 45 (Redundancy Status Request): Message Set Value / Length Description Byte No. (example) (bytes) No of bytes in message Address Message instruction Checksum Page 32 P7xxxR Series Converters...
  • Page 33 Instruction 46 (Redundancy Status Request Reply): Message Set Value / Length Description Byte No. (example) (bytes) No of bytes in message Address Message instruction (‘1’) Redundancy Type Configuration ‘1’ = 1 for 1 ‘2’ = 1 for 2 ‘N’ = 1 for N (‘M’) Redundancy Manual Mode ‘M’...
  • Page 34 Instruction 47 (Redundancy Change Request): When a unit is in a 1 for 1 configuration only the “Unit To Go Online” parameter in the message below can be manipulated on the currently OFFLINE unit. When a unit is in a 1 for 2 configuration if the unit is selected as standby then all the parameters can be modified apart from the unit priority.
  • Page 35 Management Protocol) agent software. It supports SNMP Trap, RFC1155, 1157, 1212, 1213, 1901 & 1906, as well as the Peak MIBS. The Peak SNMPv2 MIB files are supplied by Peak Communications Ltd, below is a quick overview of them. Page 35...
  • Page 36 The Peak Enterprises node is essentially split into three main areas: Converters - In this node there are numerous nodes: peakUpConverterModule showing a table of the Up Converter module. peakDownConverterModule showing a table of the Down Converter module. These tables show the current settings of the converter module and allow their reconfiguration.
