Astro Pneumatic Tool EUROHE102 Manual

Model:
EUROHE102
(1.2mm Nozzle Size)
EUROHE103
(1.3mm Nozzle Size)
EUROHE105
(1.5mm Nozzle Size)
WARNING
Study, understand and follow all instructions provided
with this product. Read these instructions carefully
before installing, operating, servicing or repairing this
tool. Keep these instructions in a safe accessible place.
INTENDED USE OF THE TOOL
The Astro EuroPro Spray Guns are designed to spray the following
solvent and waterborne light to medium viscosity materials: Enamels,
lacquers, polyurethane,urethane top coats, urethane basecoat, urethane
clearcoat and all primers. Materials which are acidic, abrasive and/or
contain benzene must not be used. In order to achieve the best results,
surface and paint preparation must be completed in accordance with
paint manufacturer's instructions and recommendations. The Astro
EuroPro Guns are intended to be used only by professionally trained
individuals. Strict compliance of applicable local and national regulations
must be followed. Do not use this tool outside of the designed intent.
Never modify the tool for any other purpose or use.
WARNING
Caution: To help prevent personal injury
• Use of this product can expose you to chemicals
such as phthalates which are known to the State
of California to cause cancer, and birth defects or
other reproductive harm. For more information go
to www.P65Warnings.ca.gov/product.
Always wear ANSI approved safety equipment,
safety glasses and clothing when using this
product. Study, understand, and follow all
instructions provided with this product. Failure to
read and follow all warnings and operating
instructions may result in damages and serious
injury or death.
• Always wear ANSI approved goggles when using
this product. (Users and By standers).
• Never use this tool for any application other than for
which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
• Improper operation and/or maintenance of the tool,
modification of the tool, or use of the tool with
accessories not designed for it could result in
serious injury or death.
• Always select the correct accessories of the correct
size and design for the job that you are attempting to
perform.
• Always work in a clean, safe, well-lit, organized and
adequately equipped area.
• Do not begin repairs without assurance that vehicle
is in secure position, and will not move during repair.
BEFORE USE
When unpacking, check the parts diagram and part
number listing on page 3 to make sure all parts are
included. If any parts are missing or damaged,
please call your distributor.
DO NOT DISCARD – GIVE TO USER
EUROHE107
(1.7mm Nozzle Size)
EUROHE108
(1.8mm Nozzle Size)
EUROHE109
(1.9mm Nozzle Size)
Page 1
Product Type:
EUROPRO HIGH EFFICIENCY/HIGH
TRANSFER SPRAY GUN & CUP
www.astrotools.com
1 YEAR LIMITED WARRANTY
• Astro Pneumatic Tool Co. warrants our products to the original user
against defective material or workmanship for a period of 1 year
(except where noted on our price schedule) from the date of 1st use.
Astro reserves the right to determine whether the product failed
because of defective material, workmanship or other causes and to
charge back for missing parts. Astro Pneumatic Tool Co., at its
discretion, will repair products covered under this warranty free of
charge. The distributor should direct the original user to return the
product (with the exceptions listed below) with the distributor's
name, address, adequate proof of date of purchase or a copy of
warranty card, and a short note explaining the problem. Failures
caused by accident, alteration, or misuse are not covered by
this warranty.
• If one part of this product fails, please do not return the entire
product. Astro will replace free of charge component parts of
this product that fail within 1 year of first use by the original
user. Items included in this category include but are not limited
to kits, hand tool kits and any other product where there are
multiple items or components that make up the unit. Please
contact the phone number below in order to obtain the
replacement components covered under warranty.
• Astro Pneumatic Tool Co. or its authorized service representatives
must perform all warranty repairs. Any repair to the product by
unauthorized service representatives voids this warranty. The rights
under this warranty are limited to the original user and may not be
transferred to subsequent owners.
• This warranty is in lieu of all other warranties, expressed or implied,
including warranties of merchantability and fitness for a particular
purpose. Some states do not allow the exclusion of limitations of
incidental or consequential damages so the above limitations may
not apply to you.
PLEASE DO NOT RETURN ANY PRODUCT WITHOUT CALLING
1-800-221-9705 FOR INSTRUCTIONS
PRODUCT INFORMATION
DURABLE & LIGHTWEIGHT
• Forged body provides longer tool life
• Anodized body for corrosion protection
• Slick finish for faster & easier cleaning
HIGH EFFICIENCY
• Unique pattern designed for great coverage, optimal overlapping
• Low overspray (bounce back) • Great transfer efficiency
• Superior atomization • Innovative High Efficiency (HE) advanced technology
QUICK THREAD TECHNOLOGY
• 1 Turn to lock/unlock the air cap • 3 Turns to lock/unlock the fluid tip
• Wide threads for easy cleaning • M16*P1.5 female thread fluid joint
• Compatible with most traditional and disposable cup systems
SMOOTH OPERATION
• Soft trigger pull to reduce fatigue
• Precise lubricated adjustment knobs for better control
• Innovative CNC machining to avoid the need for gaskets behind the fluid tip
Specification:
Nozzle Size: 1.2mm, 1.3mm, 1.5mm,
1.7mm, 18.mm or 1.9mm
Cup Capacity: 600ml
Operation Pressure: 29psi
Weight: 0.7lbs. (325g)
Gun Dimensions W x H: 7" x 5-3/4"
(175mm x 145mm)
• Internal coated passages
• Stainless steel needle and fluid tip
• Lightweight: 325 grams (0.7 Lbs)
Avg. Air Consumption: 10.5-12.5cfm
Air Inlet Thread NPT: 1/4"
Required Compressor: 3-5hp
Max. Pattern at 6" to 8" Distance:
11"-13" (280-330mm)
Air Hose I.D. Size: 6-8mm
