Summary of Contents for TECshow FRESNEL GO 200
- Page 1 FRESNEL GO FRESNEL GO 200 200W FRESNEL ZOOM LED SPOT LIGHT USER MANUAL | MANUAL DE USUARIO PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE USE POR FAVOR LEA LAS INSTRUCCIONES ANTES DE USAR P. 1 Versión Español | Tecshow Pinspot ZOOM...
-
Page 2: Security Warning
• There is no user serviceable parts inside the product, do not open the housing and never operate the product with the cover removed. • Place the unit where kids can’t reach. If you have any questions,don’t hesitate to consult our dealer or manufacturer. P. 2 English Version | Tecshow Fresnel Go 200... -
Page 3: Main Technical Parameters
• Dimensions: 505 x 289 x 264 mm • Weight: 8.6kg • Surface treatment: Aluminum die casting, powder coating • Housing color: Black (Can be customized) • Connection: Signal cable IN/OUT, power cable IN/OUT. P. 3 English Version | Tecshow Fresnel Go 200... -
Page 4: Product Features
11) 5 kinds DMX working mode. 12) 4 fan control modes. 13) Master-slave control, multi-units for synchronous control. PRODUCT PACKING INFORMATION Following accessories are packed together with the product,please check them carefully upon unpacking. P. 4 English Version | Tecshow Fresnel Go 200... -
Page 5: Product Installation
110V or 230V or use voltage regulator to supply power. After electrical connection, this product will have a few seconds self-check action, self-check finished can be used. P. 5 English Version | Tecshow Fresnel Go 200... - Page 6 • Every DMX address code can be reused as needed. • DMX address code can be any data between 001 to 512. XLR 3-PIN CABLE Pin# Function Ground (Screen) Data Minus Data Plus P. 6 English Version | Tecshow Fresnel Go 200...
-
Page 7: Operation Method
Dimmer: Manual encoder dimming knob. In the main menu, press the encoder to enter the manual dimming menu. Zoom: Manual encoder zooming knob. Press the encoder to exit the manual dimming menu. P. 7 English Version | Tecshow Fresnel Go 200... -
Page 8: Menu Overview
When other light in DMX mode, the data on Setting, User Color and Static can be sent to other light to receive and save Factory Reset NO / YES Restore factory settings P. 8 English Version | Tecshow Fresnel Go 200... - Page 9 • Press [MENU] to find the [Dimmer Curve] menu and press [ENTER] to enter dimming curve setting. • Press the [UP/DOWN] button to select [Linear], [Exponential], [Logarithmic], or [S-Curve]—four types of dimming curves. • Press [ENTER] to confirm, and the selected option will be automatically saved. P. 9 English Version | Tecshow Fresnel Go 200...
- Page 10 • Select 9CH-DZA DMX channel mode. • System Settings suggest setting the dimming curve to [Linear], the refresh frequency to 2.5KHz, and the dimming mode to [LED] for better dimming effects. P. 10 English Version | Tecshow Fresnel Go 200...
-
Page 11: Control Channel
Constant strobe dimming from 100~0% 11~33 Constant strobe dimming from 0~100% 34~56 Constant strobe on gradient 57~79 1 flash / s → 20 flashes / s (8 values increased 80~255 by 1 strobe) P. 11 English Version | Tecshow Fresnel Go 200... - Page 12 D-RES 9 (9000ms) 140~142 D-RES 10 (10000ms) 143~145 LED Frequency 2.5KHz 146~165 LED Frequency 5KHz 166~185 LED Frequency 10KHz 186~205 LED Frequency 15KHz 206~225 LED Frequency 20KkHz 226~245 LED Frequency 25KHz 245~255 P. 12 English Version | Tecshow Fresnel Go 200...
- Page 13 D-RES 9 (9000ms) 140~142 D-RES 10 (10000ms) 143~145 LED Frequency 2.5KHz 146~165 LED Frequency 5KHz 166~185 LED Frequency 10KHz 186~205 LED Frequency 15KHz 206~225 LED Frequency 20KkHz 226~245 LED Frequency 25KHz 245~255 P. 13 English Version | Tecshow Fresnel Go 200...
-
Page 14: Maintenance
Remark: This product warranty for one year. We provide pay-needed maintenance service after the warranty. But because of natural and man-made disasters or improper operation caused damage not under warranty range. P. 14 English Version | Tecshow Fresnel Go 200... - Page 15 . c o m /a m p rogrou p /a m prog ro up P. 15 English Version | Tecshow Fresnel Go 200...
