JMP Skan Boost 1000 Manual

Lithium jump starter for 12 v
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

Skan Boost 1000
Lithium jump starter for 12 V
JM no. 609 04 00
Scope of supply:
JMP Skan Boost 1000, charging cable, jumper cables, protective case
Thank you for choosing the JMP Skan Boost 1000 jump starter. The JMP Skan Boost 1000 jump starter is suita-
ble for jump-starting cars, vans, small lorries, boats, mobile homes, motorbikes, scooters, quad bikes, etc.
Charge the jump starter immediately after purchasing it, after every use and every 30 days or if its charge falls
below 85%, in order to charge the internal battery fully and extend the battery's service life.
Technical data:
12 V / 500 A continuous power, 1,000 A peak current
Dimensions: 245 x 130 x 115 mm, weight: 1 kg
Recommended for use between -20°C and +50°C
Charge at between 0°C and +45°C
Suitable for:
• Standard lead acid
• Gel
• AGM
• EFB
• Lithium (LiFePO4)
Safety information:
•
Read the instructions for use before using the device and keep them instructions available for future refe-
rence. These instructions explain how to use the device safely and efficiently. Please read and follow the
instructions and safety information carefully. Failure to do so may result in serious injuries or death.
•
Read, understand and follow all instructions concerning the battery, vehicle and equipment to be used.
Check the warnings on the battery and engine.
•
Do not expose the device to rain, snow, moisture or dust.
•
Warning: Explosive gases! Avoid naked flames and sparks. Ensure adequate ventilation during charging/
use.
•
Risk of electric shocks.
•
Fire hazard.
•
Risks from hazardous substances.
•
Wear protective clothing: protect eyes and body completely, including safety goggles.
•
Keep out of reach of children.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Skan Boost 1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JMP Skan Boost 1000

Summary of Contents for JMP Skan Boost 1000

  • Page 1 JMP Skan Boost 1000, charging cable, jumper cables, protective case Thank you for choosing the JMP Skan Boost 1000 jump starter. The JMP Skan Boost 1000 jump starter is suita- ble for jump-starting cars, vans, small lorries, boats, mobile homes, motorbikes, scooters, quad bikes, etc.
  • Page 2 • This device should not be operated by people (including children) with limited physical, sensory or mental capabilities or a lack of experience and relevant knowledge, unless such individuals are super- vised or receive corresponding training. • Supervise children to ensure they do not play with the device. •...
  • Page 3 2. General information 2.1 Description Output socket for smart cable LED light USB-C port for charging USB output 5 V – 2.4 A USB output 5 V – 3 A LCD display Display button Pad for wireless charging Smart cable with battery clamps Not shown: Type C / USB cable and bag 3.

  • Page 4: Using The Led Light

    4. Using the LED light Press the display button. Hold the display button depressed for 3 seconds. As soon as the LED light illuminates (continuously), press the display button and release it to switch between the following modes. - Flashing for an SOS signal - Flashing in strobe mode If you do not require the LED light anymore, press the display button until the light turns off.

  • Page 5: Maintenance And Storage

    Connection to the jump starter – standby mode: Connect the smart cable with the battery clamp to the jump starter output socket. The green LED on the smart cable flashes, which means that the jump starter is in “Jump starter standby mode”. Connection to the battery: First, check whether the negative terminal is connected to the chassis/earth.

  • Page 6: Troubleshooting

    8. Troubleshooting 8.1 Jump starter Problem: Solution: The jump starter’s display doesn’t Check that the device is charged. Connect it to a power supply to illuminate. reset. Check that you have pressed the display button. The thermometer symbol is The device is too hot or too cold. The thermometer symbol disap- flashing.

  • Page 7: Eu Declaration Of Conformity

    Disposal: Do not dispose of electrical appliances, batteries and rechargeable batteries as domestic waste. Old electrical and electronic appliances must be collected separately and recycled in an environmentally friendly way. Illegal disposal of the device represents a breach of the law on the disposal of hazardous waste and results in a fine.
