Maretron MConnect WSV100-01 Manual

Vessel monitoring web server

Hide thumbs

MConnect

Vessel Monitoring Web Server

WSV100-01

Overview Presentation

Revision: 10/24

Table of Contents

Need help?

Do you have a question about the MConnect WSV100-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Maretron MConnect WSV100-01

Page 1 MConnect Vessel Monitoring Web Server WSV100-01 Overview Presentation Revision: 10/24...
Page 3 87 Screen Component types ▪ 72 Engaging out the box screen components ▪ 15 User Defined components (add your own graphics) ➢ Built in Screen Editor ▪ User Defined Layout ▪ Multiple Screens ▪ Multiple Configurations Confidential and Proprietary | Maretron © 2024...
Page 4 15 Custom graphics gives control over the look and feel ▪ Requires graphic design experience (e.g. Photoshop) ➢ Product Manufacturer (OEM) ▪ Who want to display their product information on an MFD without investing in extensive development costs. ▪ White Label Confidential and Proprietary | Maretron © 2024...
Page 5 What’s in the box? ➢ MConnect box and mounting screws ➢ Power Cable (9-30V 1.5A) ➢ CAT 5E Ethernet patch cord (7ft) ➢ Getting started instructions ➢ Ethernet waterproof connection cover for custom cables. Confidential and Proprietary | Maretron © 2024...
Page 6 Commercial Graphics Modern Graphics Limited Customization Extensive Customization Telemetric Data Telemetric Data N2KView Mobile Available via any browser Real Time Cloud Service VPN for remote secure access Built in Editor Built in Editor Confidential and Proprietary | Maretron © 2024...
Page 7 MConnect Client Server Model MFDs MConnect MConnect Server Phone / Tablet Server Ethernet MAC / PC Confidential and Proprietary | Maretron © 2024...
Page 8: Ethernet (Rj45)
Installing Connections ➢ ® NMEA 2000 ➢ Power (9-30V, 1.5A) ➢ Serial (Future Use) ➢ Ethernet (RJ45) ➢ USB for ▪ Updates ▪ USB to Ethernet adapters Confidential and Proprietary | Maretron © 2024...
Page 9 Connect to 2 separate networks ▪ Navigation ▪ Vessel Monitoring ➢ Connect to redundant networks ▪ Primary ▪ Secondary ➢ Control Digital Switches (MPower, Octoplex, ++++) ➢ Note: it is not possible to bridge these networks Confidential and Proprietary | Maretron © 2024...
Page 11 Ethernet - Network Layout Party Support • Garmin • Navico • Raymarine • Simrad • Time Zero • Furuno • Hatteland • Q Experience Confidential and Proprietary | Maretron © 2024...
Page 14 Multiple overlapping components, including images and videos ▪ Named ▪ More than one screen can have the same name, and the best screen is chosen based on the shape (aspect ratio) of the screen. Confidential and Proprietary | Maretron © 2024...
Page 15 Configurations: Switch Groups ➢Switch Groups ▪ Multiple switches controlled as a group ▪ Individual delays (prevent switch on spike) ▪ Individual dim values (mood lighting) Confidential and Proprietary | Maretron © 2024...
Page 16 Indicator / Switch State (Bilge High Water, Breaker Tripped) ▪ Time of Day / Sunrise / Sunset / Twilight ➢Actions: ▪ Breaker On / Off / Toggle ▪ Reset Counters / Timers ▪ Screen Jump Confidential and Proprietary | Maretron © 2024...
Page 17 Configurations: Telemetrics ➢Telemetric Cloud Service Parameters ▪ Sent to Maretron Telemetric Cloud Service ▪ Stored for 1 year ▪ You select the parameters to be transferred and the interval Confidential and Proprietary | Maretron © 2024...
Page 18 Commands and Settings - Settings Access through Settings Button or dedicated Action Button Confidential and Proprietary | Maretron © 2024...
Page 19 Instanced at 100, 101, 102 ➢ Sync Vessel Operating mode with N2KView ➢ True Wind Reference ➢ Auto Cycle Through Screens ➢ Settings Cog Wheel position ➢ Time Zone Set ➢ Define Night Mode scheme Confidential and Proprietary | Maretron © 2024...
Page 20 Commands and Settings - Configuration Access through Settings Button or dedicated Action Button Confidential and Proprietary | Maretron © 2024...
Page 21: Configuration Dialog
Configuration Dialog ➢ Active Configuration: Each client has their own configuration. ➢ Default configuration is always loaded – even when there are no clients. Never displayed. Confidential and Proprietary | Maretron © 2024...
Page 22 Configuration Editor ➢Create Screens ➢Create Conditions and Actions ➢Create Switch Groups ➢Can edit on a Laptop web browser and display on any device Confidential and Proprietary | Maretron © 2024...
Page 23 Commands and Settings - About Access through Settings Button or dedicated Action Button Confidential and Proprietary | Maretron © 2024...
Page 24 About ➢ Provides device information summary ▪ Model ▪ Software Version ▪ Serial # ▪ Current Operating Mode ▪ IP Address(s) Confidential and Proprietary | Maretron © 2024...
Page 25 Commands and Settings - Devices Access through Settings Button or dedicated Action Button Confidential and Proprietary | Maretron © 2024...
Page 26 Devices Real Time display of received data ➢ You can filter by device and/or Device Instance Confidential and Proprietary | Maretron © 2024...
Page 27 Commands and Settings - Diagnostics Access through Settings Button or dedicated Action Button Confidential and Proprietary | Maretron © 2024...
Page 28 Diagnostics This contains pertinent information for our Support & Engineering team for troubleshooting device and server behavior. Confidential and Proprietary | Maretron © 2024...
Page 29 Commands and Settings - Screens Access through Settings Button or dedicated Action Button Confidential and Proprietary | Maretron © 2024...
Page 30 You may select a screen and press the GO button to display that screen. This need only be used if the screen designer did not add a screen navigation button to a screen. Confidential and Proprietary | Maretron © 2024...
Page 31 Commands and Settings - VPN Access through Settings Button or dedicated Action Button Confidential and Proprietary | Maretron © 2024...
Page 32 ➢Secure access from anywhere in the World! ➢Built in Tailscale VPN ▪ User must create an account. ▪ User must install Tailscale on devices. Confidential and Proprietary | Maretron © 2024...
Page 33 Install VPN on MConnect ▪ Need correct time and date on the MConnect ▪ Need Internet through the LAN port ▪ Set up a Tailscale account ▪ Download Tailscale to your devices – Computer/ Mobile Confidential and Proprietary | Maretron © 2024...
Page 34 Tailscale allows you to share the device with other Tailscale account holders ▪ Use the Tailscale IP address for N2KAnalyzer for remote access ▪ Enable or disable key expiry (default is expire in 6 months) Confidential and Proprietary | Maretron © 2024...
Page 35: Out Of Box Setup
IP address to communicate. ▪ If multiple MConnects on the same network, power on each device separately and find the IP address ▪ Create new configuration to be used and displayed. Confidential and Proprietary | Maretron © 2024...
Page 36 Can 1 LED – Green Flashing Can 1 Connected and communicating CAN 2 LED – Green Flashing Can 2 Connected and communicating ALL LEDS – Green Solid Device powered but program not started – Device will require re-imaging Confidential and Proprietary | Maretron © 2024...
Page 54 CONFIGURATION Website Resources The Maretron website has been recently updated to offer our users access to all of the latest technical materials with the ease of navigation. Datasheets, Manuals, Training Videos, Software, Knowledge Base and Sample Systems and more at your fingertips!! www.Maretron.com...
Page 55 WEBSITE RESOURCES N2KAnalyzer - Training Videos https://www.maretron.com/products/n2kanalyzer-v3-nmea-2000-analysis-software/ Confidential and Proprietary | Maretron © 2024...
Page 56 MARETRON WEB PAGES Technical Support Maretron Technical Support (Maretron, MPower and OctoPlex Brands) Monday – Friday 8am - 5pm (EST) Toll Free: (866) 550-9100 Phone: (602) 861-1707 Support@Maretron.com Confidential and Proprietary | Maretron © 2024...
Page 57 This document is provided by Maretron for informational and guideline purposes only. Maretron assumes no liability for errors or omissions in this document or for any of the information contained herein. Information is provided on an “as is” and “with all faults” basis for evaluation purposes only. Applications described are for illustrative purposes only and Maretron makes no representation that such applications will be suitable for the customer’s specific use without further testing or modification.
