HG8960 - QUICK INSTALLATION GUIDE
A. PRODUCT PRESENTATION
FEATURES:
- stereo gaming headset with excellent audio quality
- 50 mm speaker size for powerful bass sounds and clear treble
- rotatable microphone arm and in-line remote control
- console & mobile ready
- soft-cushioned synthetic leather ear cups
TECHNICAL SPECIFICATIONS
Sound: stereo
Frequency response: 20 Hz - 20 KHz
Speaker size: 50 mm
Speaker sensitivity: 106 dB ± 3 dB
Speaker impedance: 32 Ω
Microphone type: omnidirectional
Microphone size: 6x2.7 mm
Microphone sensitivity: -42 dB ± 3 dB
Backlight: blue LED
Connectors: 1x 4-pin 3.5 mm jack, 2x 3.5 mm jack via included splitter, USB (for LED light)
Cable length: 2.2 m
Compatibility: PC, consoles (PS4, Xbox One), mobile
SYSTEM REQUIREMENTS
PC system or compatible with the installed sound card, one USB port available.
B. SAFETY NOTES
- To prevent possible hearing problems, do not use the headphones at high volume for long
periods of time.
- Keep the equipment dry. Keep away from precipitation, humidity, all types of liquids and
condensation.
- Do not use the product with wet hands.
- Do not use or store the equipment in dusty or dirty areas.
- Do not store the equipment under high-temperature or low-temperature conditions (this
may damage it).
- Do not drop, knock or shake the equipment (use may result in breakage).
C. INSTALLATION
C.1 PC system
Connect the provided 3.5 mm splitter cable to the headphone. Each audio jack is colored
different (green for headphones, pink for microphone) or has an icon on it. Connect each
