MH01 - QUICK INSTALLATION GUIDE
A. PRODUCT PRESENTATION
The kit includes headset and mouse.
HEADSET
FEATURES:
- Closed, over-ear design for powerful bass sounds
- Soft-cushioned leather ear cups
- Built-in volume controller
TECHNICAL SPECIFICATIONS
Sound: stereo
Frequency response: 20 Hz - 20 KHz
Speaker size: 50 mm
Speaker impedance: 32Ω± 15%
Speaker sensitivity: 120 dB ± 3 dB
Microphone type: omnidirectional
Microphone sensitivity: -38 dB ± 3 dB
Microphone size: 4x1.5 mm
Backlight: Rainbow
Connectors: 2x 3.5 mm jack, USB (for LED light)
Cable length: 2.0 m
MOUSE
FEATURES:
- Ultra-lightweight, as low as 76 grams, thanks to special perforated- honeycomb chassis
design.
- RGB backlight with multiple selectable lighting schemes
- Advanced customization software
TECHNICAL SPECIFICATIONS
Sensor: Optical
DPI: 800-1600-2400-3200-4800-6400 (default)
Buttons: 6 (programmable)
Switch rating: 3 million clicks
Backlight: RGB
Interface: USB 2.0
Cable length: 1.5 m
Weight: 76 grams
Size: 125 x 64 x 40 mm
SYSTEM REQUIREMENTS
Advertisement
Table of Contents
Related Manuals for Marvo MH01
Summary of Contents for Marvo MH01
- Page 1 MH01 - QUICK INSTALLATION GUIDE A. PRODUCT PRESENTATION The kit includes headset and mouse. HEADSET FEATURES: - Closed, over-ear design for powerful bass sounds - Soft-cushioned leather ear cups - Built-in volume controller TECHNICAL SPECIFICATIONS Sound: stereo Frequency response: 20 Hz - 20 KHz Speaker size: 50 mm Speaker impedance: 32Ω±...
- Page 2 PC system or compatible with the installed sound card, two USB ports available; Windows 7 or newer operating system. B. SAFETY NOTES - To prevent possible hearing problems, do not use the headphones at high volume for long periods of time - Keep the equipment dry.
- Page 3 (an Internet connection is required): - download the driver and double-click the executable file; - follow the on-screen instructions and install the application; - after installing the application successfully, an icon will be displayed in the taskbar; - double-click this icon to launch the application.
- Page 4 Address： Distributor Name： TEL： Warranty Card is the important certificate for after-sale service of Marvo products, Please keep it appropriately.
