Summary of Contents for Planet Networking & Communication UNC-NMS
- Page 1 Quick User Guide UNC-NMS...
- Page 2 Overview...
- Page 3 Overview Main Features: Dashboard Providing an at-a-glance view of center system, site summary, site map, traffic, and PoE network status. Site Management Creating a site list and site map for NMS agent management. Device List Managing all site devices or filtering devices for specific sites for NMS agent functions. Statistic Displaying top 10 event reports, history comparisons, and critical events for devices.
- Page 4 Overview Network Management Characteristics Built-in DHCP Server Built-in RADIUS Server SSL secure access Certification Authentication Web-based GUI management interface SNMP v1, v2c, and v3 management Supports PLANET DDNS/Easy DDNS Industrial-grade Physical Hardware ...
- Page 5 APPLICATIONS...
- Page 6 Applications...
- Page 7 Before First Login...
-
Page 8: Product Overview
Product Overview Front Panel (LAN 5 and LAN 6 are bypass ports) - Page 9 Product Overview Back Panel (100~240V)
- Page 10 Remote Logging in NMS Open Chrome/Firefox to log in the NMS.( Default IP: https://192.168.1.100:8888) Please use Chrome/Firefox to get fully supported. (UI Resolution 1280 x 1024) 1. Press the “ADVANCED” button 2. Press “Proceed to…”...
-
Page 11: Setup Wizard
Setup Wizard... - Page 12 Account Modification Steps to modifying account: 1. Please create a new account, avoiding the use of "admin“. 2. New Password must include at least 1*[a~z], 1*[A~Z], 1*[0~9], 1*[~, !, @, ..., w/o "?"] and must contain at least 8 characters.
- Page 13 IP Configuration Setting 1. Select “Static IP” or ” DHCP Client” for IP configuration setting. 2. IP status is shown in real time. *If you want to use the SMTP Alarm function, you must at least enter one DNS server.
- Page 14 How to Add a New Site...
- Page 15 How to add a New Site Steps to add a new site: 1. Press the “1. Site” button to go to the site, and then, navigate to “2. Summary or Map” page. (The default page is Summary.) 2. Press the “3.
- Page 16 How to add a New Site Steps to add a new site: (Fields marked in red are required) 3. Enter the Site information for “1. Site Name, Description, City, Address, Latitude, Longitude and Image”. 4. Enter the NMS Agent Configuration for “2.
- Page 17 How to add a New Site Steps to add a new site: 5. Press the “1. Export” button to create an “NMS-Agent-Conf” file. 6. Click the “2. Download NMS Agent Configuration” link to get the “3. file”. ...
- Page 18 How to add a New Site Steps to add a new site: 5. Press the “1. Export” button to create an “NMS-Agent-Conf” file. 6. Click the “2. Download NMS Agent Configuration” link to get the “3. file”. ...
- Page 19 How to add a New Site Steps to add a new site: 7. Going to the NMS-500/NMS-1000V web in Remote Management page. Upload the “NMS Agent Configuration file” in the Step 6. and press “3. Apply”. (It will auto-Import authentication info.) 9.
- Page 20 How to add a New Site Steps to add a new site: 7. Going to the NMS-500/NMS-1000V web in Remote Management page. Upload the “NMS Agent Configuration file” in the Step 6. and press “3. Apply”. (It will auto-Import authentication info.) 9.
- Page 21 How to add a New Site Steps to add a new site: 10. Go back to the UNC-NMS web “Site/Summary” page to check the site status is on-line or off-line ※ In case of issues, please utilize Maintenance/Diagnostics to conduct a ping test between UNC-NMS and NMS-500/NMS-1000V.
- Page 22 Appendix...
- Page 23 Appendix – MQTT Devices Support List Please click...
- Page 24 Appendix – Console When the “UNC-NMS login” appears, please enter user login account “adminuser”, and password “adminuser”.
