Rear I/O
Expansion & Storage
Special Features
Operating Systems
LAN Controllers
Power Supplies
Dimensions
(W x H x D)
Weight
Mounting
1x ID button / LED (Blue)
1x Error LED (Orange)
1x 1GbE Dedicated Management (BMC/IPMI)
2x 10GbE LAN, Intel X710-AT2
2x USB 2.0 Type-A
1x VGA (BMC Video Output)
1x ID button / LED (Blue)
1x COM DB9
1x M.2 2280/221100 M-key (PCIe Gen 5 x4)
6x PCIe Gen 5 x16 / CXL 1.1 Full Height, Full Length Slot
1x PCIe Gen 5 x8 / CXL 1.1 (x8 Electrical, x16 Compatible) Slot
2x MCIO (PCIe5.0 x8) [CPU0]
3x OCuLink (PCIe3.0 x4 or 4 SATA 6Gb/s) [PCH]
Up to 13 SATA 6Gb/s, support RAID 0/1/5/10
All AX300 Series Servers
1x 2.5" SATA Rear Drive Bay
AX301, AX303, AX305, AX307
Support for up to 8x 2.5" 7mm SATA Drives in front bay
AX302, AX304, AX306, AX308
Support for up to 4x 2.5" 15mm NVMe Drives in front bay
RAID 0/1/5/10 Support through Intel VROC*
*VROC Standard only supports RAID 0/1/10
ASPEED AST2600: Full Web UI, iKVM, vMedia support
Optional TPM 2.0 module (Infineon SLB9670) or Intel PTT (Native)
Chassis Intrusion Detection
Security Bezel
Secure Boot
Hot Swap Fans
Bezel Detection
Microsoft Windows Server 2022 Essentials
Microsoft Windows Server 2022 Standard
Ubuntu 22.04 - Server
Ubuntu 24.04 - Server
Red Hat Enterprise Linux 8.10 (or newer)
Red Hat Enterprise Linux 9.x
VMware vSphere and ESXi 8
1x Intel X710-AT2 Controller (2 x 10GBASE-T ports on Rear)
1x GbE Dedicated Management (BMC/IPMI)
Up to 2 PSUs with PMBUS monitoring, 120~220 VAC 50-60Hz input
Delta 1000W/2400W CRPS 80 Plus Titanium AC Power Supply Forward
Airflow (110V/220V Autoranging)
438 x 132 x 421.2mm (17.3 x 5.2 x 16.6") without Security Bezel
482.6 x 132 x 455mm (19.0 x 5.2 x 17.9") with Security Bezel & Handles
132 x 448.2 x 553.6mm (5.2 x 17.6 x 21.8") with Tower Stand, Security
Bezel and Rear Cable Security Bezel
System Maximum: 24 kg (52.9 lbs)
Shipping Maximum: 35 kg (77.2 lbs)
Rack Mount 17" (430-600mm) slide rail
