Tecmojo 12130101 Instruction Manual

Please contact us for any product
related concern and questions
Instruction Manual
Network Cabinet
Save These Instructions
This manual contains instructions and warnings that must be followed during the installation and operation of the product described in this
manual. Failure to comply may invalidate the warranty and cause property damage or personal injury.
Thank you for purchasing a Tecmojo product. Please check the product carefully and contact Tecmojo for assistance if any parts are damaged
or missing. Do not attempt to install or use product if it has been damaged. This product contains small items that could be a choking hazard –
keep these items away from children.
For permanent wall mounting, be sure to securely fasten the enclosure to the building structure before operation.
Do not use with equipment that is heavier than the indicated weight capacity for this product. This product is designed to be installed indoors
on wood stud walls, solid concrete walls or brick walls. Make sure that the supporting surface will safely support the weight of the equipment
and all attached hardware and components. It is recommended that installation be performed by a qualified installer.Tecmojo cannot be held
responsible for damage to equipment or personal injury resulting from improper use or installation of product.
Maintenance: we recommend checking on regular basis that the product is secure and safe to use.
Limitations of Liability: In no event will Tecmojo Co. be liable for any damages, whether direct or indirect, special, punitive, incidental or
consequential damages (including, but not limited to, lost profits or revenue, loss of use, lost business opportunities or loss of goodwill) or for
the costs of procuring substitute products, arising out of or in connection with the use of the product, whether such liability arises from any
claim based upon contract, warranty, tort (including negligence), product liability or otherwise, whether or not seller has been advised of the
possibility of such loss or damage. In no event will seller's total cumulative liability, from all causes of action and all theories of liability, exceed
the total amounts actually paid to seller by customer under the order that gives rise to any liability hereunder.
Specification:
SKU# Capacity
12130101
12130102
18U
12130104
12130105
12130201
12130202
12130204 27U
12130205
12130301
12130302
12130303
42U
12130304
12130305
12130306
Sales@tecmojo.com
806-Tecmojo (8326656)
www.tecmojo.com
Width Depth Height
23.6" (600mm)
31.5" (800mm)
35.4"
23.6" (600mm) (898mm)
31.5" (800mm)
23.6" (600mm)
31.5" (800mm)
51.1"
23.6"
23.6" (600mm) (1298mm)
(600mm)
31.5" (800mm)
23.6" (600mm)
31.5" (800mm)
39.4" (1000mm) 77.4"
(1965mm)
23.6" (600mm)
31.5" (800mm)
39.4" (1000mm)
Page1
Please contact us for any product
related concern and questions
Front
N
Door
Step1.
C
Side Brackets(4)
Q
M6 Screws(24)
Reinforced
H
Components(2)
Square Tube
D
Frames(2)
Sales@tecmojo.com
806-Tecmojo (8326656)
www.tecmojo.com
Hardware
O
M4.4 Screws(2)
A
Top Cover
P
B Back door
C
Side Brackets(4) M8 Screws(8)
Q
D
Square Tube Frames(2)
E
Side Panels(4)
M6 Screws(24)
R
F
L Brackets(2)
G
Rack Rails(4)
M6 Self-tapping Screws(16)
H
Reinforced Components(2) S
Cantilever Shelf
I
600mm Depth-M5 Self-tapping Screws(24)
Components
Above 800mm Depth-M5 Self-tapping Screws(36)
T
Cable tie boards(2)
J
[Not Available in
600mm Depth]
M6 Flange Nuts(12)
U
K
Bottom Panel
L
Leveling Feet(4)
12-24 Screws(70) 12-24 Cage Nuts(70)
Casters with Brake(2)
M
Casters without Brake(2)
V
Connectors(4) M5 Self-tapping Screws(8)
Step2.
R
M6 Self-tapping Screws(16)
L Leveling Feet(4)
Casters with Brake(2)
M
Casters without Brake(2)
K
Bottom Panel
Page2
