- Page 1 Radxa ROCK 5C Product Brief 8K Credit Card-Sized Single Board Computer Revision 1.0 2024-03-24 Radxa Computer...
-
Page 2: Table Of Contents
1 Revision Control Table 2 Introduction 2.1 Radxa ROCK 5C Lite ....... . -
Page 3: Revision Control Table
Radxa ROCK 5C Product Brief 1 Revision Control Table Version Date Changes from previous version 2024/03/24 First version Radxa Computer (Shenzhen) Co., Ltd. -
Page 4: Introduction
Radxa ROCK 5C Product Brief 2 Introduction The Radxa ROCK 5C is a Single Board Computer (SBC) in a compact form factor packed with a wide range of class‑leading functionality, features and expansion options. The ROCK 5C is an ideal choice for makers, IoT enthusiasts, hobbyists, gamers, PC users and everyone who need an extremely highly specified platform with outstanding performance and relia‑... -
Page 5: Radxa Rock 5C
Radxa ROCK 5C Product Brief 2.2 Radxa ROCK 5C Note: The actual board layout or components location may change during the time but the main connectors type and location will remain the same 3 Features 3.1 Hardware Radxa Computer (Shenzhen) Co., Ltd. -
Page 6: Interface
Radxa ROCK 5C Product Brief ROCK 5C ROCK 5C Lite Rockchip RK3582 Rockchip RK3588S2 Dual Cortex®‑A76 Quad Cortex®‑A76 and Quad Cortex®‑A55 and Quad Cortex®‑A55 Arm Mali‑G610MC4 5TOPs@INT8 6TOPs@INT8 Memory 2GB / 4GB / 8GB / 16GB / 32GB LPDDR4x 1GB / 2GB / 4GB / 8GB / 16GB LPDDR4x H.265 and VP9 decoder by 8K@60fps... -
Page 7: Software
Radxa ROCK 5C Product Brief – Up to 1 x ADC – Up to 27 x GPIO – 2 x 5V DC power in/out – 2 x 3.3V power out 3.3 Software ・ ArmV8 Instruction Set ・ Debian/Ubuntu Linux support ・... -
Page 8: Electrical Specification
The ROCK 5C is built on a high‑performance mobile chipset which is designed to operate for extended durations on batteries with efficiency at its core. As with all electronic de‑... -
Page 9: Peripherals
UART8_RX SPDIF1_TX I2S1_SDO0 7.2 Network ROCK 5C offers a 10/100/1000Mbps RJ45 connector for wired networking. With additional PoE module/HAT, ROCK 5C can be powered by ethernet cable via RJ45 port by a PoE capable switch/router. Radxa Computer (Shenzhen) Co., Ltd. -
Page 10: Emmc Socket
Radxa ROCK 5C Product Brief 7.3 eMMC Socket ROCK 5C offers a high speed eMMC socket for eMMC modules which can be used for OS and data storage. The eMMC socket is compatible with readily available industrial pinout and form factor hardware. -
Page 11: Fan Connector
Radxa ROCK 5C Product Brief 7.9 Fan Connector The ROCK 5C has a 2pin 1.25mm header that enables users to connect a 5V fan (or other peripheral). The fan can be PWM controlled without speed feedback. 8 Availability Radxa guarantees availability of the ROCK 5C until at least September 2033. - Page 12 FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
