- Page 1 EACOME SPEAKERPHONE SV13B USER MANUAL...
-
Page 2: Table Of Contents
2.Parts List 3.Getting to know your phone 3.1 Speakerphone overview 3.2 Keypad function 3.3 LED indicator 4.How to use SV13B 4.1 Charging for preparation 4.2 Turning the Power On and Off 4.3 Connecting a Smartphone via Bluetooth 4.3.1 Pairing 4.3.2 Connecting 4.3.3 Disconnecting... - Page 3 CONTENTS 4.6 Multi-party Conference Call & Line Mode Selection 4.7 Daisy Chain Function 5. Other Functions 5.1 Checking the Speaker Volume Level 5.2 Checking the Battery Level 6. How to care for your EACOME speakerphone SV13B...
-
Page 4: Welcome
1. WELCOME Thank you for purchasing the EACOME professional speakerphone SV13B. We hope you will enjoy it ! EACOME PROFESSIONAL SPEAKERPHONE SV13B • Innovative and professional UC communicator for business video calls • UItra-wideband DSP processing delivers the great voice Quality •... -
Page 5: Parts List
2. PARTS LIST Included Accessories USB Cable Power Adapter × 1 4-Strand 3.5mm Cable × 1 User Manual SV13B Phone... -
Page 6: Getting To Know Your Phone
3. GETTING TO KNOW YOUR PHONE 3.1 Speakerphone Overview Headset Power On/Off Line in/out Answer/End Call Volume up Volume down Bluetooth Status LED Bluetooth connection LED(Y LED ) Mute microphone... -
Page 7: Keypad Function
3.2 Keypad Function Answer/End call Press the Answer/End call button Speaker volume Press the Volume up button Speaker volume Press the Volume down button Connect with new Press the Bluetooth button to connect with a new Bluetooth Bluetooth device device Reconnect/disconnect Press the Bluetooth button to reconnect/disconnect with with Bluetooth device... -
Page 8: Led Indicator
3.3 LED Indicator Green:Battery fully charged Red:Battery charging All LED blinking: Battery low level Blue: Buletooth connection Blinking blue : Bluetooth pairing... -
Page 9: How To Use Sv13B
4. HOW TO USE SV13B 4.1 Charging for Preparation SV13B is built in a rechargeable battery, use the supplied USB cable and the power adapter transmit power and start charging. Power can be transmitted by connecting the product to either a computer or a commercial 5V USB power adapter. -
Page 10: Turning The Power On And Off
4.2 Turning the Power On and Off Press and hold the power button " " for three seconds or more to turn the power on. Press and hold again for three seconds or more to turn off the power. In addition, when the USB port of the host is connected to the computer or external audio and video terminals, the host will turn on automatically. -
Page 11: Connecting A Smartphone Via Bluetooth
4.3 Connecting a Smartphone via Bluetooth This product can be paired/connected via Bluetooth with a smartphone running iOS or Android. After connecting, check whether or not the audio is output correctly. 4.3.1 Pairing Pairing needs to be performed when connecting a smartphone by Bluetooth for the first time and when pairing information has been deleted. -
Page 12: Connecting
Press the Bluetooth button on this product. After the pairing is successful, the connection LED is bright. Enable Bluetooth on your mobile device, and select the“EACOME SV13" from the list of available Bluetooth devices. b. Perform the Bluetooth connection operation in the smartphone. -
Page 13: Disconnecting
Note: Right-click the speaker icon at the bottom right of the PC screen and click“Sound”. The “Sound” screen is displayed. Click the “Playback” and “Recording” tabs and check that “EACOME SV13” is set as the default device. If it is not set as the default device, click “EACOME SV13” and click “Set Default”. -
Page 14: In/Out Connection
If the device connection port is a 3.5mm 3-strand port, you need a transfer adapter for connecting.Insert audio transfer plug into the "I/O"port of SV13B. ” port of Audio Transfer plug to the Connect the microphone”... -
Page 15: Multi-Party Conference Call & Line Mode Selection
4.6 Multi-party Conference Call & Line Mode Selection SV13B allows you to hold conference calls via analog LINE IN/OUT(or mobile phone) , USB VOIP and Bluetooth simultaneously. All above network will be mixed automatically.You can add another line or switch between connected lines during a call freely. -
Page 16: Daisy Chain Function
4.7 Daisy Chain Function SV13B has daisy chain function. For meeting rooms larger than 30m , you can use the daisy chain function and link two SV13B, the microphone gather coverage can extend up to 8m, and the sound quality will be the same good. -
Page 17: Other Functions
5. OTHER FUNCTIONS 5.1 Checking the Speaker Volume Level The volume is 16 levels, the first level is the speaker mute, the 16th level is the maximum. The brightness of status LED will increase or decrease with the speaker volume up or down. 5.2 Checking the Battery Level You can check the level of the built-in rechargeable battery power. -
Page 18: How To Care For Your Eacome Speakerphone Sv13B
6. HOW TO CARE FOR YOUR EACOME SPEAKERPHONE SV13B Always store the EACOME speakerphone SV13B with the power off and safely protected. Avoid storage at extreme temperatures (above 70°C/158°F or below -20°C/-4°F). This can shorten battery life and may affect operation. High temperatures may also degrade performance. - Page 19 Address:Floor 15th,Baoneng Technology Building,Qingxiang Road,Longhua District,Shenzhen,China Tel:+86-75586223352 ext 838 Mob:+86-13922832151 Email:Tylerzhou@eacome.cn Web:www.eacome.com...
