- Page 1 Speakerphone User Manual SV12U...
- Page 3 Internet collaborative office,improve the efficiency of meeting and working. SV12U is a economical conference system audio configuration. SV12U products are exquisite and small, equip the special carry soft bag,it is so easy to carry that suitable for private travel too.
- Page 4 CONTENTS 1.Parts List 2.Speakerphone Overview 3.Keypad Func on and LED display descrip on 4.Turning the Power On and Off 5.Connec on Steps for USB 6.Connec ng a headset/headphones 7.Applica ons 8.Advantages 9.Specifica on...
- Page 5 1.Parts List USB Cable User Manual SV12U phone...
- Page 6 2.Speakerphone Overview Headset Power On/Off Power status indicator Mute microphone Volume up Volume down Status indicator (ring LED)
- Page 7 3.Keypad Function and LED display description Volume bu on Volume up/down Turn on/off the microphone mute,press the mute microphone button and the status indicator(ring LED) Mute microphone button light is red, press again will turn on the microphone and the status indicator(ring LED) light back to green Power On/Off Long press(3 secs) to turn on/off the power Connects to the headset/audio devices...
- Page 8 Connect to the power,the green light will always on when the host is working,and extinguish when turn off the power Status indicator (ring LED) : the green light is always on when working normally, and turn red when microphone mute...
- Page 9 4. Turning the Power On and Off Connect to the power, press and hold the power button " "for 3 seconds to turn the power on.Press and hold again for 3 seconds to turn off the power. Headset Power On/Off Power status indicator...
- Page 10 Note: Right-click the microphone icon at the bottom right of the PC screen and click "sound" to display the "sound" screen. Click the “Playback” and “Recording” tabs and check that "EACOME SV12" is set as the default device. If it is not set as the default device, click "EACOME SV12" and click “Set Default ".
- Page 11 6. Connecting a headset/headphones You can communicate using a headset/headphones by connecting a commercial headset/headphones equipped with a 3.5mm audio cable to the “ ” port on this product.
- Page 12 7.Applications The video conference so ware Support wireless, can connect with any conference camera,easy to realize wireless voice call Support USB communica on, support video conference terminal, mul media communica on terminal Support video conference so ware, various network conference so ware, UC unified communica on Support Zoom, Huawei Cloud, Suirui, Haostong, Webex, Aver, Bizconf, Skype Support speaker signal output through 3.5mm interface, connect to external mixer and...
- Page 13 8.Advantages Provide full-duplex hands-free phone calls for terminal device Connect to SV12U via the USB channel of the terminal device: Video conferencing Internet audio VoIP audio calls Advanced HD-Voice audio processing technologies deliver remarkably rich,full audio for natural, effortless conversations: True full duplex performance allows user to listen and speak at the same time without audio cutting in and out .
- Page 14 8.Specification DSP processing technology Echo Cancella on Noise Suppression Automa c gain control Audio parameters Microphone frequency response: 100Hz-7KHz Speaker frequency response: 100Hz-22KHz Microphone sound-pickup coverage: 3 meters, 360 degree range Speaker Volume: up to 80dB System Requirements Win 2000, XP, Vista, Win 10, Linux, Apple IOS, Android OS Interface USB port *1 Headset 3.5mm port*1...
- Page 15 Usage environment and specifica ons Reverbera on Time: < 0.2 Noise Degree: < -48 dBA Power Requirement: USB standard,5V---500mA Opera ng Temperature: 4°C-50°C (opera ng state) Storage Temperature: -10°C-50°C Humidity: 20%-85% Safety specifica ons: CE Mark (LVD & EMC direc ve); RoHS...
- Page 16 SV12U Product Warranty Registration Card Item No.: Date of purchase: User Name: Tell: Fax : Address: E-mail: Zip Code: Dealer name : Dealer phone :...
