- Page 1 INSTALLATION MANUAL LED TV* * LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. LN34* UN34* www.lg.com *MFL71970601* Copyright © 2022 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
- Volume Media Share - Key Management - SmartShare - Limited Mode - Screen Share - DTV Channel Update - LG Presenter - Power On Default - Media Renderer - Aux Source Setting - DIAL - Power Management - Device Name... - Page 3 IR Codes External control device Setup RS-232C Setup Phone jack Type Type of Connector : D-Sub 9-Pin Male RS-232C Configurations Communication Parameters IR OUT Using Guide - Suitable / Not Recommend remote-controller data format - IR Receiver specifications Command Reference List Transmission / Receiving Protocol...
-
Page 4: Location And Function Of Controls
Location and Function of Controls Parts and Button Basic functions Power On (Press) Power Off (Press and Hold) Menu Control (Press Menu Selection (Press and Hold All running apps will close. You can access and adjust the menu by pressing the button when TV is on. You can use the function when you access menu control. -
Page 5: First Use Wizard
First Use Wizard * Image shown may differ from your TV. (Depending on model) • There are four options - Basic Settings, Data Cloning, Solution Settings, and Installation Menu Settings. Each menu can access by START button. (Normal Configuration is the default focus item.) -
Page 6: Basic Settings
Basic Settings * Image shown may differ from your TV. This menu is for Basic Settings related to language, network, portal, voice service coverage and channel tuning without SI (Pro:Centric) setting. There are four steps for it. Language & Location (Depending on model) •... -
Page 7: Network Settings
Network Settings (Depending on model) • Set Network connection. You can connect easily to wired/wireless network. (”Network” on page 28) Wireless (Auto Wi-Fi) : Connect a default hidden SSID/PW. (SSID : lgwebostv, PW : procentric, Security : WPA/WPA2 PSK) -
Page 8: Portal Settings
Portal Settings (Depending on model) • Set the Portal Mode and Portal Auto Start. Portal Mode (Depending on model) • You can select ‘Default Portal’ (Use webOS default portal), ‘Customizable Portal’ (Use editable Portal), or ‘None’ (Do not use portal). Portal Auto Start •... -
Page 9: Voice Service Coverage
Voice Service Coverage (Depending on model) • Set the voice service coverage. You can set LG Service Country and Service Area Postcode for voice service. -
Page 10: Data Cloning
Data Cloning (Depending on model) Access Data cloning menu of TV Manager application for applying cloning file. Solution Settings (Depending on model) The Pro:Centric Platform enables you to simply install, manage and use guest-centric solutions. The default Domain “procentric.local” and IP Server Address are needed to be registered in DNS TV will contact the IP Server using the default Domain “procentric.local”... -
Page 11: Tv Configuration Options
TV Configuration Options (Depending on model) From the TV Configuration Options screen, you can choose how to proceed with the configuration of this TV. Whether you will configure the TV for Pro:Centric operation via the wizard or use a USB memory device to configure the TV, you may first wish to set the Room Number on the TV. Also, you can configure the network environment. - Page 12 • If you intend to apply the files via USB, use USB Configuration option to access TV Manager app. (“TV Manager” on page 52) • If you intend to set network, use the Network Settings option. You can connect easily to wired/wireless network by this option. (”Network” on page 28) Wireless (Auto Wi-Fi) : Connect a default hidden SSID/PW.
-
Page 14: Configure Pro:centric Server
Configure Pro:Centric Server (Depending on model) You can select two options. • Standard Pro:Centric Server Settings : Default Automatic / Manual Pro:Centric Server Configuration • Installation Code Settings : Installation Code based simple installation for Cloud solution... -
Page 15: Standard Pro:centric Server Settings
Standard Pro:Centric Server Settings (Depending on model) Automatically for Setup This step automatically searches for the Pro:Centric Server. If was found the Pro:Centric data programme, select the Next. - Page 16 Downloading the Pro:Centric application files takes few minutes. After the installation is completed, the following screen will be displayed.
-
Page 17: Manually For Setup
Manually for Setup Please select the Manual Pro:Centric. Configure the appropriate Pro:Centric settings in the TV. (Taiwan does not support RF) - Page 19 Downloading the Pro:Centric application files takes few minutes. After the installation is completed, the following screen will be displayed.
-
Page 20: Installation Code Settings
From the Installation Code Settings screen, You can input the installation code that issued from Cloud Portal. Server Searching LG Pro:Centric Cloud • Server search succeed : The message “Server Found [property name]” is displayed. And the search button changes to the next button. - Page 21 LG QI Server • Server search succeed : The message “Server Found” is displayed. And the search button changes to the next button. • In case of error : The message “Server Not Found” is displayed.
-
Page 22: Installation Menu Settings
Download Pro:Centric App • After clicking the next button, Downloading the Pro:Centric application files takes few minutes. Download Complete • After the installation is completed, the following screen will be displayed. Installation Menu Settings (Depending on model) Access Installation menu for commercial feature settings. -
Page 23: Installation Menu
The abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’ . The wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators. -
Page 24: Public Display Settings
Public Display Settings - When Public Display Settings is set to On, all functions of Public Display Settings apply. Power On Status • Decide to select working status of TV Set when turn on main power. • You can select PWR, STD, LST. •... -
Page 25: Volume
- Manage key usability of Local(Front) Key and Remote Control. IR Operation • Decide whether work the LG remote control or not. - When set to ‘Normal’ , all remote keys are available. - ‘Use PWR Only’ makes block all remote keys except power key. -
Page 26: Limited Mode
Limited Mode • Configure TV function’s limitation. When selected to ‘On’ , following sub-menus will be worked by below. Setup Menu • Permit to tune and manage Channels. Channel Change • Decide to change channel or not. Menu Display • Function to decide whether work with menu of control key or not. - Although select Off, the action that press a Menu button for 5 seconds to enter ‘Installation Menu’... -
Page 27: Dtv Channel Update
DTV Channel Update • It is a mode to set whether to update DTV Channel automatically or not. • When set to ‘Auto’ , update Channel map according to DTV Channel’s stream information. • When set to ‘Manual’ , keep Channel map even though DTV Channel’s information is changed. Power On Default •... -
Page 28: Network
Network (Depending on model) MAC Address • Displays the MAC address (not customizable). Network Setting One-click network connection • Connects easily to a network. • This menu supports to connect to an available network. -
Page 29: Ip Stream Control
IP Stream Control (Depending on model) Audio PTS Offset • Controlling output stream timing of audio. Video PTS Offset • Controlling output stream timing of video. IGMP • You can set IGMP version. (2 or 3) Wake On LAN • Sets the Wake On LAN function. - The Wake On LAN feature enables the TV to receive software updates and/or be powered ON upon receipt of Magic Packet data via the wired LAN. -
Page 30: Pro:centric
• If you input the 6-digit installation code when ‘Type’ is ‘LG Pro:Centric Cloud’ , the server is automatically searched. • If you input the 8-digit installation code when ‘Type’ is ‘LG QI Server’ , , the server is automatically searched. -
Page 31: Room Number Setting
Room Number Setting • You can set Label and Room Number using the Room Number Setting. Media Type (Depending on model) • Sets the media type to RF or IP. • The default value is RF. (Depending on model) • Data Channel - Sets the Channel at which the Pro:Centric data is received. -
Page 32: General
General Configuration Setup Select RCU • It is a mode to set whether to use Select RCU or not. When set to ‘Enable’ , You can adjust ‘Number of RCU’ menu. Number of RCU • Number of RCU value range 1~16. (When ‘Select RCU’ is set to ‘Enable’) •... -
Page 33: On Timer Operation
» Type of Connector: D-Sub 9-Pin Male Male connector on box, viewed towards connector. Signal Signal requirements RX RS232 Standard RS232 specification TX RS232 Standard RS232 specification IR from TV Power ground 6, 8 Not connected +5 V DC 10 %, max 100 mV ripple 1.5 A +12 V DC 10 %, max 100 mV ripple One Channel Map... -
Page 34: Auto Sensing
USB Auto Playback (Depending on model) • When set to ‘Movie’ , TV finds and plays the USB’s movie files located at the root(top) directory Movies if USB is plugged in. • When set to ‘Photo’ , TV finds and plays the USB’s photo files located at the root(top) directory Photos if USB is plugged in. •... -
Page 35: Insert Image
Insert Image (Depending on model) • Set to On or Off. • It is a mode to decide whether to display background image when using Clock app, Bluetooth Sound Sync app, Audio Programme app, No Signal state and watching Radio programme. •... - Page 36 • You can configure the Sound Out to be set after power on. • You can select Off, TV Speaker, Optical, LG Sound Sync., HDMI ARC • If you set this option to Off, the TV maintains Sound Out after power on.
-
Page 37: External Speaker
External Speaker (Depending on model) Volume Control • Selects the volume control method of an external speaker. • You can select ‘Off’ , ‘Int Variable’ , ‘Fixed’ or ‘Ext Variable’ . (Depending on model) • Ext Variable uses the External Vol Up/Down Control Line to change the volume up to 2 Watts. •... -
Page 38: Set Id Setup
Set ID Setup Set ID Lock • Set the ‘Set ID’ item in the user menu whether to activate or not. • Set to On (Work) or Off (Do Not Work). Set ID • Set the ‘Set ID’ of TV Set with 1~99. •... -
Page 39: Hcec Setup
• You will have 2 modes to choose [Default], [HCEC]. • If [Default] is selected, you can use SIMPLINK which is provided in LG TV. Also you can enable and disable SIMPLINK through SIMPLINK MENU. • If [HCEC] is selected, you can use TVLink-HCEC Protocol. (For more detailed information, please refer to TVLink-HCEC Protocol document) IR Decoding •... -
Page 40: Clock Setup
Clock Setup (Depending on model) Mood Display Setup (Depending on model) • You can setup Mood Display features. Clock Display (Depending on model) • You can select ‘Enable’ or ‘Disable’ . • After selecting ‘Enable’ , you can see the LED Clock TV. Dimming Standby (Depending on model) •... -
Page 41: Welcome Video Mode
Welcome Video Mode (Depending on model) • You can set to Off, Once or Repeat. Operation • The video displays after your TV is turned on and the boot logo appears. • If Welcome Video is enabled and a video is downloaded on the TV, the video plays. •... -
Page 42: Developer Mode
• The connection status with is displayed. (Disconnected, Connecting, Connected) • CONNECT: If you press the button once, a set tries to connect to the server and the button phrase is changed into DISCONNECT. To disconnect, pressing the button again is needed. Developer Mode (Depending on model) •... -
Page 43: Portal Settings
Portal Settings (Depending on model) Portal Mode (Depending on model) • You can select ‘Default Portal’ (Use webOS default portal), ‘Customizable Portal’ (Use editable Portal), or ‘None’ (Do not use portal). Auto Start (Depending on model) • You can select ‘Off’ , ‘Website Shortcut’ , or ‘Portal Mode’ . •... -
Page 44: Website Shortcut
Website Shortcut (Depending on model) Shortcut • Sets Enable or Disable. When it is set to Enable, Website Shortcut app is displayed at launcher bar. Shortcut Name • You can set Website Shortcut app name (title). Shortcut URL • Sets URL to connect when excute Website Shortcut app. Shortcut Icon •... -
Page 45: Hotel Directory
Hotel Directory (Depending on model) • Set the information to display at Hotel Directory app. Facility or Service Name • Set the facility or service name. Details or Extension • Set the detailed information. Related Photo • You can select None, downloaded images or Download (Go to TV Manager). •... - Page 46 • Edit Template - Vertical » You can set Vertical when selecting focus. Select between Hotel or Hospital. - Template » You can set Template when selecting focus. Select between Bar Type or Tile Type. - Video » You can set this mode to On/Off when selecting Customizable Portal. »...
-
Page 47: Device Discovery
Device Discovery (Depending on model) A function that enables sets connected to one network to search to each other. Portal Manager (Depending on model) This feature enables you to group together multiple monitor sets on a single network into the same group and copy portal setting data on a group basis. -
Page 48: Group Management
» Hotel : you must do one of the things listed below. i. Enable SmartShare(dlna) reboot ii. Enable DIAL reboot iii. Enable Media Renderer(DMR) reboot iv. Enable LG connect reboot • It may not work properly in wireless network environments. It is recommended you use a wired network. -
Page 49: Media Share
LG Presenter (Depending on model) • LG Presenter uses wired/wireless connection to share PC screen(Windows or Mac OS). If this value is enabled, LG Presenter app is displayed at launcher bar and TV can display the screen of PC or laptop. -
Page 50: Softap
SoftAP (Depending on model) • SoftAP is similar to Access Point. When this value is On, Wi-Fi Service application is displayed at the launcher bar. SoftAP is activated when user selects On in the Wi-Fi Service application. • Regardless of the Instant On mode, the SoftAP setting stays unchanged after power off/on. (Depending on model) Use Default •... -
Page 51: Beacon
Beacon (Depending on model) • This option enables BLE Beacon, one of Bluetooth 4.0’s features. • Beacon Mode (On/Off Toggle): enables the Beacon feature. • The iBeacon/Eddystone Type Beacon features are supported. iBeacon • Beacon UUID (hex): Set the UUID. - Field1: 4byte hex value (8 digits) - Field2: 2byte hex value (4 digits) - Field3: 2byte hex value (4 digits) -
Page 52: Tv Manager
TV Manager * Images shown may differ from your TV. You can update files from a USB memory device to TV through the TV manager. Diagnostics (Depending on model) • Sets Enable or Disable. When it is set to Disable, user can’t control TV via RMS. The changed setting is applied after reboot. - Page 53 Ez Download • Ez Download is a function that enables users to download the desired items all at once, such as EPK (software update file), TLL, Media files, Micom, Pro:Idiom M Key. (Depending on model) - Media files, Pro:Idiom M Key files, and Software Update files must be stored in a folder named “LG_DTV” in the root directory of the USB memory device.
- Page 54 • Press button to display storage usage information. • Press the “Clear Storage” button to delete the downloaded media files.
-
Page 55: Image Download
Image Download (Depending on model) • The download sequence is Image Download Select Image(s) Download. • The image files must be stored in a folder named “LG_DTV” in the root directory of the USB memory device. • Press the “Clear Storage” button to delete the downloaded images. - Boot Logo Image (Depending on model) »... - Page 56 Icon Download (Depending on model) • If you updates the images, original images will be removed. • The download sequence is Icon Downalod Select Images Download. • Icon update function supports only JPG, JPEG, PNG format file. • Press the Clear Storage button to delete the downloaded icons. - Hotel Icon on Portal, Website Shortcut, Input Shortcut »...
-
Page 57: Video Download
Video Download (Depending on model) • The video files must be stored in a folder named “LG_DTV” in the root directory of the USB memory device. • The download sequence is Video Download Select video file Download. • Video files can only download one file each. •... -
Page 58: Data Cloning
Data Cloning Import Clone File • Once the internal TV data and its programme map information are written to the USB memory device, the user can perform “Import Clone File” with a clone (.tll) file located in the root directory of the USB memory device. The user should not turn TV off nor unplug the USB device while processing. - Page 59 Export Clone File • “Export Clone File” creates a clone (.tll) file in the root directory of the USB memory device. The user must not turn TV off nor unplug the USB device while processing.
-
Page 60: Usb Download Menu
USB Download Menu USB Cloning An Installation can quickly set up and clone multiple TV sets at a property. These cloned TVs will all have the same Master TV Setup: Installation Menu settings, User A/V settings and the programme Map. This newer procedure significantly decreases the installation time that would be necessary if the standard RS-232C method were used instead. -
Page 61: Software Update
Software Update Update TV Software • This feature updates the TV software using the EPK file contained in a folder named “LG_DTV” in the root directory of the USB memory device. • The download sequence is Software Update Update TV Software Select file(EPK) Update. -
Page 62: Ir Codes
IR Codes • This feature is not available for all models. ► A Type Code (Hexa) Function Code (Hexa) Function (POWER) (BACK) Number Key 0-9 10-19 Alphabet buttons (Space) - Page 63 ► B Type Code Function Code (Hexa) Function (Hexa) (Dash) / (Blue) (Power) (Yellow) (Green) (Mute) (Input) (Red) (Home) 10 - 19 Number Key 0 - 9 (Settings)
- Page 64 ► C Type Code Code Function Function (Hexa) (Hexa) (Green) (Red) (Yellow) (Blue) (Power) 10 - 19 Number Key 0 - 9, (Space) (Back) (Dash)
-
Page 65: External Control Device Setup
External control Phone jack Type device Setup (TV) (PC) (Depending on model) • You need to purchase the phone-jack to RS-232C cable required for RS-232C IN (CONTROL & SERVICE) the connection between the PC and the TV, which is specified in the ENTRÉE RS-232C (PC) (TV) -
Page 66: Rs-232C Configurations
IR output signals will be suppressed automatically by IR receiver. • In this case, LG does not guarantee IR working function. • Baud rate: 9,600 bps (UART) • To make sure of this matter, here are two methods as •... -
Page 67: Command Reference List
Command Reference List (Depending on model) Data Command1 Command2 (Hexadecimal) 01. Power 00 to 01 02. Aspect Ratio (See p. 68) 03. Screen Mute (See p. 69) 04. Volume Mute 00 to 01 05. Volume Control 00 to 64 06. Contrast 00 to 64 07. -
Page 68: Transmission / Receiving Protocol
Transmission / Receiving 1 Power (Command: k a) ►To control Power On/Off of the set. Protocol Transmission [k][a][ ][Set ID][ ][Data][Cr] (Depending on Model) Data 00 : Off Data 01 : On Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [a][ ][Set ID][ ][OK/NG][Data][x] [Command1] : First command to control the TV. - Page 69 3 Screen Mute (Command: k d) 6 Contrast (Command: k g) ►To select screen mute on/off. ►To adjust screen contrast. You can also adjust contrast in the picture settings. Transmission [k][d][ ][Set ID][ ][Data][Cr] Transmission [k][g][ ][Set ID][ ][Data][Cr] Data 00 : Screen mute off (Picture on) / Video mute off Data 01 : Screen mute on (Picture off) Data Min : 00 to Max : 64 Data 10 : Video mute on...
- Page 70 10 Sharpness (Command: k k) 13 Balance (Command: k t) ►To adjust the screen sharpness. ►To adjust balance. You can also adjust sharpness in the picture settings. You can also adjust balance in the audio settings. Transmission Transmission [k][k][ ][Set ID][ ][Data][Cr] [k][t][ ][Set ID][ ][Data][Cr] Data Min : 00 to Max : 32 Data L : 00 to R : 64...
- Page 71 15 Energy Saving (Command: j q) 17 Equalizer (Command : j v) ►To reduce the power consumption of the TV. You can also adjust ►To adjust equalizer. Energy Saving in picture settings. Transmission Transmission [j][v][ ][Set ID][ ][Data][Cr] [j][q][ ][Set ID][ ][Data][Cr] Power Saving Level Function...
- Page 72 19 Program Skip/Add (Command: m b) 22 Input select (Command: x b) (Main Picture Input) ►To set skip status for the current Channel. ►To select input source for main picture. Transmission Transmission [m][b][ ][Set ID][ ][Data][Cr] [x][b][ ][Set ID][ ][Data][Cr] Data 00 : Skip Data Structure Data 01 : Add...
- Page 73 23 Channel(Programme) Block/Unblock (Command :m d) 24 Fail Over Mode (Command: m i) ►This command may work differently depending on model and ►Selects the Fail Over mode. signal. Transmission [m][i][ ][Set ID][ ][Data][Cr] ►For South Korea, North/Latin America except Colombia Model Data 00: Off Transmission Data 01: Auto...
- Page 74 26 Internal storage media contents play (Command: s n, a8) ►Plays media stored in the internal memory. ►This command may work differently depending on model and signal. Transmission [s][n][ ][Set ID][ ][a][8][ ][Data][Cr] Data 01 : media contents play Acknowledgement [n][ ][Set ID][ ][OK/NG][a][8][ ][Data][x] * Real data mapping 00 :...
