- Page 1 GUIDELINE WATER PROBE REPLACEMENT MODELS : TK500 – TK1000 – TK 2000 www.tecoonline.com www.tecous.com...
- Page 2 EQUIPMEMT 5 black clamps Screw-drivers Tongs Water Probe (spare part) Allen wrench (7) www.tecoonline.com www.tecous.com...
- Page 3 STEP n. WARNING! Parts replacement and reparation may be carried out only by qualified persons. If this are not performed properly, they can cause electric shock, burns and fires Disconnect the chiller from power supply. Never touch internal part or dismount chiller when it is connected to power supply to avoid potential electric shock.
- Page 4 STEP n. Remove the air filter grid and air filter from their position. www.tecoonline.com www.tecous.com...
- Page 5 STEP n. Using the screw-driver, remove the 4 INOX screws indicated in the picture here below. www.tecoonline.com www.tecous.com...
- Page 6 STEP n. Remove the red fan support lifting it up from the bottom edge. Leave it on the metal cover, as you can see in the picture. www.tecoonline.com www.tecous.com...
- Page 7 STEP n. Disconnect the compressor connector, heater connector and probes connector. Probe Compressor Heater connector connector connector www.tecoonline.com www.tecous.com...
- Page 8 STEP n. Cut the black clamps inside the chiller that embrace the probe’s wire. Then with the small screw driver, disconnect the green connector from the water probe’s wire. Pay attention to not confuse water probe with overheating probe. Water probe wire comes from the bottom of exchanger. Overheating probe comes from drier filter.
- Page 9 STEP n. Remove the rubber cup positioned in the chiller’s bottom side. Now you are able to see the probe’s position and it’s insulation. www.tecoonline.com www.tecous.com...
- Page 10 STEP n. Remove the probe’s insulation. Then remove the probe from its position, pulling it off from the wire. www.tecoonline.com www.tecous.com...
- Page 11 STEP n. Take the probe and remove it from the exchanger’s bottom part, following the small passage where the probe’s wire pass. Then, from the chiller’s top part, take out the probe. www.tecoonline.com www.tecous.com...
- Page 12 STEP n. Take the new probe and put the probe’s final part (two wires) in the exchanger’s small passage. Go in the chiller’s bottom part and take out the probe’s wire. www.tecoonline.com www.tecous.com...
- Page 13 STEP n. Insert the new probe inside the Take the probe’s insulation and exchanger. put it on the probe’s hole. ATTENTION: the probe has to ATTENTION: there must not be touch the pipe’s end part. any air leakage !! Insert the black tap in its place. www.tecoonline.com www.tecous.com...
- Page 14 STEP n. Connect the probe’s wire to the green connector using the screw-driver. Then re-connect it to the thermostat. Take a new black plastic clamp and pinch the probe’s cable around the exchanger’s pipe insulation, as showed in the picture. www.tecoonline.com www.tecous.com...
- Page 15 STEP n. Take the fan support Assembly. Reconnect all connectors and fix it at the chiller’s body. Attention: the front panel side must be insert in the aluminum profiles! Rebuild the top part of the chiller following the indicated sequence: 4 INOX screw (fix the fan support on the metal cover) Conveyor...
