TABLE OF CONTENTS

1 Warning ----------------------------------------------------------------------------------------
2 Specifications -----------------------------------------------
3 Troubleshooting Guide ----------------------------------
4.1. Disassembly instruction----------------------------
4.2 Assembly Instructions------------------------------
5 Wiring Connection Diagram-----------------------------
6 Schematic Diagram ---------------------------------------
Model No.
Oceania
PAGE
2
2
7.1. Exploded View for EH-NA98 -----------------------------
3
7.2. Parts List for EH-NA98 ------------------------------------
5
7
13
14
© Panasonic Corporation 2016 Unauthorized copying
and distribution is a violation of law.
Order Number PEWT2209A80CE
(Household) Hair Dryer
EH-NA9J
PAGE
15
15
16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the nanoe Oceania EH-NA9J and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic nanoe Oceania EH-NA9J

Summary of Contents for Panasonic nanoe Oceania EH-NA9J

  • Page 1: Table Of Contents

    7.2. Parts List for EH-NA98 ------------------------------------ 4 Disassembly and Assembly Instructions --------- 5 4.1. Disassembly instruction---------------------------- 4.2 Assembly Instructions------------------------------ 5 Wiring Connection Diagram----------------------------- 6 Schematic Diagram --------------------------------------- © Panasonic Corporation 2016 Unauthorized copying and distribution is a violation of law.

  • Page 2: Warning

    1. Warning Caution: - Pb free solder has a higher melting point that standard solder; Typicall the melting point is 50 - 70°F (30 - 40℃) higher. Please use a oldering iron with temperature control and adjust it to 750 ±20°F (400 ± 10 ℃). In case of using high temperature soldering iron, please becareful not to heat too long.

  • Page 3: Troubleshooting Guide

    3 TROUBLESHOOTING GUIDE Refer to WIRING CONNECTION DIAGRAM. < TROUBLE > < CHECK > < REMEDY > <CHECK POWER CORD> Replace the It does not work even Check the conductivity of POWER CORD MOTOR HEATER if the power switch is ASSEMBLY turned to "I"...
  • Page 4 < TROUBLE > < REMEDY < CHECK > <CHECK THE THERMAL DISPLAY MODULE.> Air temperature Replace the The LED display is not changed even if the cannot be adjusted. Mi-COM SWITCH MODE SWITCH is pushed. CIRCUIT ASSEMBLY Or air temperatures are not changed even if the display is changed.

  • Page 5: Disassembly And Assembly Instructions

    4 Disassembly and Assembly instructions 4.1 Disassembling instruction (1) Remove two TORX SCREWS by torx screwdriver. (5) Remove the AIR INLET by a slotted (2) Disassemble the HANDLE. screwdriver etc.as the figure. Torx screws Air inlet (3) Remove two SCREWS at side of AIR INLET and OUTLET.
  • Page 6 4 Disassembly and Assembly instructions 4.1 Disassembling instruction (7) Draw out the AIR OUTLET by hand. Air outlet Air outlet 4 hooks (8) Remove the hooks and disassemble the HOUSING. (9) Remove the Mi-COM SWITCH CIRCUIT ASSEMBLY from two hooks and lift it to remove. Hooks...

  • Page 7: Assembly Instructions

    4.2 Assembly instruction (1) Install the MAIN SWITHC BUTTON, LED lens, and LED PANEL inside of the HOUSING A. LED Lens Screw Switch button (2) Assemble the AIR OUTLET GRILL as the figure. Air Outlet Grill Air Outlet Grill Nozzle B Nozzle B (3) Assemble the Mi-COM SWITCH CIRCUIT ASSEMBLY and switch board with MOTOR HEATER ASSEMBLY.
  • Page 8 4.2 Assembly instruction (4) Assemble AIR OUTLET GRILL, NOZZLE B and the MOTOR HEATER ASSEMBLY to the groove of the HOUSING A. Groove Groove Groove Groove (5) Assemble HOUSING A, B and AIR OUTLET RING. - Install AIR OUTLET RING with its four brims inside. Air Outlet Brims Fit the ledges of...
  • Page 9 4.2 Assembly instruction (7) Install the CLICK RING so that to long concaves are on the HANDLE side. Handle side Long concave (8) Allocating the lead wire at the HANDLE. Install the MAIN SWITCH so that the side of two terminals is upward.
  • Page 10 Point of assembling the parts and allocating the wires. Assemble the air outlet ring and the air outlet grill inside the ribs of the main body case firmly. Control point for assembly Power Cord Insulation of power cord must be over limit line only as shown in a picture.
  • Page 11 Point of allocation of the wire of the main body inside the handle. Insulation Tape 3 layers (For IEC Requirement) Housing A Wire Housing B Wire...
  • Page 12 Check if the nanoe and the mineral ions are generated at the discharge electrode before installing the main body case. * The following figures are just for reference. If the tip of dis charge electrode lights, it is normal. * Check the tip of the discharge electrode from the side diagonally. These light purple.

  • Page 13: Wiring Connection Diagram

    5 WIRING CONNECTION DIAGRAM...

  • Page 14: Schematic Diagram

    6. Schematic Diagram SW 1 Main Sw. OFF " O " SET " I " DRY " II " TURBO " III " Symbol Part name Specification CAPACITOR (FOR EMC) 0.68 µF, 275V 0.1 µF, 100VDC CAPACITOR (FOR DIODE BRIDGE) 400V, 2A DIODE 400V, 2A...

  • Page 15: Exploded View & Replacement Parts List

    7 EXPLODED VIEW & REPLACEMENT PARTS LIST 7.1. Exploded View for : EH-NA9J All parts are supplied from PMFTH-AP through PLAP...

  • Page 16: Parts List For Eh-Na98

    Model No. : EH-NA9J Parts List Ref.No. Part No. Parts Name & Descriptions Q'ty Remarks EHNA9JT3012W TORX SCREW 3.0*12 EHNA9JALMAW ALUMINIUM SEAL A EHNA9JHDNW HANDLE AB For -N765 : AU EHNA9JMHB76W MOTOR HEATER ASSEMBLY For -N765 : AU EHNA9JCRTW CLICK RING EHNA9JSRTW SWIVEL RING EHNA9JT2005W...
