TECH SPECS - SMC8708L2
PORTS
• SMC8708L2: 8 10G-BASE ports
• Built-in Network Management
NETWORK INTERFACE
• XFP Transceiver slots supporting SR, LR and ER XFP.
• Multimode fiber cable; 62.5/125 or 50/125 microns
• Singlemode fiber cable: 9/125 micron
SWITCHING FABRIC
• 160Gbps
• 120Mpps
BUFFER ARCHITECTURE
• 4 Mbytes
SWITCHING DATABASE
• 16K MAC address entries
LED
• System: Power, RPU , Diag,
• Port: Link/activity, XFP Module
TEMPERATURE
• Operating: 0 to 50 °C (32 to 122 °F)
• Storage: -40 to 70 °C (-40 to 158 °F)
HUMIDITY
• Operating: 5% to 95% (non-condensing)
WEIGHT
• 5.84kg
• 12.87lbs
DIMENSIONS
• 440 x 415 x 43 mm
• 17.3 x 16.3 x 1.8 in
AC INPUT
• 100 to 240 V, 50-60 Hz, 2A
POWER SUPPLY
• Internal, auto-ranging transformer: 100 to 240 VAC, 50 to 60 Hz
• External, supports connection for redundant power supply
POWER CONSUMPTION
• 150 Watts maximum
MAXIMUM CURRENT
• 2.00 A @ 100 VAC
• 1.00 A @ 240 VAC
MTBF
• 47271 hours at 50 celcius
o
SWITCH FEATURES
• Spanning Tree Protocol (802.1D, .1w, .1s)
• Forwarding Mode
• Store-and-forward
• VLAN Support
• Up to 255 groups; port-based or with 802.1Q
• VLAN tagging, GVRP for automatic VLAN learning
• 802.1v (Protocol based Vlans)
• Quality of Service
• Supports four levels of priority with flexible classification
and prioritization
• MultiLink Trunking (LACP)
• Port Mirroring
• TACACS+ client authentication
• HTTPS and SSL
• SSH for Telnet sessions
• Rate limiting
• Static port security
• Jumbo Frame support
MANAGEMENT FEATURES
• In-Band Management
• Telnet, SLIP, Web-based HTTP, or SNMP manager
• Out-of-Band Management
• RS-232 DB-9 console port
• Software Loading
• TFTP in-band or Xmodem out-of-band
• MIB Support
• MIB II (RFC 1213), Bridging MIB (RFC 1493), Ethernet-Like
MIB (RFC 1643), RMON MIB (RFC 1757), SMC's private MIB
RMON SUPPORT
• Groups 1,2,3, 9 (Statistics, History, Alarm, Event)
STANDARDS
• IEEE802.3 Ethernet, IEEE802.3u Fast Ethernet,
• IEEE802.1D Spanning Tree Protocol and traffic priorities,
• IEEE802.1p Priority tags
• IEEE802.1Q VLAN
• IEEE802.1ac VLAN tagging
• IEEE802.1ad Link aggregation control protocol
• IEEE802.1w Rapid Spanning Tree
WARRANTY
• Please check www.smc.com for the
warranty terms in your country/region
SLIDE-IN TRANCEIVERS FOR 10G XFP PORS
SMC10GXFP-SR
• 10G SR XFP Transceiver, 300m, Multimode fiber
SMC10GXFP-LR
• 10G LR XFP Transceiver, 10km, Single mode fiber

REDUNDANT POWER SUPPLY

SMCRPU14
• 4 port redundant power supply unit
CONTACT
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local country contact information
