INSTRUCTION MANUAL
800W ELECTRIC
ASH VAC
MODEL NO: THAV80010L -- PRODUCT NO: 1938363001
EN - ORIGINAL INSTRUCTIONS
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
FOR YOUR SAFETY
Please read & understand this manual, paying attention to the safety instructions, before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, our policy
of continuous improvement determines the right to make modifications without prior warning.
Images used are for illustration purposes only.
14-08-2024 v1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for The Handy THAV80010L
Summary of Contents for The Handy THAV80010L
- Page 1 INSTRUCTION MANUAL 800W ELECTRIC ASH VAC MODEL NO: THAV80010L -- PRODUCT NO: 1938363001 EN - ORIGINAL INSTRUCTIONS ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS FOR YOUR SAFETY Please read & understand this manual, paying attention to the safety instructions, before use.
- Page 2 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
-
Page 3: Table Of Contents
CONTENTS SPECIFICATION IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS SET UP & PREPARATION FOR OPERATION ASSEMBLY OPERATION MAINTENANCE & STORAGE PARTS DIAGRAM & LIST DECLARATION OF CONFORMITY WARRANTY ASSEMBLY IS REQUIRED - MINIMUM TWO PERSONS • This product requires assembly before use. •... -
Page 4: Specification
Noise Pressure Level (L 86 dB(A) Consistent with our policy of continuous improvement, The Handy reserves the right to change the design and configuration of any of its products without notice or obligation. Therefore, please treat the text and images in this manual for illustrative purposes only. -
Page 5: Important Information
IMPORTANT INFORMATION INTENDED USAGE The basic version of the equipment is an ash vacuum cleaner for private use, i.e., for use in home and domestic gardening environments. It is designed for vacuuming cold ash or cold material residues from fireplaces, charcoal ovens, ashtrays or barbecues. -
Page 6: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. -
Page 7: Important Safety Warnings
IMPORTANT SAFETY WARNINGS TO REDUCE RISK OF INJURY: Before any use be sure everyone using this product reads and understands all safety instructions and other information contained in this manual. WARNING The warnings, cautions, and instructions outlined in this instruction manual cannot cover all possible conditions or situations that may occur. -
Page 8: Personal Safety
PERSONAL SAFETY 1. This machine is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the machine by a person responsible for their safety. 2. -
Page 9: Electrical Safety
ELECTRICAL SAFETY Always check that the power supply corresponds to the voltage on the rating plate. 1. Power tool electrical plugs must match the outlet. Never modify the plug in any way. Do not use adapter plugs with earthed power tools. Unmodified plugs and matching outlets will reduce the risk of a lethal electric shock. - Page 10 11. Check the hose, the ash filter and the extractor regularly when extracting, to assess levels of heating. 12. If the appliance heats up, switch it off, pull the mains plug out of the electrical source and remove the filter bag immediately. Separate the ash filter from the extractor and remove the extracted material. Next, let the extractor and the ash filter cool off outside, under supervision.
-
Page 11: Set Up & Preparation For Operation
SET UP & PREPARATION FOR OPERATION Components can be housed inside the ash vac. If you believe you are missing any components, please contact us. Familiarise yourself with the assembly components of this machine. 1. Handle 2. On/Off Switch 3. Tank Lid 4. -
Page 12: Assembly
ASSEMBLY FITTING THE TANK LID (FIG. 2) 1. The tank lid (3) is fastened to the tank (6) by the locking clasps (5). 2. To remove the tank lid (3), open the locking clasp (5) and remove the tank lid (3). When fitting the tank lid (3), make sure that the locking hook (5) locks into place correctly. -
Page 13: Filter Assembly
FILTER ASSEMBLY Never use the ash vacuum without the filter! Always ensure that the filters are perfectly secure. 1. Assemble the HEPA filter (10) to the tank lid (3), by applying sliding it onto the lid as per (Fig.6). 2. Slide the pre-filter (11) over the HEPA filter (10) 3. -
Page 14: Maintenance And Storage
ON/OFF SWITCH (Fig. 1) 1. Press the ON/OFF switch (2) to switch the equipment ON and OFF. VACUUMING (Fig. 3-4) 1. Connect the suction hose (9) to the suction hose connector (7) The ash vacuum cleaner is not suitable for the vacuuming of combustible materials! BLOWING (Fig. - Page 15 PARTS DIAGRAM – THAV80010L (1938363001) PARTS LIST – THAV80010L (1938363001) Item No. Part No. Handy Description TH268-1 Tank Lid with Handle TH268-2 1m Hose TH268-3 Vacuum Tube TH268-4 HEPA Filter TH268-5 Pre-Filter...
-
Page 16: Declaration Of Conformity
DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: 800W ELECTRIC ASH VAC Model(s): THAV80010L Product Number: 1938363001 Type/Serial No: As per rating label on machine. Motor Wattage: 800 Complies with the following directives: 2014/30/EU –... - Page 17 & 3 years of the warranty. The Handy (including Light Construction), Platinum (Petrol & Electric), a) 2 years from the original date of sale to the first domestic user. b) 90 days from the original date of sale to the professional/commercial user.
- Page 18 e) Engines are supplied with a separate warranty to the machine. The engine manufacturers warranty statement which will be supplied within the engine instruction manual. All enquiries and warranty repairs should be discussed with the engine manufacturer or approved warranty repair dealer. 90 days from the original date of purchase for Replacement Spare Parts (unless normal wear &...
- Page 20 For spares or support of your handy product, please contact us: Tel: 01793 333212 Email: cs@thehandy.co.uk Office Hours 8:00am - 5:00pm (CLOSED WEEKENDS & BANK HOLIDAYS) To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy, Murdock Road, Dorcan, Swindon, SN3 5HY...
