USER MANUAL
EN

technical data

model
Catalogue number
max. capacity
max. height
min. height
net weight (without case)
general safety conditions
The use of a vehicle jack has inherent dangers to avoid risk of personal injury or property damage make sure
you are fully aware of the operating instructions for this product, the recommendations in the vehicle owners
manual for jacking of your vehicle prior to lifting the vehicle. do not exceed maximum lifting capacity of this jack.
This jack is intended for automotive use only. be aware that large or heavy vehicles may exceed jack's stated
capacity check vehicle owners manual or contact the vehicle manufacturer. do not use for any other purpose
except the raising and lower of vehicles. never use to raise any structure or building, do not lift any human load
and never ride on jack.
Preparing work area
1. Thoroughly inspect jack for damage or wear before each use. Test operation of unloaded jack before using
to lift any load. if jack is damaged or malfunctioning do noT LifT AnY LoAd until the problem is corrected.
2. The vehicle manufacturer's owner's manual should be consulted prior to the lifting of the vehicle. it will
advise jacking procedure, vehicle weight and location of jack support areas on vehicle. The working load
limit of the jack is 2500 kg. neVeR eXCeed WoRking LoAd LimiT of jACk.
3. Clear children and others from work area before lifting vehicle. Another adult should be nearby for extra
safety and assistance but must be clear of vehicle as it is lifted. no person should remain in a vehicle that is
being lifted. no person should enter or lean into a vehicle which is supported by a jack or by support stands.
4. Clear obstructions from work area. Working in tight or cluttered work areas is dangerous.
5. be sure jack and vehicle are on solid, even surface. Uneven or sloped surfaces create hazardous working
conditions and dangerously impeded the function of the jack.
6. With vehicle in proper position, set vehicle's parking brake and lowest gear. Turn ignition off and lock
steering wheel. not lifted wheels should be chocked.
7. The load should be centrally located on the saddle. off centre loads can be unstable.
8. The jack should be used for lifting and lowering only; the raised vehicle should be supported on vehicle
support stands. Have support stands capable of supporting vehicle weight ready nearby for use.
Operation – lifting vehicle
Lifting Vehicle Lifting a vehicle using a jack can be dangerous. follow all instructions and precautions below. do
not lift any vehicle with its engine running or start any vehicle that is supported by jack or jack stands.
Approximately six complete pumping cycles should be carried out with the release valve (8) open before lifting
to distribute the hydraulic oil properly.
Hydraulic Jack LS-01 2,5T / WLS-01 2,5T  User manual
Hydraulic jack LS-01 2,5T / WLS-01 2,5T
23-03-65929 / 23-03-73126
2500 kg
365 mm
85 mm
11 kg
3
