hepco & becker 6807530 01 01 Mounting Instructions

Smartrack for ducati scrambler 800, ducati scrambler sixty 2

Advertisement

Quick Links

Smartrack
DUCATI Scrambler 800
(2015-2018)
Artikel Nr.: / Item-no.:
DUCATI Scrambler Sixty 2
(2016-)
Artikel Nr.: / Item-no.:
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
Abbildung ähnlich / Image similar
Kombinierbar mit C-Bow Softtaschenhalter.
combinable with C-Bow softbag holder
WICHTIG
IMPORTANT
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle
zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das
entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut
ist. Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined
action, you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the
screws should be tightened to the torque specified. This guarantees, that the product is mounted without tension.
Observe the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Weiteres Zubehör auf unserer Homepage. More accessories: see our homepage.
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
7530
680
01 01
7538
680
01 01
Tel.:
+49 (0)6331 - 1453 - 100
Fax:
+49 (0)6331 - 1453 - 120
eMail: vertrieb@hepco-becker.de
www.hepco-becker.de
schwarz/black
schwarz/black
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6807530 01 01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for hepco & becker 6807530 01 01

  • Page 1 Smartrack DUCATI Scrambler 800 (2015-2018) 7530 01 01 Artikel Nr.: / Item-no.: schwarz/black DUCATI Scrambler Sixty 2 (2016-) 7538 01 01 Artikel Nr.: / Item-no.: schwarz/black MONTAGEANLEITUNG MOUNTING INSTRUCTIONS Abbildung ähnlich / Image similar Kombinierbar mit C-Bow Softtaschenhalter. combinable with C-Bow softbag holder WICHTIG IMPORTANT Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung.
  • Page 2 Smartrack DUCATI Scrambler 800 (2015-2018) 7530 01 01 Artikel Nr.: / Item-no.: schwarz/black DUCATI Scrambler Sixty 2 (2016-) 7538 01 01 Artikel Nr.: / Item-no.: schwarz/black INHALT CONTENTS 700013600 Smartrack 700013600 Smartrack 700013601 Cover 700013601 Abdeckung 700013830 Mounting kit 700013830 Befestigungskit 700008999 tube adapter left...
  • Page 3 Smartrack DUCATI Scrambler 800 (2015-2018) 7530 01 01 Artikel Nr.: / Item-no.: schwarz/black DUCATI Scrambler Sixty 2 (2016-) 7538 01 01 Artikel Nr.: / Item-no.: schwarz/black MONTAGEANLEITUNG MOUNTING INSTRUCTIONS Halteadapter links & rechts / Holding adatper left & right: M8x16 Ø8,4 Den Heckkotflügel wieder montieren.
  • Page 4 Smartrack DUCATI Scrambler 800 (2015-2018) 7530 01 01 Artikel Nr.: / Item-no.: schwarz/black DUCATI Scrambler Sixty 2 (2016-) 7538 01 01 Artikel Nr.: / Item-no.: schwarz/black MONTAGEANLEITUNG MOUNTING INSTRUCTIONS Smartrack: M6x20 Ø6,4 Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren! Abgebaute Teile wieder montieren.

This manual is also suitable for:

6807538 01 01
