Super-mini terminal block signal conditioners

Advertisement

Quick Links

Super-mini Terminal Block Signal Conditioners M5X-UNIT
MULTI POWER TRANSDUCER
(self-powered, PC programmable)
Functions & Features
• Super-mini power transmitter
• 5 to 600 A clamp CT use for current sensor
• Single-phase/2-wire, single-phase/3-wire and 3-phase/3-
wire are available
• High-density mounting
• Power LED
• No auxiliary power source required
25
[.98]
97
[3.82]
41
[1.61]
mm [inch]
MODEL: M5XWT-113[1]
ORDERING INFORMATION
• Code number: M5XWT-113[1]
Specify a code from below for [1].
(e.g. M5XWT-113/Q)
• Specify the specification for option code /Q
(e.g. /C01/S01/SET)
CONFIGURATION
1: Single phase / 2-wire and 3-wire, 3-phase / 3-wire
INPUT
1: 240 V AC / CLSE
Clamp-on current sensor is selectable from below.
CLSE (5A, 50A, 100A, 200A, 400A, 600A)
5A is available as CT's secondary.
EXTERNAL INTERFACE
3: Modbus communication
[1] OPTIONS
blank: none
/Q: With options (specify the specification)
MG CO., LTD.
www.mgco.jp
SPECIFICATIONS OF OPTION: Q (multiple selections)
COATING (For the detail, refer to our web site.)
/C01: Silicone coating
/C02: Polyurethane coating
/C03: Rubber coating
TERMINAL SCREW MATERIAL
/S01: Stainless steel
EX-FACTORY SETTING
/SET: Preset according to the Ordering Information Sheet
(No. ESU-2782)
RELATED PRODUCTS
• PC Configurator cable (model: COP-US)
• PC configurator software (model: PMCFG)
Downloadable at our web site.
• Clamp-on current sensor (model: CLSE)
GENERAL SPECIFICATIONS
Construction: Terminal block
Connection: M3.5 screw terminals (torque 0.8 N·m)
Screw terminal: Nickel-plated steel (standard) or stainless
steel
Housing material: Flame-resistant resin (black)
Isolation: Current input or voltage input to Modbus
Measured variables
Voltage: R-S, S-T, T-R
Current: R, S, T
Active power
Reactive power
Apparent power
Power factor
Frequency
Active energy: Incoming / outgoing
Reactive energy: Incoming / outgoing / lag (inductive)
/lead (capacitive)
Apparent energy
Average active power (demand)
Average reactive power (demand)
Average apparent power (demand)
Average (demand) current: R, S, T
Max. and min. values
Simplified measurement mode: Calculates power from
current values with fixed voltage values and power factor.
Power indicator LED: Green LED; Blinking patterns indicate
different operating status of the transmitter.
MODBUS COMMUNICATION
Communication: Half-duplex, asynchronous, no procedure
Standard: Conforms to TIA/EIA-485-A
Transmission distance: 500 meters max.
Baud rate: 1200, 2400, 4800, 9600, 19200, 38400 bps
M5XWT SPECIFICATIONS
MODEL: M5XWT
ES-2782 Rev.3 Page 1/4

Advertisement

loading
Need help?

Need help?

Do you have a question about the M5XWT and is the answer not in the manual?

Questions and answers

Summary of Contents for MG M5XWT

  • Page 1 MODEL: M5XWT-113[1] Isolation: Current input or voltage input to Modbus Measured variables Voltage: R-S, S-T, T-R ORDERING INFORMATION Current: R, S, T • Code number: M5XWT-113[1] Active power Specify a code from below for [1]. Reactive power (e.g. M5XWT-113/Q) Apparent power •...
  • Page 2 MODEL: M5XWT (default: 38400 bps) current in a single-phase/3-wire circuit and phase-S current Protocol: Modbus RTU in an 3-phase/3-wire circuit. Node address: 1 to 247 (default: 1) Temp. coefficient: ±0.0075 %/°C (0.004 %/°F) Parity: None, even or odd (default: odd) Sampling time: ≤...
  • Page 3 MODEL: M5XWT EXTERNAL VIEW ■ SIDE VIEW ■ FRONT VIEW Power Indicator LED Terminator DIP SW for Modbus Configurator Jack TERMINAL CONNECTIONS System/ System/ Terminal Terminal Application Application P1 P2 P3 1K P1 P2 1K COM source load source load...
  • Page 4 MODEL: M5XWT EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm [inch] 7.3 [.29] 8–M3.5 SCREW DIN RAIL 35mm wide 25 [.98] 41 [1.61] (3.3 [.13]) • When mounting, no extra space is needed between units. SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM Terminator DIP SW for Modbus...
