Chromeboxand necessary cautions and tools before performing any service and repairs. o provide the best service and support for the CN60, we have provided the below information for technicians from distributors and resellers to perform the complete VivoPC disassembly and assembly.
Service Overview CN60 Overview The illustrations below show the Vivo PC’s overview from front view F R O N T V I E W Kensington Lock 2-in-1 Card Reader 2 x USB3.0 Audio Jack DisplayPort 2 x USB3.0 DC-in HDMI port...
Service Overview Service Overview Please pay special attention to the cautions below to prevent any damages to the VivoPC and also please be sure to select the appropriate tools described in this section to perform any services desired. Precautions P R E C A U T I O N S Before you perform any service and or repair on the VivoPC, please follow the steps below first.
Page 4
Service Overview Appropriate Tools T O O L S The illustrations below show the appropriate tools that should be used for the VivoPC’s service and repair. Phillips-head Screwdriver C R O S S H E A D Use a Phillips-head screwdriver to fasten/remove the K- or B-typed screws. S C R E W D R I V E R Tweezers...
Page 5
D I S A S S E M B L Y C A U T I O N ASUS hereby provides a basic instruction for the disassembly of ASUS products, i.e. to remove components and materials that require selective treatments, which are defined by Annex II of the European Union (EU) Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC.
Be sure to use proper tools described before. SUS Chromebox CN60 consists of various modules. This chapter describes the procedures for the complete Chromebox disassembly. In addition, in between procedures, the detailed disassembly procedure of individual modules will be provided for your service needs.
Page 7
Disassembly Procedure Cover and HDD C O V E R A N D H D D The illustrations below show how to remove the Cover and HDD from the VivoPC. 1. Remove rubber 2. Remove the bottom cover Unscrew 4 screws 2 - 7...
Page 8
Disassembly Procedure 3. Motherboard Remove the power switch cable and wifi cable Unscrew 2 screws and take out the motherobard Notice there is a battery cable connect with MB, please remove it 2 - 8...
Page 9
Disassembly Procedure 4. Memory , Wifi Card and SSD Unlock the holders and take the memory out Unscrew the screw and remove the wifi card Unscrew the screw and remove the SSD 2 - 9...
Page 10
Disassembly Procedure 5. Card reader module and cooler system, Unscrew the screw and remove the card reader Remove the fan power cable Unscrew two screws and remove the fan 2- 10...
Page 11
Disassembly Procedure Unscrew 3 screw and remove the CPU cooler 6. Chassis parts Before remove the top cover, please remove the cable first 2 -11...
Page 12
Disassembly Procedure Unlock 7 holders and remove the top cover Unscrew 2 screws and remove the power SW module 7. All parts, 2 -12...
