Thank you for giving UL the opportunity to partner with you.
Please note, Follow-Up Procedure Revisions or Report Revisions do not include Authorization Pages, Indices, Section
General, and/or Appendices unless revisions were required or requested.
Should you have any questions, after reviewing the material, or need to report any inaccuracies, please reach out to
your UL representative or find UL contact details for your local Customer Service Department at
https://www.ul.com/about/locations.
Please find attached the related material on Project 4789962160
For your convenience, the below describes the related updates:
Certificate of Compliance format now separates US and Canada certified Products by specified scheme and category.For
revised/new documentation, please reference 2021-07-05 in the page headings.Volume(s) 1 Section(s) 40 were added.
E324690-20210705-CertificateofCompliance
E324690-20210705-Description
Figure-15-Total
Illustration-5-Total
E324690-20210705-TestRecord
This material is provided on behalf of UL LLC (UL) or any authorized licensee of UL.
Times change, Trust Remains™

Advertisement

loading
Need help?

Need help?

Do you have a question about the FE9192-H and is the answer not in the manual?

Questions and answers

Related Manuals for Vivotek FE9192-H

Summary of Contents for Vivotek FE9192-H

  • Page 1 Thank you for giving UL the opportunity to partner with you. Please note, Follow-Up Procedure Revisions or Report Revisions do not include Authorization Pages, Indices, Section General, and/or Appendices unless revisions were required or requested. Should you have any questions, after reviewing the material, or need to report any inaccuracies, please reach out to your UL representative or find UL contact details for your local Customer Service Department at https://www.ul.com/about/locations.

  • Page 2: Certificate Of Compliance

    C E R T I F I C A T E O F C O M P L I A N C E Certificate Number UL-US-2133281-0 Report Reference E324690-20210705 Date 7-Jul-2021 VIVOTEK INC Issued to: 6TH FL, 192 LIEN CHENG RD CHUNG HO DISTRICT NEW TAIPEI Taiwan 235 AZOT - Audio/Video, Information and Communication This is to certify that...
  • Page 3 This is to certify that representative samples of the product as specified on this certificate were tested according to the current UL requirements Model Category Description FE9192-H Network Camera Bruce Mahrenholz, Director North American Certification Program UL LLC Any information and documentation involving UL Mark services are provided on behalf of UL LLC (UL) or any authorized licensee of UL. For questions, please contact a local UL Customer Service Representative at http://ul.com/aboutul/locations/...
  • Page 4 C E R T I F I C A T E O F C O M P L I A N C E Certificate Number UL-CA-2127743-0 Report Reference E324690-20210705 Date 7-Jul-2021 VIVOTEK INC Issued to: 6TH FL, 192 LIEN CHENG RD CHUNG HO DISTRICT NEW TAIPEI Taiwan 235 AZOT7 - Audio/Video, Information and Communication This is to certify that...
  • Page 5 This is to certify that representative samples of the product as specified on this certificate were tested according to the current UL requirements Model Category Description FE9192-H Network Camera Bruce Mahrenholz, Director North American Certification Program UL LLC Any information and documentation involving UL Mark services are provided on behalf of UL LLC (UL) or any authorized licensee of UL. For questions, please contact a local UL Customer Service Representative at http://ul.com/aboutul/locations/...
  • Page 6 Project 4789962160 July 5, 2021 REPORT Audio/Video, Information and Communication Technology Equipment VIVOTEK INC NEW TAIPEI, 235 TAIWAN Copyright  2021 UL LLC UL LLC authorizes the above named company to reproduce this Report only for purposes as described in the Conclusion, provided it is reproduced in its...
  • Page 7 [ ] Listed Accessory CCN: [X] AZOT, [X] AZOT7 (Information Technology Equipment) Product: Network Camera Model: FE9192-H Rating: PoE DC 37-57 V, 0.24-0.15 A (Optionally provided on marking plate) Applicant Name and Address: VIVOTEK INC 6TH FL, 192 LIEN CHENG RD...
  • Page 8 File E324690 Vol. Sec. Page Issued: 2021-07-05 and Report Supporting Documentation The following documents located at the beginning of this Procedure supplement the requirements of this Test Report: A. Authorization - The Authorization page may include additional Factory Identification Code markings. B.
  • Page 9 File E324690 Vol. Sec. Page Issued: 2021-07-05 and Report Altitude during operation (m) ..........: Up to 2,000 Up to ___ m Altitude of test laboratory (m) ..........: Less than 2,000 Approximately _____ 0.354 kg Mass of equipment (kg) .............:...
  • Page 10 File E324690 Vol. Sec. Page Issued: 2021-07-05 and Report Technical Consideration (NOT FOR FIELD REPRESENTATIVE’S USE)  The product was submitted and evaluated for use at the maximum ambient temperature (Tma) permitted by the manufacturer’s specification of: 50 °C  The product is intended for use on the following power systems: No direct connection ...
  • Page 11 LPS (Limited Power Source) or PS2, and output rating 37-57Vdc, 0.24-0.15A min, suitable for use at Tma 50 degree C. If need further assistance with purchasing the power source, please contact to Vivotek for further information. Or equivalent.
  • Page 12 File E324690 Vol. Sec. Page Issued: 2021-07-05 and Report 4.1.2 TABLE: list of critical components Pass Object/part or Manufacturer/ type/model technical data Product Category Required Supplement ID Description trademark CCN(s) Marks of Conformity 01. Label Interchangeable Interchangeable Min. 70 degree C to metal PGDQ2 or PGJI2 UL surface 02.
  • Page 13 File E324690 Vol. Sec. Page Issued: 2021-07-05 and Report 03. Lens cover TEIJIN LIMITED L-1225Z(#1)(f1) HB min., 2.5 mm thickness QMFZ2 RESIN AND min. 115C. Overall See PLASTIC Illustration-2 for details. 04. Plastic enclosure SABIC JAPAN L L C 945(GG) V-0, 2.5 mm thickness min.
  • Page 14 File E324690 Vol. Sec. Page Issued: 2021-07-05 and Report 11. Interconnecting Interchangeable Interchangeable Maximum length 3.05 m. FEP, AVLV2 Cable (Optional) PTFE, PVC, TFE, neoprene, polyimide or rated VW-1 or FT- 1. Minimum 80 degree C. Minimum 30 V for non-POE circuit &...
  • Page 15 File E324690 Vol. Sec. Page Issued: 2021-07-05 and Report (Alternate) (Optional) surface. Interchangeable 15b. Plastic Material of Interchangeable V-1 min. or VTM-1 min. when ZPMV2 or ZPXK2 UL Flexible Printed Wiring components mounted on (Alternate) (Optional) surface existed.
  • Page 16 File E324690 Vol. Sec. Page Issued: 2021-07-05 and Report ENCLOSURES Type Supplement Id Description Photographs Figure-01 Overall View-1 Figure-02 Overall View-2 Figure-03 Overall View-3 Figure-04 Internal View-1 Figure-05 Internal View-2 Figure-06 Lens View-1 Figure-07 Lens View-2 Figure-08 Internal board View-1 Figure-09 Internal board View-2 Figure-10...
  • Page 18 Figure-1 Page-1...
  • Page 19 Figure-2 Page-1...
  • Page 20 Figure-3 Page-1...
  • Page 21 Figure-4 Page-1...
  • Page 22 Figure-5 Page-1...
  • Page 23 Figure-6 Page-1...
  • Page 24 Figure-7 Page-1...
  • Page 25 Figure-8 Page-1...
  • Page 26 Figure-9 Page-1...
  • Page 27 Figure-10 Page-1...
  • Page 28 Figure-11 Page-1...
  • Page 29 Figure-12 Page-1...
  • Page 30 Figure-13 Page-1...
  • Page 31 Figure-14 Page-1...
  • Page 32 Figure-15 Page-1...
  • Page 33 The following Page(s) are related to Illustration-1. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
  • Page 34 ISSUE DATE 1.81 Sep-03-20 REVISION 名稱 ≦10 10~50 50~120 120~400 >400 THEREWITH ARE PROPRIETARY TO VIVOTEK INC, AND SHALL NOT BE USED OR DISCUSSED IN WHOLE ±1 ±0 30' ±0 20' ±0 10' ±0 5' FINISH SCALE UNIT OR IN PART WITHOUT VIVOTEK`S CONSENT.
  • Page 35 SUS304_ 1.1 mm Dec-30-20 REVISION 7.參考尺寸以配合組裝為主要考量，必要時需要額外實配檢驗 名稱 ≦10 10~50 50~120 120~400 >400 THEREWITH ARE PROPRIETARY TO VIVOTEK INC, 8.變形量請依圖面標示,或尺寸<0.25%定義 AND SHALL NOT BE USED OR DISCUSSED IN WHOLE ±1 ±0 30' ±0 20' ±0 10' ±0 5' FINISH SCALE UNIT OR IN PART WITHOUT VIVOTEK`S CONSENT.
  • Page 37 The following Page(s) are related to Illustration-2. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
  • Page 38 THIS DRAWING ON THIS PRINT AND INFORMATION M'TL 透明PC(L-1225Z) ISSUE DATE 03-Aug-16 REVISION 11.所有料件、組裝配件以及包裝之材質(此處指會隨我司成品出貨之包裝材)都需符合RoHS環保規範，並檢附相關報告 >300 0.30 THEREWITH ARE PROPRIETARY TO VIVOTEK INC, AND SHALL NOT BE USED OR DISCUSSED IN WHOLE (需符合歐盟2011/65/EU法規之有害物質限制含量以下規定，且不接受任何排除條款) FINISH SCALE 3:10 UNIT ANGULAR:X OR IN PART WITHOUT VIVOTEK`S CONSENT.
  • Page 40 The following Page(s) are related to Illustration-3. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
  • Page 41 晶睿白色PC ISSUE DATE Nov-17-20 REVISION 名稱 ≦10 10~50 50~120 120~400 >400 THEREWITH ARE PROPRIETARY TO VIVOTEK INC, AND SHALL NOT BE USED OR DISCUSSED IN WHOLE ±1 ±0 30' ±0 20' ±0 10' ±0 5' FINISH SCALE UNIT OR IN PART WITHOUT VIVOTEK`S CONSENT.
  • Page 43 The following Page(s) are related to Illustration-4. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
  • Page 44 ADC12 ISSUE DATE 1.61 Sep-24-20 REVISION 名稱 ≦10 10~50 50~120 120~400 >400 THEREWITH ARE PROPRIETARY TO VIVOTEK INC, AND SHALL NOT BE USED OR DISCUSSED IN WHOLE ±1 ±0 30' ±0 20' ±0 10' ±0 5' FINISH 晶睿白砂烤漆 SCALE UNIT OR IN PART WITHOUT VIVOTEK`S CONSENT.
  • Page 46 The following Page(s) are related to Illustration-5. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
  • Page 47 VIVOTEK NOTE: Camera Hardware Preventative Maintenance: 1. Visual inspection of all major components including accessories, cabling and connections where accessible for signs of deterioration or damage. 2. Check and clean cameras, lenses and housings inside and out as needed. •...
  • Page 48 VIVOTEK IMPORTANT: 1. The product must be installed and protected in a location that is not easily accessible, and is away from impacts or heavy vibration. For example, at the location where the surveillance cameras are looking down or installed at high positions such as on a wall, or at least 3 meters above the ground.
  • Page 50 2021-07-05 TEST RECORD NO. 1 SAMPLES: The manufacturer submitted representative production samples of Network Camera, Model FE9192-H for investigation. GENERAL: Test results relate only to the items tested. Unless otherwise noted, all clauses and tests were not considered necessary based upon previous evaluation under the CB scheme. The CB Scheme Test Certificate Ref.
  • Page 51 File E324690 Page T1-2 of 2 Issued: 2021-07-05 Test Record Summary: The results of this investigation, including construction review and testing, indicate that the products evaluated comply with the applicable requirements in the U.S. and Canadian (Bi-National) Standard for Safety of Audio/video, information and communication technology equipment - Part 1: Safety requirements CAN/CSA-C22.2 No.62368-1 2 Edition, issued Date...
  • Page 52 File E324690 Page C1 Issued: 2021-07-05 CONCLUSION A sample of the product covered by this Report has been found to comply with the requirements covering the category and the product is found to comply with UL’s applicable requirements. The description and test result in this Report are only applicable to the sample(s) investigated by UL and does not signify UL certification or that the product(s) described are covered under UL’s Follow-Up Service Program.
