- Page 1 ™ P e r f o r m a n c e , D e l i v e r e d . Gas Genset (Electric Start) Made in China/Fabriqué en Chine Lotus Tool Group (Philippines) www.lotustoolworks.com GL8500EX...
-
Page 2: Safety Information
• Keep the area well-ventilated and keep open flames/sparks away when hand ling the battery 2． CONTROL FUNCTION OIL WARNING SYSTEM When the oil level falls below the lower level, the engine stops automatically. Unless you refill with oil, the engine will not start again. ® Lotus Tool Group... -
Page 3: Engine Switch
(7) Choke Lever (8) AC Receptacle (9) Engine Switch (10) Ground Termina (11) Oil Filler Cap (12) Oil Drain Plug (13) Recoil Starter (14) Fuel Gauge (15) Oil Warning Light (option) (16) AC Current Breake (17) Voltmeter ® Lotus Tool Group... -
Page 4: Before Operation Check List
• If fuel level is low, refill with unleaded gasoline. • Be sure to use the fuel filter screen on the fuel filter neck. • Recommended fuel: Unleaded gasoline. • Fuel tank capacity: Model Full 1.5KW 3.0KW, 3.5KW 6.5KW, 8.5KW, 9KW,10KW ® Lotus Tool Group... -
Page 5: Check Engine Oil
NOTE: The Generator has been shipped without engine oil. Fill with oil or it will not start. STARTING THE ENGINE NOTE: • Before starting the engine, do not connect the electric apparatus. Keep circuit breaker in OFF position. ® Lotus Tool Group... - Page 6 After starting, allow the starter handle to return to its original position while still holding the handle. 5. Allow engine to warm up for 30s, then turn the choke lever back to the “RUN” position slowly. 6. Allow engine to warm up without load for 2 minutes. ® Lotus Tool Group...
-
Page 7: Using Electric Power
4. Turn the fuel shut off valve lever to “OFF”. 4） BATTERY (Optional, Electric starting system ONLY) 1. REPLENISHING THE BATTERY FLUID • Check the fluid level. The level should be between the upper and lower level marks. • Add only distilled water if necessary. ® Lotus Tool Group... -
Page 8: Recommended Battery
System Decarboni - More frequentl y i f necessary. zati o n Fi t ti n gs / Check al l fi t ti n gs and fasteners correct i f Fasteners necessary. ® Lotus Tool Group... -
Page 9: Engine Oil Replacement
2. Turn the fuel shut off valve lever to “OFF”. 3. Clean with solvent. 4. Wipe off. 5. Check the gasket. Replace it if damaged. ! WARNING BE sure the fuel shut off valve cup is tightened securely. ® Lotus Tool Group... -
Page 10: Fuel Tank Filter
2. Clean the carbon deposits out of the muffler screen using a wire brush. 3. Check the muffler screen. Replace it if damaged. 4. Install the muffler screen and muffler protector. ① Muffler protector ② Muffler screen ® Lotus Tool Group... -
Page 11: Engine Troubleshooting
Faulty magneto chamber supplied Consult dealer with fuel Improper adjustment of carburetor Prope Spark Insufficient Pull rope pulling speed for sharply starting rope Improper grade Check fuel of fuel used Overloading Check the working condition Overheating ® Lotus Tool Group... -
Page 12: Generator Trouble Shooting
• Spark plug dirty with carbon or wet….Remove carbon or wipe spark plug dry. • Faulty ignition system….Consult dealer. 4. Compression Insufficient • Worn out piston and cylinder….Consult dealer. • Loose cylinder head nuts….Tighten nuts properly. • Damaged gasket….Replace gasket. ® Lotus Tool Group... -
Page 13: Drain The Fuel
9. Clean exterior of the generator and apply a rust inhibitor. 10. Store the generator in a dry, well-ventilated place. 11. The generator must remain in an upright position. 8. SPECIFICATION Items GL1500X GL3000X GL3500EX GL6500EX GL8500EX GL10000EX Voltage/Frequency 220V/60HZ 220V/60HZ 220V/60HZ 220V/60HZ 220V/60HZ 220V/60HZ Rated Power (Real) 1.2KW...
