Summary of Contents for Lotus DL8000EX
- Page 1 ™ P e r f o r m a n c e , D e l i v e r e d . 8KW Diesel Genset Electric Made in China/Fabriqué en Chine Lotus Tool Group (Philippines) www.lotustoolworks.com DL8000EX...
- Page 2 Some of the pictures in this manual may differ slightly from the actual product as well. We reserves the right to make changes at any time without notice and without incurring any obligation. ® Lotus Tool Group...
-
Page 3: Chapter 1 Technical Specification And Data
Figure 1. Overall of the DL8000EX CHAPTER 1 TECHNICAL SPECIFICATION AND DATA MODEL DL8000EX GENERATOR TYPE Single Phase EXCITATION Self- excitation voltage VOLTAGE SYSTEM Condenser compensation System 50/60Hz FREQUENCY (Hz) RATED POWER 7.5KVA 220-240V AC RATED VOLTAGE DC RATED OUTPUT 12 - 8.3... -
Page 4: Chapter 2 Operating The Diesel Generator
If you come in contact with elctrolytic liquid, wash it immediately with clean water. Also if the electrolytic liquid comes in contact with your eyes, see a doctor immediately. ® Lotus Tool Group... -
Page 5: Preparation Before Operation
After filling, b. 3-4 days later, insert half of the fuel sucker into the drum Tghten the fuel cap. (water and impurities stay in the lower portion of the drum). ® Lotus Tool Group... -
Page 6: Check Air Filter
(2) After replacing the air filter element, replace the cover and tighten the butterfly nut firmly. Cover at the check mouth for air filter ® Lotus Tool Group... - Page 7 20 hours or every month, an order engine the oil change about 100 hours or three months. 2.4 Starting the generator set 2.4.1 Manual starting. Start the engine in accordance with procedures below: 1. Put the fuel switch in the “ON” position. ® Lotus Tool Group...
- Page 8 3. Do not adjust the speed limit regulation nut or the fuel adjustment bolt. These bolts have been set by the factory, Changing them will affect the properties of the engine performance. ® Lotus Tool Group...
- Page 9 3. Do not connect the negative and positive terminals of the battery together at any time. Doing so will damage the battery. 4. Do not reverse the polarities when attching the battery cables to the battery. Doing so will damage the both the battery and the electric starter. ® Lotus Tool Group...
-
Page 10: Stopping The Generator
If you need these manual, please call our company and we will send you one. Before starting the mantenance, make sure the diesel engine is off. Please refer to the table 3-1 for proper maintenance schedule. ® Lotus Tool Group... - Page 11 Do not use detergent to clean aie filter element Note: Never start the engine without the air filter. This can cause serious damage to the engine if foreign objects enter the intake system. Always change the air filter or time. ® Lotus Tool Group...
- Page 12 6. Finally pull the recoil starter until you feel resistance; This is when the piston is on the compression stroke where the intake and exhaust valves closed will prevent rust, as moisture cannot get inside the combustion chamber. 7. Clean the engine and store it in a dry place. ® Lotus Tool Group...
-
Page 13: Chapter 4 Overhauling And Troubleshoo
1. Model of diesel engine generator and engine model number 2. State of residency 3. Number of hours of operating equipment along with the problem that accured 4. A deatiled condition and time when the problem occured, in other words, climate and atmosphere ® Lotus Tool Group... - Page 14 ® Lotus Tool Group...
- Page 15 ® Lotus Tool Group...
- Page 16 2. If the remote control was chosen to start the generaor, the remote control should be chosen to stop the unit. To stop the unit, press the number “2” key the generator will automatically stop. 3. Description of keys a. Remote control start b. Remote control stop ® Lotus Tool Group...
