Installing the MVGA-NVTNT2A/AL(Ultra) adapter
card
1. Turn OFF your computer, remove the computer case, and then ground
yourself by touching the power supply of the computer.
Note: Before installing the MVGA-NVTNT2A/AL(Ultra) card you
2. Remove your old graphics card, and install your new
MVGA-NVTNT2A/AL(Ultra) card into the AGP slot.
3. Align and secure the mounting bracket of the card to the computer and
replace the computer case.
4. Connect the monitor cable to the DB-15 connector of the card.
5. Turn ON your computer.
must first set the VGA option to either standard VGA or
Standard Display VGA.
MVGA-NVTNT2A/AL(Ultra)
AGP slot
PCI slot
AGP mainboard
4
