Summary of Contents for Vive Comfort TP-P-HP21
- Page 1 Operation Manual Operation Manual 尺寸：120*120mm 材质：105g铜版纸，一颗骑马钉，彩印...
- Page 2 TP-P-HP21 Vive Comfort Web: www.vivecomfort.com Table of Contents Page Caution: Table of Contents Thermostat Operation Equipment damage hazard. Do not switch the system to Thermostat Quick Reference 4-18 cool if the temperature is Warranty Information below 50ºF (10ºC). Una version en español...
-
Page 3: Thermostat Operation
Thermostat Operation Thermostat Operation System Switch Selects the operation mode on your HVAC system. Selecting HEAT turns on the heat mode. Selecting COOL turns on the cool mode. Selecting OFF turns both heating and cooling off. Selecting EMER is typically used when compressor operation is not desired, or you prefer to ①... -
Page 4: Thermostat Quick Reference
Thermostat Quick Reference Thermostat Quick Reference Important: LEAVE The thermostat will operate from 2 size “AA” alkaline batteries or 24VAC power. When operated from batteries, connection to the “C” (common) or (neutral) TEMPORARY Hold terminal is not required. NOTE: When operated from batteries only, the LCD display backlight will be lighted less than 5 seconds after each button pressed, when backlight option are set to 2) or 3). - Page 5 Thermostat Quick Reference Thermostat Quick Reference Understanding Your Thermostats Staging: Select lter time in months. Default = 00. A selection of “00” FL (00) 00, 1 to 12 PRGM This thermostat controls 2 stages of heating. For reasons of energy efficiency the thermostat will try to deactivates the lter feature.
-
Page 6: Manual Operation
Thermostat Quick Reference Thermostat Quick Reference 2. Select heating cycle rate 7. Select compressor lockout delay The FA setting is used to produce shorter heating cycles. The SL setting produces a longer heating To protect the compressor from short cycling, you can select compressor off-time cycle cycle. - Page 7 Thermostat Quick Reference Thermostat Quick Reference MANUAL OPERATION Weekdays (5 day) Saturday and Sunday Mode Period Start Time Temperature Start Time Temperature SET CURRENT DAY AND TIME Press the TIME button for 3 seconds. The display will show the hours numbers ashing. Heat 6:00 AM 70ºF...
- Page 8 Thermostat Quick Reference Thermostat Quick Reference MANUAL OPERATION MANUAL OPERATION (Continue...) (Continue...) 6) Move the SYSTEM switch to HEAT or COOL and press RUN to begin program operation. 6) Repeat steps 3 and 4 to select the start time and heating temperature for the 2nd heating REVERT TO FACTORY DEFAULT PROGRAM SET TINGS program period.
-
Page 9: Troubleshooting
Thermostat Quick Reference Thermostat Quick Reference MANUAL OPERATION MANUAL OPERATION (Continue...) (Continue...) COOLING SYSTEM Important: Replace the batteries when the low battery message ashes on the display. This will keep the thermostat operating properly. With two “AA” batteries installed, your thermostat will maintain CAUTION: To prevent compressor damage, if the outdoor temperature is below 50ºF (10ºC), DO NOT operate the cooling system time and continuously display the temperature during a loss of AC power. - Page 10 Thermostat Quick Reference Thermostat Quick Reference Troubleshooting Troubleshooting (Continue...) (Continue...) Symptom Symptom Possible Cause Corrective Action Possible Cause Corrective Action system down when a lockout condition Check each wire connection to verify they are occurs. If the heat works intermittently, not shorted or touching together.
-
Page 11: Warranty Information
Thermostat Quick Reference Warranty Information Troubleshooting (Continue...) Warranty Registration Symptom Possible Cause Corrective Action Your new thermostat has 1 year limited warranty. You must register The thermostat will maintain its program in your thermostat within 60 days of installation. Without this Clock memory even with no power and no batteries, looses... -
Page 12: Speci Cations
Speci cations Installation Manual Power Supply......20VAC-30VAC 50-60HZ or Battery power for display not control TP-P-HP21 Terminal Load......1.0A per terminal, 3.0A maximum total load Set Point Temp. Range..45ºF to 90ºF (7ºC to 32ºC). Accuracy........+/- 1ºF or +/- 0.5ºC. Vive Comfort Web: www.vivecomfort.com Dimensions......6.0”... -
Page 13: Installation Tips
Subbase Installation Installation Tips Mount Thermostat Horizontal Mount Installation Tip: Electrical Hazard Vertical Mount Always turn off power at the main power 1. Push the button to open source by removing the fuse, or switch thermostat front cover the circuit breaker to the off position before installing, removing, cleaning, or servicing this thermostat. - Page 14 Thermostat Quick Reference Important Installing batteries backwards can damage the thermostat. Features 1. Install two fresh “AA” alkaline batteries in the battery compartment. Be sure to match positive (+) ends of batteries with positive (+) battery terminals in the battery Large LCD display with backlight, continuous backlight option.
-
Page 15: Wiring Diagrams
Wiring WARNING ! Electrical Shock Hazard Wiring Diagrams Power from C wire (Without battery) Turn off power at the main service panel by removing the fuse or switching the appropriate circuit breaker to the OFF position before removing the existing thermostat. -
Page 16: Terminal Designations
Wiring Wiring Terminal Designations FAN OPTION SWITCH Read the following information before setting the fan option switch (See gure 1). If you are unsure of your application, contact a quali ed service person. This thermostat is con gured from the factory to energize the fan on a call for heat. If your system Heat Pump System is an electric heat or heat pump that REQUIRES the thermostat to turn on the fan on a call for heat, 1 HEAT 1 COOL / 2 HEAT 1 COOL... - Page 18 C O M F O R T www.vivecomfort.com...
