SMC Networks TigerSwitch SMC6128L2 Specifications page 2

TECH SPECS - SMC6128L2 / SMC6152L2
PORTS
• 24/48 10/100BASE-T ports
• 4 Gigabit combo ports (RJ-45/SFP)
nETWORk InTERFACE
• 10/100 BASE-T ports
• 10/100/1000 BASE-T ports
• SFP Transceiver slots supporting SX, LX
and ZX SFP
• Multimode fiber cable; 62.5/125 or
50/125 microns
• Singlemode fiber cable: 9/125 micron
SWITCHInG FABRIC
• SMC6128L2 - 12.8 Gbps / 9.5Mpps
• SMC6152L2 - 17.6 Gbps / 13Mpps
BUFFER ARCHITECTURE
• 4Mbits
SWITCHInG dATABASE
• 8K MAC address entries
MEMORy
• SMC6128L2: 64MB SDRAM/ 16MB Flash
• SMC6152L2: 64MB SDRAM/ 16MB Flash
LEd
• System: Power, Diag
• Ports: Link/activity
TEMPERATURE
• Operating: 0 to 40 °C/32 to 104 °F
• Storage: -40 to 70 °C/-40 to 158 °F
HUMIdITy
• Operating: 10% to 90% (non-condensing)
WEIGHT
• SMC6128L2 - 3 kg/6.7 lbs
• SMC6152L2 - 3.15 kg/6.96 lbs
dIMEnSIOnS
• 440 x 171 x 43 mm
• 17.3 x 6.7 x 1.7in
AC InPUT
• 100 to 240 V, 50-60 Hz, 1A
POWER SUPPLy
• Internal, auto-ranging transformer:
100 to 240 VAC, 50 to 60 Hz
POWER COnSUMPTIOn
• 30 Watts maximum
MAXIMuM CuRREnT
• 0.25 A @ 115 VAC
• 0.12 A @ 230 VAC
MTBF
• 8 Years
SWITCH FEATURES
• Spanning Tree Protocol (802.1D, .1w)
• Forwarding Mode
• Store-and-forward
• VLAn Support
• up to 255 groups; port-based or
with 802.1Q
• VLAn tagging, GVRP for automatic VLAn
learning
• 802.1v (Protocol based Vlans)
• Private vlan support
• MultiLink Trunking (LACP)
• 8 groups of up to 8 ports
• IEEE 802.1x
• L2/L3/L4 access control lists
• RADIuS
• TACACS+ client authentication
• HTTPS and SSL
• SSH (v1.5 and 2.0) for Telnet sessions
• Static port security
• Jumbo Frame support (on gigabit ports)
QUALITy OF SERVICE
• Supports 4 levels of priority with flexible
classification and prioritization
• Per port bandwidth management
• Diffserv, IEEE802.1p (priority queues), DSCP,
or TCP/UdP port based
dIAGnOSTIC FEATURES
• Port Mirroring
• Remote Ping
• Event/Error Log
• SMTP
• SnTP
MAnAGEMEnT FEATURES
• In-Band Management
• Telnet, SLIP, Web-based HTTP, or SnMP
manager
• Out-of-Band Management
• RS-232 DB-9 console port
• Software Loading
• TFTP in-band or Xmodem out-of-band
• Dual firmware images
• Multiple configuration files support
• MIB Support
• MIB II (RFC 1213), Bridging MIB (RFC 1493),
Ethernet-Like MIB (RFC 2665), Bridge MIB
Extensions (RFC 2764), RMOn MIB (RFC
1757), RFC 2737, RFC 2742, RFC 2021, RFC
2863, RFC 2618, SMC private MIB
RMOn SUPPORT
• Groups 1,2,3, 9 (Statistics, History,
Alarm, Event)
STAndARdS
• IEEE802.3 Ethernet, IEEE802.3u
Fast Ethernet, IEEE802.3ab, IEEE802.3z
Gigabit Ethernet
• IEEE802.1D Spanning Tree Protocol and
traffic priorities
• IEEE802.3x Flow Control
• IEEE802.1p Priority tags
• IEEE802.1Q VLAn
• IEEE802.1ac VLAn tagging
• IEEE802.3ad Link aggrega tion control
protocol
• IEEE802.1w Rapid Spanning Tree
• IEEE802.1v Protocol Based Vlans
POWER TO CONNECT
ISO
• IEC8802.3
COMPLIAnCES
• CE Mark
• Emissions
• FCC Class A
• Industry Canada Class A
• En55022 (CISPR 22) Class A
• En 61000-3-2/3
• VCCI Class A
• Immunity
• En 61000-4-2/3/4/5/6/8/11
SAFETy
• uL / CuL (uL 60950-1, CSA 22.2 nO60950-1)
• TuV/GS (En60950-1)
• CB (IEC60950-1)
WARRAnTy
• Please check www.smc.com for the warranty
terms in your country/region
SLIdE-In TRAnSCEIVERS
FOR COMBO PORTS
SMC1GSFP-SX
• 1G SX SFP Transceiver, 550M, Multimode fiber
SMC1GSFP-LX
• 1G LX SFP Transceiver, 10Km,
Singlemode fiber
SMC1GSFP-ZX
• 1G LH SFP Transceiver, 70Km
Singlemode fiber
COnTACT
north America
20 Mason
Irvine, CA 92618
1-800-SMC-4yOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local country
contact information
