- Page 1 P e r f o r m a n c e , D e l i v e r e d . ™ 60A Plasma Cutter Made in China/Fabriqué en Chine Lotus Tool Group (Philippines) www.lotustoolworks.com LT60CXT Pro...
- Page 2 • In case that you have difficulty in installation and operation, please refer to the relative content in this manual for troubleshooting. • In case that you have difficulty in understanding the manual or this manual fail to solve the problems, please contact your supplier or our service center for professional help. ® Lotus Tool Group...
- Page 3 2. Any damage caused by non-human factors can be repaired for free in the repairing guarantee periiod. 3. Don’t remove, change or replace the electronic parts by clients, otherwise it will cause more serious effect. Any responsibility from the effect is not covered by our company. ® Lotus Tool Group...
-
Page 4: Technical Parameter
I. Technical Parameter MODEL LT60CXT Pro Input Voltage (V) AC220V±15% Input Power Capacity (KVA) No Load Voltage (V) Current Range (A) 20-60A Rated Output Voltage (V) Load Sustaining Rate (%) Efficiency Power Factor Cos Ø 0.93 Insulation Class Shell Protection Grade... - Page 5 Note: The electrode shall be turned into the torch head by using hex key wrench in the installation of torch head and tight it up. Otherwise it will burn the inner thread of electrode. ® Lotus Tool Group...
-
Page 6: Operation
1. Turn the power switch on the front plate to the “ON” position, after that the power switch indicating lamp will be on and the screen of the meter display the set current value. LT60CXT Control Panel description Figure ® Lotus Tool Group... -
Page 7: Matters Need Attention
If no or little plasma arx was sprayed from the nozzle, the electrode or nozzle was installed improperly. It shall be reinstalled after the machine is off. ® Lotus Tool Group... -
Page 8: Maintenance
2. When it start cutting, point the outer edge of nozzle to that of the workpiece, press the swich ant it will start arc. If the arc can not be ignited, release the switch, press the switch again and move the torch at stable speed for normal cutting after succed in arc starting. -
Page 9: Faults And Troubleshooting
VI. Faults and Troubleshooting Note: The following operaion require the operator having sufficient knowledge on electricity and relevant safety snese. The operator shall have valid qualification certificates. 1. LT60CXT Faults and Troubleshooting FAULTS TROUBLESHOOTING • Power indication lamp is on Overload protection.
