INSTRUCTION MANUAL
(Synchronous closing acceleration function. ±0.05Hz)
(Synchronous closing acceleration function. ±0.02Hz)
AUTOMATIC SYNCHRONIZER
ASY-96-A1
ASY-96-A2
ASY-203-056

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASY-96-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Daiichi Electronics ASY-96-A1

  • Page 1 ASY-203-056 INSTRUCTION MANUAL AUTOMATIC SYNCHRONIZER ASY-96-A1 (Synchronous closing acceleration function. ±0.05Hz) ASY-96-A2 (Synchronous closing acceleration function. ±0.02Hz)
  • Page 2 ASY-203-056 The following rules and warnings must be followed during handling the product. This instruction manual contains important information to prevent injury to person and damage on the product. Read entire instruction manual before handling the product. 1. Installation environment Do not install the product in the following environment.
  • Page 3: Table Of Contents

    ASY-203-056 CONTENTS 1. Description ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3 2. Feature ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3 3. Functions ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3 4. Specification and performance 4.1 Specification ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4 4.2 Performance ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 5 5. Control function 5.1 Control range ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 6 5.2 Control input and description ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 6 5.3 Control output and contents ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・...
  • Page 4: Description

    ASY-203-056 1. Description This is a control device to carry out a synchronous closing safely and smooth in operation of generators in parallel connections. At time of parallel connection, each voltage and frequency are checked and when the difference is within a given value, closing signal is given to circuit breaker ahead of the synchronous point, accounting on advancing breaking time, so that the circuit breaker (CB) can be closed at an exact synchronous point.
  • Page 5 Voltage difference: ×100(%) (% indication to AC110V) Frequency difference:F -F (Hz) Green 7 Segment LED:-□.□□Hz Synchronous closing ASY-96-A1 (±0.05Hz specification) -0.05Hz<ΔF<+0.05Hz acceleration ASY-96-A2 (±0.02Hz specification) -0.02Hz<ΔF<+0.02Hz function 4.1.2 Setting value. 1) Voltage difference (ΔV) setting. (By rotary cord switch 1) Setting range:1, 2, 3, 4, 5, 7, 10%.
  • Page 6: Specification And Performance

    ASY-203-056 4.2 Performance Item Specification and performance Voltage difference ±0.5% Frequency difference ±0.02Hz Pulse width ±50ms Accuracy ±10%+(10~200ms) Voltage adjustment pulse cycle Phase difference detection ±1° Synchronous-closing phase ±5° accuracy Affect of temperature It is the inside of tolerance at 23±20℃ Affect of frequency It is the inside of tolerance at ±3Hz to a bus rated frequency.
  • Page 7: Control Function

    ASY-203-056 5. Control function 5.1 Control range Bus voltage :AC90~125V Generator voltage :More than AC80V Bus frequency :50±3Hz , 60±3Hz Frequency difference:Less than ±4Hz <Note> Control will stop at other ranges than above and indicate “ERROR” for each. 5.2 Control input and description. (1a contact, Switching voltage / current DC12V, 10mA) (1) Automatic synchronous start and manual synchronous start.
  • Page 8: Operation

    ASY-203-056 (7) Synchronous failure signal (ALARM). When synchronous closing is failed 3 times continuously, alarm LED turns on about 1 second afterward and contact is output. After alarm is outputted, when there is a control start, ΔF, ΔV, and ±15°(Only indication) control action are continued.
  • Page 9: Manual Synchronous Control

    ASY-203-056 6.3.2 In case of synchronous closing from generator to bus (receiving). ① Automatic synchronous start can be done under the bus voltage input condition (AC90~125V) and “SLOW” side closing designation (more than AC80V in generator voltage) is input. The control will stop under unstable voltage condition in the generator side and “ERROR”...
  • Page 10 ASY-203-056 6.4.3 Timing of a auxiliary supply, bus voltage, generator voltage, control start. Please carry out on the following conditions. ① A control input is started, after it apply bus voltage and generator voltage simultaneously and more than 1 seconds pass, where an auxiliary supply is apply. <Note>...
  • Page 11: Handling

    ASY-203-056 7. Handling 7.1 Dimension diagram +0.8 Panel cut out ( ) 162.5 M4SCREW <Note> This container and spacing with the equipment that is next give a panel cut to for more than 27mm. ■ Installation environment condition Installation selects a place suit lower account of environment condition. The place that the vibration that is mechanical and dust and corrosive gas are few.
  • Page 12: Connection

    ASY-203-056 7.3 Connection 7.3.1 Connection diagram AUTO :Automatic synchronous start signal. 60R :Voltage increases signal. MANUAL :Manual synchronous start signal. 60L :Voltage decreases signal. SLOW :SLOW side closing designation signal. ALARM :Alarm signal. 15R :Governor increases signal. <Note> The control signal input of AUTO, MANUAL, and SLOW 15L :Governor decreases signal.
  • Page 13: Setting Method

    ASY-203-056 7.5 Setting method Setting must be carried out in reference to the setting arrangement as below. Setting must be carried out at no voltage (both of bus voltage and generator voltage) or control start at “OFF” position (both of auto and manual synchronous start).
  • Page 14 ASY-203-056 (3) Voltage adjusting pulse cycle setting (Vpint)(Rotary cord switch) Set at given value in reference to code setting value table. “ERROR” (E3) is indicated at setting, code 6, 7, and 0. Cord Voltage adjusting pulse cycle setting point (Vpint) ←...
  • Page 15: Setting Example

    ASY-203-056 7.6 Setting example 7.6.1 Setting item ① Voltage difference (△V) ② Frequency difference (△F) ③ Voltage adjusting pulse width (Vpw) ④ Voltage adjusting pulse cycle (Vpint) ⑤ Governor pulse width (Fpw) ⑥ CB advancing time (25T) Setting item Initial value Setting example Voltage difference (△V) 5%...
  • Page 16: Display

    ASY-203-056 7.7 Display (Indication arrangement) Synchronous check signal Phase difference. ±15°:Umber (Corner form LED, 26 point) CB closing signal Power supply . POWER : Green 25:Green Voltage difference inside setting Voltage control signal (Dichromatic LED) % signal. (Within setting value) 60R:Red , 60L:Green ΔV : Green  ...
  • Page 17: Error Management

    ASY-203-056 7.8 Error management Control Error № Contents of error Reset condition Note status output ROM/RAM error Stop Alarm Equipment trouble A/D error Stop Alarm Equipment trouble Setting error Stop Auto return by reset Out of range, bus voltage Stop Auto return Out of range, generator voltage Stop...
  • Page 18: Simulation Test

    ASY-203-056 8. Simulation test Quality of this device is fully confirmed, however, simulating test can be carried out under the following Guidance in order to avoid trouble in advance. 1) Simulation test Amplifier Oscillator (Bus) Frequency meter Amplifier Oscillator Alarm (Generator) Frequency meter 110V/5V...
  • Page 19: Principle Of Operation

    ASY-203-056 10. Principle of operation 10.1 Block-diagram ±15° Governor increase Timer signal. Governor Timer decrease signal. Hz detection 1/2 Percent lap Hz detection Voltage Timer 1/2 Percent lap increase signal. Cycle (Period) Voltage Phase difference decrease detection Timer signal. Voltage A/D conversion detection △V...
  • Page 20: Operating Explanation

    ASY-203-056 10.2 Operating explanation (1) Frequency control (Governor increase output, governor decrease output) Bus voltage input (V ) and generator voltage input (V ) are input into frequency detecting circuit through wave-form adjusting circuit and dividing circuit, after isolation by a VT. In the frequency detecting circuit, AC cycle is counted and fed into data bus and the frequency is calculated by soft operation (1/cycle).
