- Page 1 Q-208-098C INSTRUCTION MANUAL AUTOMATIC SYNCHRONIZER ASY-100...
- Page 2 Q-208-098C Introduction Thank you for your purchase of our product. Read this instruction manual carefully before installation， wiring， and using this product. Keep this instruction manual handy for reference at any time. Have a contact with us or sales agent in case that this instruction manual is lost or damaged. <Caution>...
-
Page 3: Table Of Contents
Q-208-098C Contents 1. Outline ･･･････････････････････････････････････････････････････････････････ 3 2. Specification and performance 2.1 Specification ･････････････････････････････････････････････････････････ 4 2.1.1 Input ･････････････････････････････････････････････････････････････ 4 2.1.2 Output contact ････････････････････････････････････････････････････ 4 2.1.3 Indication ････････････････････････････････････････････････････････ 5 2.1.4 Input contact signal for control ･･････････････････････････････････ 5 2.1.5 Control signals and content ･･･････････････････････････････････････ 5 2.1.6 Control range ･････････････････････････････････････････････････････... -
Page 4: Outline
Q-208-098C 1. Outline This equipment is automatic synchronizing equipment used in the case of synchronous generation running with the system in parallel. On the occasion of parallel running，there is the need of smooth synchronous closing that suppresses the in-rushing current， alleviates the turbulence of the system and the shock to the generator by coinciding the voltage and frequency of both sides and by closing the circuit breaker precisely at the synchronizing point. -
Page 5: Specification And Performance
Q-208-098C 2. Specification and performance 2.1 Specification 2.1.1 Input (1) Analogue input：System side input， AC110V，50/60Hz，1φ(R，S) 15VA Generator side input， AC110V，50/60Hz，3φ，Each 1VA (2) Power source for test：AC110V (90～120V)， 50/60Hz， 15VA (3) Contact input For setting of advance time of circuit breaker ... (applied voltage，current，DC13V 10mA) ( ４... -
Page 6: Indication
Q-208-098C 2.1.3 Indication (1) Indicating lamp (Illumination in red) 1) Power 2) Voltage increase signal ＝ ON 3) Voltage decrease signal ＝ ON 4) Governor increase signal ＝ ON 5) Governor decrease signal ＝ ON 6) Closing command signal of circuit breaker ９... -
Page 7: Control Range
Q-208-098C (6) Automatic governor increase pulse signal Governor incremental pulse signal When frequency was the same (0～0.05Hz)， and a Phase phase difference became constant on the way， a difference governor increase pulse signal is outputted automatically. ｔ About 3 second 2.1.6 Control range This controller is available under following conditions. -
Page 8: Performance
Q-208-098C 2.2 Performance Item Performance Voltage difference ±0.5％ Frequency difference ±0.03Hz Tolerance Pulse width ±10％ Voltage adjustment pulse period ±10％ ＋ 200ms Phase angle difference ±1°±1 digit Influence of temperature Within tolerance by 23±20℃. Instantaneous overload 2 times of the rated voltage. 10 seconds. Between the electric circuit as a whole and the case Insulation resistance (earth terminal). -
Page 9: Instruction Manual
Q-208-098C 3. Instruction manual 3.1 Installation 3.1.1 Dimension diagram 3.1.2 Conditions of fitting environment At the time of installation， please select an installation place with less mechanical vibration， dust and corrosive gas，a place without an impact of strong electro-magnetic field nearby due to a large current bus or a saturable reactor. -
Page 10: Connection
Q-208-098C 3.3 Connection 3.3.1 Connection diagram Using phase rotation detector， check and confirm that the line side and generator sides indicate the correct phase rotation. １ ＧＥＮＥＲＡＴＯＲ ＬＯＡＤ ２ 60R：Signal for voltage increase ３ 60L：Signal for voltage decrease １ 15R：Signal for governor increase ＬＩＮＥ... -
Page 11: Setting
Q-208-098C 3.4.3 Setting Setting condition ① Terminal for "SET" should be short-circuited ･･････ Setting stop can be released. ② LED "SET" should be illuminated by pushing SET ten key ･････ Setting becomes possible. (1) Setting of voltage balance 1) Setting of voltage difference (1％ unit) Example：5％... -
Page 12: Indication
Q-208-098C 3.4.4 Indication ・ Condition of indication By pushing "DISPLAY" key LED DISPLAY should be lit up (indication possible) (By putting off the light of LED SET，DISPLAY mode should be obtained. Even if leaving the SET terminals short-circuited as it is，Display mode is obtained likewise.) (1) Indication of voltage balance setting 1) Indication of set value of 2) Indication of set value of... -
Page 13: Test
Q-208-098C 3.4.6 Test Though the quality of this product is secure enough，to prevent an accident of emergency beforehand，carry out the 3-phase operation test by all means before implementing the closing. If the 3-phase operation test can not be carried out unavoidably，implement the single-phase type operation test according to the instruction below. - Page 14 Q-208-098C (2) 3-phase type operation test. Using phase rotation detector，check and confirm that the line side and generator sides indicate the correct phase rotation. Switch：Operate START ：Short circuit for control start Example of set values Voltage difference：5％ Frequency difference：0.1Hz 25-1：100ms Voltage increase / decrease，pulse width：0.5s Voltage increase / decrease，pulse period：2s ①...
-
Page 15: Operation Principle
Q-208-098C 4. Operation principle 4.1 Circuit composition (ASY-100 Block diagram) ±15° ＲＧ Ｇａｖｅｒｎｏｒ Ｓｐｅｅｄ Ｔｉｍｅｒ ｓｐｅｅｄ ｕｐ ＳＧ ｍａｔｃｈｉｎｇ ｃｉｒｃｕｉｔ Ｔｉｍｅｒ Ｇａｖｅｒｎｏｒ ＴＧ ｓｐｅｅｄ ｄｏｗｎ Ｒｅｖｅｒｓｅ ｐｈａｓｅ １／２ Ｈｚ ｆｒｅｑｕｅｎｃｙ ｄｅｔｅｃｔｏｒ ... -
Page 16: Explanation Of Activation
Q-208-098C 4.2 Explanation of activation (1) Speed matching circuit This circuit detects the frequency difference between the line side and generator side and a pulse is sent out to keep the frequency difference below a constant value. Pulse circuit ... - Page 17 Q-208-098C (3) Reverse phase detection (Generator side) In case that generator side phase is reverse rotation，speed matching circuit is reset and control stop is instructed to CPU. (4) Signal within ±15°( The signal within ±15°for the phase difference between VRS of generator side and VRS of system side is constituted in the digital IC circuit.
-
Page 18: Maintenance And Check
Load MM4X (DC100/110V) Life times：2 million times 5.2 About life The life duration of ASY-100 changes with the ambient temperature. (For aluminum electrolytic capacitor being used) Average temperature of installation environment. 30℃：Guaranteed life 10.7 years， Ability life 15 years. 40℃：Guaranteed life 5.3 years， Ability life 14.5 years.
