EZO8*1H
EZO8*2H
EZO8*3H
INSTALLATION & USE MANUAL
Manual de instalación y uso
Manuel d'installation et utilisation
EZO™ Series Sensor-Operated Water Coolers
EZO™ La Barrera de la serie Liberta Agua Coolers
EZO™ Coolers d'Eau de Barrière-Libère de feuilleton
Model EZO8L
Patent zurn-elkay.com/patents
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
Page 1
1000002686 (Rev. D - 12/24)
Advertisement
Related Manuals for Elkay FLEXI-GUARD EZO Series
Summary of Contents for Elkay FLEXI-GUARD EZO Series
- Page 1 EZO™ La Barrera de la serie Liberta Agua Coolers EZO™ Coolers d’Eau de Barrière-Libère de feuilleton Model EZO8L Patent zurn-elkay.com/patents WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov Page 1 1000002686 (Rev.
- Page 2 EZO8*1H EZO8*2H EZO8*3H Note: Danger! Electrical shock hazard. Disconnect power before servicing unit. Nota: peligro! Peligro de descarga eléctrica. Desconecte antes de reparar la unidad l’appareil. Remarque : Danger ! Risque de choc électrique. Débrancher avant de réparer Uses HFC-134A refrigerant Usa refrigerante HFC-134A Utilise du fluide frigorigéne HFC-134A 13,22...
- Page 3 EZO8*1H EZO8*2H EZO8*3H FIG. 2 Page 3 1000002686 (Rev. D - 12/24)
-
Page 4: Entretien
EZO8*1H EZO8*2H EZO8*3H HANGER BRACKETS INSTALLATION INSTALACIÓN DE SOPORTES PARA COLGAR SUPPORTS DE CROCHET DE SUSPENSION INSTALLATION Retire el soporte fijador que se encuentra conectado a 1) Remove hanger brackets fastened to back of cooler la parte posterior del enfriador sacando un (1) tornillo. 1) Retirez le support de suspension fixé... - Page 5 EZO8*1H EZO8*2H EZO8*3H Note: Danger! Electrical shock hazard. Disconnect power before servicing unit. Nota: peligro! Peligro de descarga eléctrica. Desconecte antes de reparar la unidad Remarque : Danger ! Risque de choc électrique. Débrancher avant de réparer l’appareil. Service Instructions Lower and Upper Shroud To access the refrigeration system and plumbing connections, remove four screws from bottom of cooler to remove the lower shroud.
- Page 6 EZO8*1H EZO8*2H EZO8*3H SENSOR RANGE ADJUSTMENT: The electronic sensor used in this cooler is factory pre-set for a “visual” range of 36 inches (914 mm). If actual range varies greatly from this or a different setting is desired, follow the range adjustment procedure below: Using a small tip screwdriver, locate range adjustment screw through the small hole between the sensor lenses (See Page 1.) Turn this screw clockwise to increase range and counterclockwise to decrease range (See Fig.
- Page 7 EZO8*1H EZO8*2H EZO8*3H 115V PARTS LIST/ 115V LISTA DE PIEZAS/ 115V LISTE DES PIÈCES ITEM PART DESCRIPTION DESCRIPCIÓN DESCRIPTION Soporte Colgante 28401C Hanger Bracket Support de Suspension Estanque - Acero Inoxidable 55001109 Basin - Stainless Steel Basin - Inox Compresor Paquete de Servicio 36322C Compressor Serv.
- Page 8 NÚMERO GRATIS DE SERVICIO 1.800.260.6640 IMPRESO EN LOS E.E.U.U. INFORMATIONS POUR LE SERVICE PAR NUMERO SANS FRAIS 1.800.260.6640 IMPRIMÉ AUX É.-U. • ELKAY MANUFACTURING COMPANY • 1333 BUTTERFIELD ROAD • DOWNERS GROVE, IL 60515 • 630.574.8484 www.elkay.com 1000002686 (Rev. D - 12/24) Page 8...
