The Rooftop Sky Sensor provides ambient light and irradiance feedback to SageGlass Maestro
composed of several sensors to provide 360-degree coverage assessing cloud cover, light and energy in order to optimize the
300-1181-001
Interface
PoE Ethernet
Peak Power
1.1 W
Data Range
•
Illuminance: 1K Lux to 100K Lux
•
Irradiance: 8 W/m
Product Sheet:
Rooftop Sky Sensor
automated tinting behavior of SageGlass Dynamic Glass.
Product Dimensions
Part
Width
Number
8.9 cm
Description
Communication and Power
Input
Voltage
44 - 57 V DC
to 800 W/m
2
2
Dimensions
Length
8.1 cm
Specifications
10/100M
PoE Standard
Current
25 mA
IEEE 802.3af Type 1
Product Ratings
. The Rooftop Sky Sensor is
®
Height
8.9 cm
IP54
Advertisement
Related Manuals for SAINT-GOBAIN SageGlass 300-1181-001
Summary of Contents for SAINT-GOBAIN SageGlass 300-1181-001
- Page 1 Product Sheet: Rooftop Sky Sensor The Rooftop Sky Sensor provides ambient light and irradiance feedback to SageGlass Maestro . The Rooftop Sky Sensor is ® composed of several sensors to provide 360-degree coverage assessing cloud cover, light and energy in order to optimize the automated tinting behavior of SageGlass Dynamic Glass.
