Summary of Contents for Gembird SC-5.1-1
- Page 1 5.1 channels sound card SC-5.1-1 5.1 channels sound card...
- Page 2 • No part of this manual may be reproduced, transmitted or translated in any language in any form, by any means, without the prior written permission of Gembird Electronics Ltd. • Gembird Electronics makes no warranties for damages resulting from corrupted or lost data due to a mistaken operation or malfunction of the product, the software, personal computers or peripheral devices.
- Page 3 5.1 channels sound card SC-5.1-1 User manual Introduction Thank you for buying the Gembird® 5.1 channels sound card! This manual will help you install and use it properly. Features • 2/4/6 channel speakers mode. Supports 2/2.1/4/4.1/5.1 speakers • Full-duplex playback and recording •...
-
Page 4: Specifications
5.1 channels sound card Specifications • Supports 6 channel output • Fully compliant with AC97 Revision 2.3 • Superior audio fidelity • Independent 20 bit ADC and 20 bit DAC • Provide 96K/20 bit Multi-channel analog output • High quality headphone amplifier •... -
Page 5: System Requirements
5.1 channels sound card System requirements • Windows® 98SE/ME/2000/XP/Vista • DirectX 8.1 or above Sound card layout... - Page 6 5.1 channels sound card The rear panel of card has the following jacks: Mic In Line In Line Out Surr Out CEN/LFE J10 Analog CD|IN Port (Signals: L-G-G-R)
-
Page 7: Installation
5.1 channels sound card Installation • Locate an available PCI slot on your computer, and insert the 6 Channel Sound Card into the slot. Fasten the card to the case using a screw • Start your PC. Windows® will detect the Sound Card, find a “PCI Multimedia Audio Device”...
