SERVICE MANUAL
TECHNICAL INFORMATION
FOR SERVICE PERSONNEL ONLY
RAK-VJ18PHAE
RAK-VJ25PHAE
RAK-VJ35PHAE
RAK-VJ42PHAE
RAK-VJ50PHAE
RAC-VJ18PHAE,RAC-VJ25PHAE,RAC-VJ35PHAE,RAC-VJ42PHAE,RAC-VJ50PHAE
(JCH-WH NO.0148E) for items not described in this manual.
SPECIFICATIONS
TYPE
INDOOR UNIT
MODEL
RAK-VJ18PHAE
POWER SOURCE
TOTAL INPUT (W)
TOTAL AMPERES (A)
COOLING
(KW)
CAPACITY
(B.T.U./h)
TOTAL INPUT
(W)
TOTAL AMPERES (A)
HEATING
(KW)
CAPACITY
(B.T.U./h)
W
DIMENSIONS
H
(mm)
D
NET WEIGHT
(Kg)
The performance tests are based on the EN14511、EN14825.
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
ROOM AIR CONDITIONER
Johnson Controls-Hitachi Air Conditioning Wuhu Co., Ltd.
INDOOR UNIT
RC-AGS1EA0E
OUTDOOR UNIT
INDOOR UNIT
RAC-VJ18PHAE
RAK-VJ25PHAE
1 PHASE,50Hz,220-240V
1 PHASE,50Hz,220-240V
419 (250
1,010)
549 (250 1,290)
2.46-2.35
3.08-2.95
2.00 (0.90 2.50)
2.50 (0.90 3.10)
6,820 (3,070 8,530)
8,530 (3,070 10,580)
519 (250 970)
733 (250 1,250)
2.93-2.81
3.87-3.71
2.50 (0.90 3.20)
3.40 (0.90 4.40)
8,530 (3,070 10,920)
11,600 (3,070 15,010)
780
750(+60)
780
280
548
280
227
288(+55)
227
8.6
31.6
8.6
INDOOR UNIT
JCH-WH
RAK-VJ18PHAE
RAK-VJ25PHAE
RAK-VJ35PHAE
RAK-VJ42PHAE
RAK-VJ50PHAE
REFER TO THE FOUNDATION MANUAL
SPECIFICATIONS ----------------------------------------------------------------
HOW TO USE ----------------------------------------------------------------------
CONSTRUCTION AND DIMENSIONAL DIAGRAM ---------------------
MAIN PARTS COMPONENT --------------------------------------------------
WIRING DIAGRAM ---------------------------------------------------------------
CIRCUIT DIAGRAM --------------------------------------------------------------
BLOCK DIAGRAM ----------------------------------------------------------------
BASIC MODE ----------------------------------------------------------------------
REFRIGERATING CYCLE DIAGRAM --------------------------------------
PROCEDURE FOR DISASSEMBLY AND REASSEMBLY -----------
DESCRIPTION OF MAIN CIRCUIT OPERATION ------------------------
SERVICE CALL Q & A ----------------------------------------------------------
STRUCTURE OF AN INDOOR UNIT ELECTRIC PARTS -------------
SELF-DIAGNOSIS DISPLAY FUNCTION ----------------------------------
FORCED COOLING OPERATION (ONLY SINGLE CONNECTION) ---
HOW TO SET UP FROM SERVICE SETTING MODE -------------------
DIAGNOSIS AND TROUBLESHOOTING OF INDOOR ELECTRIC PARTS ----
PARTS LIST AND DIAGRAM --------------------------------------------------
DC INVERTER
OUTDOOR UNIT
INDOOR UNIT
OUTDOOR UNIT
RAC-VJ25PHAE
RAK-VJ35PHAE
RAC-VJ35PHAE
1 PHASE,50Hz,220-240V
875 (250 1,460)
4.35-3.98
3.50 (0.90 4.00)
11,940 (3,070 13,650)
1,000 (250 1,700)
5.05-4.63
4.20 (0.90 5.00)
14,330 (3,070 17,060)
750(+60)
780
7500(+60)
548
280
548
288(+55)
227
288(+55)
31.6
8.6
31.6
- 1 -
NO.0147E
CONTENTS
OUTDOOR UNIT
INDOOR UNIT
INDOOR UNIT
RAC-VJ42PHAE
RAK-VJ42PHAE
RAK-VJ50PHAE
1 PHASE,50Hz, 220-240V
1 PHASE,50Hz, 220-240V
1,120 (500 1,800)
1,471 (500 2,100)
4.68-5.10
6.14-6.69
4.20 (1.70 5.00)
5.00 (1.90 5.20)
14,330 (5,800 17,060)
17,060 (6,480 17,740)
1,317 (500 2,300)
1,558 (500 2,750)
5.49-5.99
6.50-7.09
5.40 (1.70 6.00)
6.00 (2.20 7.30)
18,430 (5,800 20,470)
20,470 (7,510 24,910)
792(+91)
780
780
600
280
280
227
299(+47)
227
39.5
8.8
8.8
6
8
30
31
32
34
35
36
49
51
54
64
66
69
74
75
83
95
OUTDOOR UNIT
RAC-VJ50PHAE
792(+91)
600
299(+47)
39.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAK-VJ18PHAE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hitachi RAK-VJ18PHAE

  • Page 1 31.6 31.6 39.5 39.5 NET WEIGHT (Kg) 31.6 The performance tests are based on the EN14511、EN14825. SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT ROOM AIR CONDITIONER INDOOR UNIT Johnson Controls-Hitachi Air Conditioning Wuhu Co., Ltd. - 1 -...
  • Page 2 6$)(7< '85,1* 5(3$,5 :25.  ,Q RUGHU WR GLVDVVHPEOH DQG UHSDLU WKH XQLW LQ TXHVWLRQ EH VXUH WR GLVFRQQHFW WKH SRZHU FRUG SOXJ IURP WKH SRZHU RXWOHW EHIRUH VWDUWLQJ WKH ZRUN  ,I LW LV QHFHVVDU\ WR UHSODFH DQ\ SDUWV WKH\ VKRXOG EH UHSODFHG ZLWK UHVSHFWLYH JHQXLQH SDUWV IRU WKH XQLW DQG WKH UHSODFHPHQW PXVW EH HIIHFWHG LQ FRUUHFW PDQQHU DFFRUGLQJ WR WKH LQVWUXFWLRQV LQ WKH 6HUYLFH 0DQXDO RI WKH XQLW ,I WKH FRQWDFWV RI HOHFWULFDO...
  • Page 3 WORKING STANDARDS FOR PREVENTING BREAKAGE OF SEMICONDUCTORS 1. Scope The standards provide for items to be generally observed in carrying and handling semiconductors in relative manufactures during maintenance and handling thereof. (They apply the same to handling of abnormal goods such as rejected goods being returned.) 2.
  • Page 4 (6) Use a three wire type soldering iron including a grounding wire. Metal plate (of Al. stainless steel, etc.) Bare copper wire (for body earth) Working table Resistor 1MΩ(1/2W) Staple Earth wire Fig.3 Grounding of the working table soldering iron Grounding wire Screw stop at the screwed part using a rag plate...
  • Page 5 CAUTION In quiet or stop operation, slight flowing noise of refrigerant in the refrigerating cycle is heard occasionally, but this noise is not abnormal for the operation. When it thunders near by, it is recommend to stop the operation and turn off the circuit breaker for safety. In the event of power failure,the room air conditioner will restare automatically in the previously selected mode once the power is restored.
  • Page 6: Specifications

    SPECIFICATIONS RAK-VJ42PHAE RAK-VJ18PHAE,RAK-VJ25PHAE,RAK-VJ35PHAE RAK-VJ50PHAE 18W (DC340 V) 38W (DC340 V) S14K320E2G10AS5 - 6 -...
  • Page 7 Figure showing the installation of lndoor unit MODEL RAK-VJ18PHAE RAK-VJ25PHAE RAK-VJ35PHAE RAK-VJ42PHAE RAK-VJ50PHAE Be sure to above 50mm completely above 50mm seal any gap with putty. above 50mm 2300 mm or more The indoor piping should be insulated with the enclosed insulation pipe.
  • Page 8 - 8 -...
  • Page 9 - 9 -...
  • Page 10 - 10 -...
  • Page 11 - 11 -...
  • Page 12 - 12 -...
  • Page 13 - 13 -...
  • Page 14 - 14 -...
  • Page 15 - 15 -...
  • Page 16 - 16 -...
  • Page 17 - 17 -...
  • Page 18 - 18 -...
  • Page 19 - 19 -...
  • Page 20 - 20 -...
  • Page 21 - 21 -...
  • Page 22 - 22 -...
  • Page 23 - 23 -...
  • Page 24 - 24 -...
  • Page 25 - 25 -...
  • Page 26 - 26 -...
  • Page 27 - 27 -...
  • Page 28 - 28 -...
  • Page 29 - 29 -...
  • Page 30: Construction And Dimensional Diagram

    CONSTRUCTION AND DIMENSIONAL DIAGRAM MODEL RAK-VJ18PHAE,RAK-VJ25PHAE,RAK-VJ35PHAE,RAK-VJ42PHAE,RAK-VJ50PHAE Unit:mm Top air suction grill Front panel Mounting plate Cabinet Horizontal air diflector Air outlet Drain When piping is drawn from the left side,exchange the drain hose for the drain cap. Drain cap connection port...
  • Page 31: Main Parts Component

    MAIN PARTS COMPONENT THERMOSTAT (Room temperature Thermistor) RAK-VJ18/25/35/42/50PHAE FAN MOTOR RAK-VJ42PHAE RAK-VJ18PHAE,RAK-VJ25PHAE,RAK-VJ35PHAE RAK-VJ50PHAE DC:340V 325V 0~65V - 31 -...
  • Page 32: Wiring Diagram

    WIRING DIAGRAM MODEL RAK-VJ18/25/35/42/50PHAE - 32 -...
  • Page 33 WIRING DIAGRAM OF THE PRINTED WIRING BOARD [Remote controller] RC-AGU1EA0G - 33 -...
  • Page 34 CIRCUIT DIAGRAM MODEL RAK-VJ18/25/35/42/50PHAE - 34 -...
  • Page 35: Block Diagram

    BLOCK DIAGRAM MODEL RAK-VJ18/25/35/42/50PHAE Frost wash WIFI Humidity Sensor Vertical sweep motor Human Sensor (21M77*) series Ionizer - 35 -...
  • Page 36 MODEL RAK-VJ18/25/35/42/50PHAE Super Hi Super Hi Super Hi Super Hi Super Hi Super Hi Super Hi Super Hi - 36 -...
  • Page 37 RAK- RAK- RAK- RAK- RAK- MODEL VJ18PHAE VJ25PHAE VJ35PHAE VJ42PHAE VJ50PHAE LABEL NAME VALUE COMP_WMAX 3800min-1 4700min-1 6000min-1 4700min-1 5500min-1 COMP_WMAX3 4800min-1 5200min-1 6400min-1 5400min-1 5800min-1 WSTD 3100min-1 4200min-1 4700min-1 4000min-1 4700min-1 COMP_CMAX 4000min-1 4500min-1 5650min-1 4550min-1 5000min-1 COMP_CMAX3 4000min-1 4500min-1 5650min-1 4550min-1...
  • Page 38 PDCIN2 50.00℃ 50.00℃ 50.00℃ 50.00℃ 50.00℃ 48.00 ℃ 48.00 ℃ PDCOF2 45.00℃ 45.00℃ 45.00℃ DNZKON 15.00℃ 15.00℃ 15.00℃ 15.00℃ 15.00℃ DNZKOF 13.00℃ 13.00℃ 13.00℃ 13.00℃ 13.00℃ FNUPPW_C 30min-1 30min-1 30min-1 30min-1 30min-1 DFMAX_STD 3700min-1 4600min-1 5700min-1 5000min-1 5000min-1 DFMAX_ATF 3700min-1 4600min-1 5700min-1 4000min-1...
  • Page 39 STARCPD1_ATF 3000min-1 3000min-1 3000min-1 2000min-1 2000min-1 STARCPD2_ATF 3400min-1 4500min-1 4500min-1 2300min-1 2300min-1 STARTDF1_ATF STARTDF2_ATF frzcln_blnce_tm 8min 8min 8min 8min 8min frzcln_souf1_tm 3min 3min 3min 3min 3min CLNTIM_DEF1 3min 3min 3min 3min 3min clntim_suf1_frz1 5min 5min 5min 5min 5min clntim_wam1_frz1 10min 10min 10min 10min...
  • Page 40 set temp. +fcaut_h_8u+0.66 set temp. +fcaut_h_8u set temp. +fcaut_l_8u+0.66 set temp. +fcaut_l_8u set temp. set temp.- 0.66 set temp.- oftmpc_8u set temp.- fan speed set to "auto" Super HI indoor Silent Ultra-LO Start Stop Stop Start start/stop switch Themo off Thermo judgment Operation lamp fzontmc1_8u/fzontmc2_8u...
  • Page 41 Super Hi Silent heating Super Hi (1) Pressing the "POWERFUL" button will reduce the temperature setting by PWSFTC 2°C. (2) The powerful operation is for 20 minutes after setting. (3) Operation is continued forcibly thermo-ON for 20 minutes after the powerful operation is finished. (4) Pressing the "START/STOP"...
  • Page 42 Start Stop Start Stop Thermo-OFF Thermo-OFF Lo silent Ultra-Lo heating Notes: (1) If the room temperature is (cooling preset temperature) - (1.33°C) or less after 30 seconds from starting the operation, the operation is done assuming as the preset temperature = (room temperature at the time) - (2°C).
  • Page 43 Dry Powerful Operation (1) Pressing the "POWERFUL" button will reduce the temperature setting by PWSFTSD. (2) The powerful operation is for 20 minutes after setting. (3) Operation is continued forcibly thermo-ON for 20 minutes after the powerful operation is finished. (4) Pressing the "START/STOP"...
  • Page 44 set temp. ksrmonw_8u set temp. +oftmpw_8u set temp. +0.66 set temp. fzontmw1_8u/fzontmw2_8 Start Stop Stop Start start/stop switch fan speed set to "auto" Super HI control bu IDU exchanger control bu IDU exchanger indoor temperature temperature Silent Ultra-LO Themo off Thermo judgment Preheating judgment Operation lamp...
  • Page 45 Setting Defrosting Inhibit Period dftim2_std_8u dftim3_std_8u dftim1_std_8u Outdoor temperature – 1 0 – 5˚C ˚C Notes: The first inhibit time after operation start is set to DFTIM_FST. From the second time onwards, the inhibit time is set according to the time required for defrosting.
  • Page 46 Super Hi Same as Basic Heating operation (1) Pressing the "POWERFUL" button will increase the temperature setting by PWSFTW. STARCPIL (2) The powerful operation is for 20 minutes after setting. (3) Operation is continued forcibly thermo-ON for 20 minutes after the powerful operation is finished. (4) Defrost is inhibited for 20 minutes after the start of the powerful operation.
  • Page 47 Reversing valve defrosting ECO button 15' or more Auto fresh defrosting Over defrosting inhibit period Cooling:0.66 Dehumidifying:0.66 Fan speed Stop set to "Hi" Start/Stop button Set temperature Defrost signal Heating:0.66 Preheating released Preheating released Preheating judgment Preheating Indoor fan Current restrict Ultra-Lo Outdoor fan control by ODU temperature and compressor speed...
  • Page 48 Frost wash Cooling、Heating、 Frost wash operation Dehumdify operation Defrosting period Fan period 1 Blance period Frost period Heating period 1 Stop period 1 Heating period 2 Stop period 2 Fan period 2 frzcl n_blnce_tm clntim_def1 clntim_suf1_frz1 clntim_wam1_frz1 clntim_stp1_frz1 clntim_wam2_frz1 clntim_stp2_frz1 clntim_suf2_frz1 ※1 (AUTO) frzcln_souf1_tm...
  • Page 49 MODEL RAK-VJ18/25/35PHAE EVAPORATOR SINGLE-ENDED UNION(3/8") SERVICE VALVE(1/4") SERVICE VALVE(3/8") SINGLE-ENDED UNION(1/4") EVAPORATOR SINGLE-ENDED UNION(3/8") SERVICE VALVE(1/4") SERVICE VALVE(3/8") SINGLE-ENDED UNION(1/4") - 49 -...
  • Page 50 MODEL RAK-VJ/42/50PHAE EVAPORATOR SINGLE-ENDED UNION(1/2) SERVICE VALVE(1/4") SERVICE VALVE(3/8") SINGLE-ENDED UNION(1/4") EVAPORATOR SINGLE-ENDED UNION(1/2") SERVICE VALVE(1/4") SERVICE VALVE(3/8") SINGLE-ENDED UNION(1/4") - 50 -...
  • Page 51: Procedure For Disassembly And Reassembly

    Procedure for Disassembly and Reassembly RAK-VJ18/25/35/42/50PHAE INDOOR UNIT 1. Front Panel (3)Pull the support hook at the upper side of the indication lamp of the indicating P.W.B. and pull Be sure to hold the front panel with both hands to out the P.W.B.
  • Page 52 (3)Pull fan motor out of the remove the right. Points for attention of fan motor and tangential air flow fan installation. When installing the flow fan,the first part of the fan and water seal plate on the tube plate overlap, then tighten the screw.
  • Page 53: Human Sensor

    B: stepping motor for vertical deflector Push the claws on the M-COVER and take out the M-COVER from the CABINET.(2 places) Push the claws on the ION-COVER and take out the Ionizer from the ION-COVER.(2 places) Push the claws on the M-COVER and take out the STEP-MOTOR from the M-COVER.
  • Page 54: Description Of Main Circuit Operation

    DESCRIPTION OF MAIN CIRCUIT OPERATION MODEL RAK-VJ18/25/35/42/50PHAE ・ ・ The oscillation frequency is a fixed value of 67kHz when tha air condition operation, but it changes in voltage peak depending on power load. In the standby state, the oscillation frequency is also 67kHz, but there are some periods that stops switching acting, which can reduce the total loss to reduce the power.] ・...
  • Page 55 2. Stepping motor drive circuit Microcomputer CN18 Left-right louver, right Left-right louver, right Left-right louver, right Left-right louver, right Left-right motor 1 CN19 Left-right louver, left Left-right louver, left Left-right louver, left Left-right louver, left Left-right motor 2 Up-down flap Up-down flap Up-down flap Up-down flap...
  • Page 56 3. Drive circuit of the indoor fan motor Fig. 3-1 < The circuit check (For test) > < Pin 6 - Pin 4 voltage one example > Name Test point Test voltage 1300min - Motor drive power About 325V CN2 1 pin- 4 pin About 15V Motor contorl power CN2 5 pin- 4 pin...
  • Page 57 Caution The indoor fan motor and drive circuit are connected to the primary power supply. They therefore have voltage to ground. Guard against electric shocks. Caution While the product is energized, do not under any circumstances detach or reattach a connector. Any such practice would cause a high voltage to run, resulting in the indoor fan motor and board circuit being destroyed.
  • Page 58 R536 R535 7. Temporary Switch Circuit MICROCOMPUTER Temporary switch R672 TEMPORARY SW SW831 Fig. 7-1 The temporary switch is used to operate the air conditioner temporarily when the wireless remote control is lost or faulty. The air conditioner operates in the previous mode at the previously set temperature. However, when the power switch is set to OFF, it starts automatic operation.
  • Page 59: Humidity Sensor Circuit

    9. Heat Exchanger Thermistor Circuit Heat exchanger temperature is noticed inside the room (1) Preheating (2) Low-temperature defrosts at cooling and dehumidification operation time. (3) Not working of reversing valve or detection of opening of heat exchanger thermistor is controlled. (4) The microcomputer will estimated the pressure of the compressor due to the intermediate temperature of the IDU heat exchanger.
  • Page 60 11. Indoor/outdoor communication circuits Indoor unit side Outdoor unit side Inverter circuit Outdoor C302 microcomputer Indoor transmission circuit Indoor microcomputer Outdoor Indoor/outdoor communication Outdoor reception chopper output (30kHz) R343 reception circuit input Indoor transmission output 66 Outdoor transmission circuit Outdoor transmission output Indoor reception input 65...
  • Page 61 R606 C610 CN70 - 61 -...
  • Page 62 R512 R511 Fig.13-1 Fig.13-1 Fig.13-2 - 62 -...
  • Page 63 14.Ionizer circuit Warning! Pay attention to high voltage Applied high voltage (about -4.7kV) Never measure or touch it. It's very dangerous. The high voltage generator will apply a voltage of about - 4.7kv. The high-voltage generator is operated through the remote control. Under the condition of setting "AQtiv-Ion"...
  • Page 64: Service Call Q&A

    SERVICE CALL Q&A MODEL RAK-VJ18/25/35/42/50PHAE Cold air comes out during a To improve the dehumidification efficiency performs dehumidifying operation. quiet fan operation. Therefore the air is cold and it is not a malfunction..- 64 -...
  • Page 65 Frost Wash - 65 -...
  • Page 66 STRUCTURE OF AN INDOOR UNIT ELECTRIC PARTS RAK-VJ18/25/35/42/50PHAE FIXTURE SCREW ELECTRIC A L. COVER FIXTURE SCREW FIXTURE SCREW Removing electrical parts 1. Remove the electrical parts cover. Remove the connectors from the CN2, CN4, CN7A, CN12, CN14, CN16, CN17, CN18, CN19,CN70. Control P.W.B.
  • Page 67: Other Instructions

    Other instructions 1 Detaching and reattaching the receptacles for tab terminal All the receptacles for connecting tab terminals are with a locking mechanism. orcibly pulling any such receptacle without unlocking it will destroy it. Be on guard. When reconnecting it, insert it securely all the way home. ・Receptacle types and how to unlock them Mild resin cover Cancel button...
  • Page 68: Troubleshooting Support

    Troubleshooting support unction Self-diagnosis display ・The failure mode detected on the indoor unit side is displayed by Display on the indoor blinking the "timer lamp". And a failure detected on the outdoor unit side unit side will be indicated by the "time lamp" blinking 4 times. ・If the outdoor unit side detects a failure, the product will first conduct several operation retrials.
  • Page 69 Self-diagnosis display function (indoor side display) While the "timer lamp" , of the indoor unit is blinking, troubleshoot the product while referring to the table below. 1. How to count the lamp blinking frequency [An example of 5-time blinking] ・ The product will repeat blinking with 2-second 2-second 2-second intermissions.
  • Page 70 with checking the ERROR CODE INFO MATION <HOW TO DISPLAY ERROR CODE > 1.Press three key ( [On Timer] + [Fan Speed] + [Reset] ) button on the remote control for 5 seconds to avoid access by User. 2. Press “ ”...
  • Page 71 LD301 TIMER LAMP BLINKING CODE MEANING BLINKING Normal Refrigerant cycle fault 1 time 2 times Outdoor unit is under forced operation Communication error (indoor) 3 times 9 times 9 times Indoor thermistor defective 10 times Abnormal rotating numbers of DC fan motor 12 times 9 times Communication error (outdoor)
  • Page 72 MEANING OPERATION LAMP BLINKING CODE (THE FOLLOW DEFECTIVES IN OUTDOOR UNIT) 2 times Peak current cut 3 times Compressor abnormal low speed rotation 4 times Compressor switching failure 5 times Overload lower limit cut 6 times OH thermistor temperature rise 7 times Abnormal outdoor thermistor 9 times...
  • Page 73 At ODU PCBA error or compressor error. This function can be done after power supply off, and on. HHRC LCD display Layer1 Layer2 Layer3 Category Function Name Value Category Function Value request Display ODU Diagnosis Self-check resulrt eserve Layer 1 Layer 2 Layer 3 (category selection)
  • Page 74 Forced cooling operation (Only single connection) The cooling operation can be forcibly performed for collecting refrigerant and inspecting failures. Do not perform the forced cooling operation continuously for long hours, because the compressor continues to be in operational status, regardless of room temperature. <How to start the operation>...
  • Page 75 How to set up from Service setting mode The Service function, which was set by DIP-SW setting or double pressing of the HHRC in the current model. it will be done by HHRC in GRAC as shown as below. 「On �mer」+ 「Fan speed」 +「Reset」 ( Press three Key for 5 seconds to avoid access by User ) All icon ON for 2 Seconds ENTRY...
  • Page 76: Installation

    How to operate the HHRC method Temp△▽ : Selection (in the same layer) Mode : move to previous layer Fan Speed  : Move to next layer ON/OFF : Decision/Send (at layer 3) : Current setting check(at layer 2) Filter: category initialization(at layer 1) Filter + ON/OFF: all category initialization(at layer 1) ※ To exit from this setting mode, you need to either not operate the HHRC panel for 30 seconds or press and hold the UP/Down key for 5 seconds. Layer 2 Layer 3 Layer 1 (Function selection) (Setting select) (category selection) 01:Disable A0:Cardkey 1A:installation 02: Input ‐A Enable A1:・・・ 03:Input ‐B Enable 2C:・・・ A2:・・・ 3d:・・・ - 76 -...
  • Page 77 Service setting item used for GRAC Standard(Wireless remote model:RC-AGS1EA0E) Display on LCD Temperature 7 segment Layer Category Function Wise Value setting meaning at Layer-3 1 - Card Key Input - Disable 2 – Contact A Enable Card Key 3 – Contact B Enable 04-99 4~99 : Reserved 1 - Normal Mode...
  • Page 78 Service setting item used for GRAC Standard(Wireless remote model:RC-AGS1EA0E) Temperature Resolution 1 -0.5 °C Resolution change 2-1 °C Resolution - 0.5°C--> 1°C Fan Speed key 1 - Default ( Auto-Silent-Low-Med-Hi-H2) sequence 2- Reverse ( Hi2-Hi-Med-Lo-Silent-Auto) ( Weaker to stronger , 1-Disable Selection on HHRC by Mode key Operation Mode : Auto 2 - Enable Selection on HHRC by Mode Key...
  • Page 79 Check of current service setting (shift value adjustment of setting temperature(Cool Mode)example) press on/off button toward IDU, IDU LED will show current setting by blinking. with showing “E1” at Layer 2 (to show Layer 3 setting contents by blinking times) (IDU buzzer: “Pi”) Layer 2 (Function selection)
  • Page 80 Buzzer sounding for showing error contents 【Purpose】 Reduction of “mis‐communication about error contents" at contacting the service call center. 【Function】 Add buzzer sounding for showing error contents during error, in addition to IDU LED action . 【How to use】 When IDU or ODU has failed, and the Timer lamp is blinking. Service engineer can know error contents from the buzzer through phone. 「Up/Down」...
  • Page 81: Display Mode

    OTHER SETTING  ID SELECTION Press “Up/Down swing button” and “set. Temp. up button” and “reset button”, and release “reset button”. Select from A or B by pressing “set.temp. button”. Press “On/Off button” toward IDU. (EEPROM in HHRC will keep the A or B information.)  DISPLAY MODE Press “On Timer button” and “On/Off button” and “reset button”, and release “reset button”. Fan speed icon(         ) on LCD will blink. Press “On/Off button” toward IDU. Switching ℃ or ℉ FAN SPEED+TEMP↑+RESET - 81 -...
  • Page 82 - 82 -...
  • Page 83 Diagnosis and troubleshooting of indoor electric parts Initiating troubleshooting Are the "timer lamp" of the indoor unit Perform troubleshooting according to the blinking? self-diagnosis display. The product will begin to run in response to a remote control setting: "cooling mode, temperature setting 16 "...
  • Page 84 Checking the indoor unit electrical parts Introduction First check the failure phenomenon and status, and then move on to elaborate diagnosis. Initiating troubleshooting How many times does the time lamp Is the "timer lamp" of the indoor unit blinking? blinding not 4 times 4 times time lamp blinking,...
  • Page 85 ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ WR006-WR002? - 85 -...
  • Page 86 2.Failure phenomenon: The product will not receive a remote control signal. Situation The product does not receive a remote control signal. It is not very responsive. (The product does run normally in response to the emergency operation switch.) Estimated failure ・...
  • Page 87 How to identify sources of jamming in the reception of remote control signals [ Situation ] The product may become poorly responsive to remote control signals due to external factors even though the product itself is trouble-free. [ Estimating sources of jamming ] Identify the installation status of the air-conditioner and the indoor and outdoor environments to identify possible causes of the jamming.
  • Page 88 Effects of other Checking points electrical products ・Check the effects of light and power noises coming from other electrical products. ・Turn on and off the electrical products, turn off the power and turn on the power, and check their effects on the reception of remote control signals.
  • Page 89 3. Failure phenomenon: The compressor will not run. [ Situation ] The compressor will not run (the same state as the thermometer turned off), the product receives remote control signals normally. The self-diagnosis lamp (LD301) of the outdoor unit blinks once or becomes turned off. [ Estimated failure locations ] ・Room temperature thermistor, heat exchanger thermistor Microcomputer peripheral circuit ・...
  • Page 90 4. Failure phenomenon: The fan motor will not stop. Situation I have conducted the stop operation on the product by remote control, but the indoor fan motor will not stop. (It stopped about 10 minutes later.) Estimated failure locations ・Indoor fan motor ・Fan motor drive circuit Diagnosis flow Initiating troubleshooting...
  • Page 91 5. Timer lamp blinking: blinking once The timer lamp blinks one time and the product will not operate. [Situation] (This is not a sign of a breakdown.) [Estimated failure locations] ・ Reversing valve defective. ・The refrigerating cycle block gas leakage . 6.
  • Page 92 9. Timer lamp blinking: blinking 9 times [Situation] The timer lamp blinks 9 times and the product will not run. [Estimated failure location] Loose connector, wire break, or short-circuit in the room temperature thermistor, heat exchanger thermistor. [Cautions] Starting the product by remote control will initiate failure detection. (Merely turning on the power will not activate the failure detection function.) [Diagnosis flow] Initiating troubleshooting...
  • Page 93 10. Timer lamp blinking: blinking 10 times [Situation] The timer lamp blinks 10 times and the product will not run. [Estimated failure locations] ・Loose connector or wire break in the indoor fan motor ・ Indoor fan motor mechanically locked ・ ・Indoor fan motor ・Indoor fan motor drive circuit [Diagnosis flow]...
  • Page 94 11. Timer lamp blinking: blinking 12 times [Situation] The timer blinks 12 times and the product will not run. [Estimated failure locations] Erroneous connection in the indoor-outdoor connection line (F cable) Wire break or poor insertion of the indoor-outdoor connection line (F cable) Electrical parts in the outdoor unit (communication circuit, power circuit error) Communication error due to noise in other home electronics This does not constitute a failure in the air-conditioner...
  • Page 95 RAK-VJ18/25/35/42/50PHAE - 95 -...
  • Page 96 HHAW PARTS NO Q'TY/U PARTS NAME RAK-VJ18PHAE RAK-VJ25PHAE RAK-VJ35PHAE RAK-VJ42PHAE RAK-VJ50PHAE HWRAK-VJ18PHAE CABINET ASS'Y HWRAK-VJ18PHAE VERTICAL AIR DEFLECTOR HWRAK-DJ18PHAE HWRAK-DJ50PHAE FAN MOTOR HWRAK-DJ18PHAE TANGENTIAL AIR FLOW FAN HWRAK-18PED FAN SUPPORT ASS'Y HWRAK-DJ18PHAE FAN MOTOR SUPPORT-R HWRAK-DJ18PHAE FAN MOTOR SUPPORT-L HWRAK-VJ18PHAE...
  • Page 97 JCH-WH NO.0147E RAK-VJ18PHAE RAK-VJ25PHAE RAK-VJ35PHAE RAK-VJ42PHAE RAK-VJ50PHAE - 97 -...
