Summary of Contents for Yaesu FT-3165R
- Page 1 FT-3165R FT-3165E Operating Manual VHF FM TRANSCEIVER DIAL...
-
Page 2: Table Of Contents
Memory Operation ........24 Memory Storage ............24 Introduction ............ 2 Split Memory ............24 New Features of the Yaesu FT-3165R/FT-3165E ..2 Naming a Memory Channel ........24 Other Features ............2 Memory Recall............25 Accessories & Options ......... 3 Memory Recall from the Microphone Keypad .. -
Page 3: Ft-3165R/E Quick Reference Guide
FT-3165R/E Quick Reference Guide VOL Knob Frequency DIAL Knob Adjusts the audio Selects the operating Frequency. volume level. DIAL Power Switch Press and hold for one second. Transmission Switch Speak into the microphone in a normal voice level while Microphone pressing this switch. -
Page 4: Introduction
S-Meter, thus reduc- ing guesswork in setting the squelch threshold. Congratulations on your purchase of the FT-3165R/E. Whether this is your first rig, or if Yaesu equipment is already the backbone of your station, the Yaesu organization is com- mitted to ensuring your enjoyment of this high-performance transceiver. -
Page 5: Accessories & Options
Accessories & Options Supplied Accessories DTMF Microphone Mobile Mounting Bracket DC power cable w/Fuse SSM-85D (Attachment screw set) Operating Manual Spare fuse (25 A) USB cable (20 A, European version) Optional Accessories DTMF Microphone (equivalent to the supplied microphone) SSM-85D Microphone MH-42C6J Audio Signal Processing Unit... -
Page 6: Safety Precautions (Be Sure To Read)
Be sure to read these important precautions, and use this product safely. Yaesu is not liable for any failures or problems caused by the use or misuse of this product by the purchaser or any third party. Also, Yaesu is not liable for damages caused through the use of this product by the purchaser or any third party, except in cases where ordered to pay damages under the laws. - Page 7 Never cut off the fuse holder of the DC power When transmitting, keep the antenna at least 1.8m cord. away from your body. Do not use modified or dam- This may cause short-circuiting and result in ignition aged antennas. and fire. RF Exposure: This devise should be operated with a minimum separation distance of 20cm (8 inches) Do not use fuses other than those specified.
-
Page 8: Installation
Coaxial cable plug Mobile Installation The FT-3165R/E must only be installed in vehicles having a 13.8 Volt negative ground electrical system. Mount the transceiver where the display, controls, and microphone are easily accessible, using the supplied mounting bracket. -
Page 9: Power Connection
Warning! Never apply AC power to the power cable of the FT-3165R/E, nor DC voltage greater than 15.8 Volts. When replacing the fuse, only use a 25-A (20-A, European version) fuse. Failure to observe these safety precautions will void the Limited Warranty on this product. -
Page 10: Base Station Installation
Installation Base Station Installation The FT-3165R/E is ideal for base station use as well as in mobile installations. The FT- 3165R/E is specifically designed to integrate into your station easily, using the following information as a reference. AC Power Supplies Operation of the FT-3165R/E from an AC line requires a power source capable of provid- ing at least 20 Amps continuously at 13.8 Volts DC. -
Page 11: Front Panel Controls & Switches
Front Panel Controls & Switches Front Panel DIAL VOL knob Rotate the knob to adjust the audio volume level. S-DX (Super DX) indicator Lights white when the Super DX function is in operation. (When the optional Audio Signal Processing Unit SPU-1 is installed, the indicator Lights blue when the “Super DX function”... -
Page 12: Lcd Display
Front Panel Controls & Switches This key instigates tuning in 1MHz steps (the MHz digits will blink on the display). Press and hold this key in for over one second to activate the Setup (Menu) Mode. Press this key briefly to switch between VFO mode and memory mode. Press and hold the key for over one second to display the memory registration screen. -
Page 13: Microphone Switches
Microphone Switches Microphone (SSM-85D) Speak into the microphone during transmission. TX LED Lights red while pressing PTT switch. Press and hold the PTT switch to transmit, and release it to receive. Press this key during the set mode to exit the set mode. -
Page 14: Rear Panel Connectors
DATA Jack Use this jack when updating the firmware. When a new firmware update for the FT- 3165R/E is available, go to the YAESU website to download the programming data and update the FT-3165R/E to its newest state. Cooling Fan... -
Page 15: Basic Operation
Note: A special “RF Squelch” feature is provided on this transceiver. This feature al- lows setting the squelch so that only signals exceeding a certain S-meter level will open the squelch. For details, refer to the Advanced Manual (download from the Yaesu website). Lock Feature To activate the key-lock feature, press the key. -
Page 16: Frequency Navigation
Basic Operation Frequency Navigation Using the Dial Rotating the DIAL knob allows tuning in the pre-programmed steps. Clockwise rotation tunes the frequency upwards, whereas coun- DIAL terclockwise rotation tunes the frequency downwards. key momentarily, and then rotate the DIAL knob, to change the frequency Press the steps to 1MHz per step. -
Page 17: Transmission
The sensitivity (gain) of the microphone can be adjusted. For details, refer to the Advanced Man- ual (download from the Yaesu website). 3. Release PTT. The BUSY/TX indicator turns OFF and the transceiver returns to the receive mode. -
Page 18: Repeater Operation
[ P4 ] key, and use the PTT for activating the transmitter thereafter. To access the repeaters which require a 1750Hz burst tone with the FT-3165R (USA/Asian versions), the program key on the microphone may be used to serve as the “T CALL” key instead. -
Page 19: Advanced Operation
The voice can be brought out to produce clearer, easier-to- listen sound quality. Even weak signals that were previously inaudible due to noise can now be received clearly. *Refer to the Advanced Manual (download from the Yaesu website) for installation of the SPU-1. Indicator... -
Page 20: Priority Channel Scanning (Dual Watch)
Priority channel. 5. Now set the FT-3165R/E for operation on another memory channel, Home channel, or on a VFO frequency. 6. Press the program key of the microphone to which “DW” function is assigned. The display will remain on the VFO, the selected memory channel, or the Home channel, but every 5 seconds the FT-3165R/E will check the Priority Channel for activity. -
Page 21: Programming The Key Assignments
Advanced Operation Programming the Key Assignments Default FT-3165R/E key functions have been assigned to the Microphone [P1]/[P2]/[P3]/ [P4] keys at the factory. The user may change these key function assignments, if quick access to another function is desired. Note: The default setting: [P1] - SQL OFF... -
Page 22: Ctcss Operation
When the CTCSS tone being transmitted by another station is not known, you can tune the transceiver to the incoming signal and activate tone scan to search for and identify the tone being used. Note: For details, refer to the Advanced Manual (download from the Yaesu website). -
Page 23: Dcs Operation
Advanced Operation DCS Operation FT-3165R/E is equipped with a DCS (Digital Coded Squelch) function that allows audio to be heard only when signals containing the corresponding DCS code are received. By matching the DCS code with the partner stations beforehand, a quiet receive standby is possible. -
Page 24: Weather Broadcast Reception
Advanced Operation Weather Broadcast Reception The FT-3165R/E includes a unique feature which allows reception of weather broadcasts in the 160MHz frequency range. Ten standard Weather Broadcast channels are preload- ed into a special memory bank. To listen to a Weather Broadcast Channel (Example: When “WX” is assigned to [ P4 ] ): 1. -
Page 25: Epcs (Enhanced Paging & Code Squelch) Operation
Note: For details, refer to the Advanced Manual (download from the Yaesu website). Split Tone Operation The FT-3165R/E can be operated in a “Split Tone” configuration that enables operation on repeaters using a mix of both CTCSS and DCS control via the Setup menu. -
Page 26: Memory Operation
Memory Operation The FT-3165R/E provides a wide variety of memory system resources. These include: r 199 “basic” memory channels, numbered “1” through “199”. r A “Home” channel, providing storage and quick recall of one prime frequency. r 10 sets of band-edge memories, also known as “Programmable Memory Scan” chan- nels, labeled “L0/U0”... -
Page 27: Memory Recall
3. Press the key, the data will now have been copied to the VFO. Note: For details, refer to the Advanced Manual (download from the Yaesu website). Memory Only Mode Once memory channel programming has been completed, you may place the transceiver in a “Memory Only”... -
Page 28: Masking Memories
Memory Operation Masking Memories There may be situations where you want to “Mask” memories so they are not visible during memory selection or scanning. (except for Memory Channel “1”, the Priority Chan- nel, and the Home Channel). 1. In the Memory Recall mode, press and hold key for one second, then rotate the DIAL knob to select the memory channel DIAL... -
Page 29: Scanning
Scan Resume Options Select which of the three resume scan modes is to be performed after the scanning stops. Note: For details, refer to the Advanced Manual (download from the Yaesu website). Memory Skip Scanning Memory channels which you do not want to receive can be skipped during scanning. -
Page 30: Miscellaneous Settings
Note: See Setup Menu Item “39 TEMP” on page 31. Band Edge Beeper The FT-3165R/E will automatically “beep” when the receiver’s band edge is encountered during scanning (either in standard VFO scanning or during PMS operation). You may additionally enable this feature (band edge beeper) when the frequency reaches the band edge while selecting the VFO frequency manually, using the DIAL knob. -
Page 31: Reset Procedure/Clone
(press any other key to cancel the Reset procedure). Clone The FT-3165R/E includes a convenient “Clone” feature, which allows the memory and configuration data from one transceiver to be transferred to another FT-3165R/E. This can be particularly useful when configuring a number of transceivers for a public service operation. -
Page 32: Setup (Menu) Mode
Setup (Menu) Mode The FT-3165R/E Setup (Menu) mode, already described in parts of many previous chapters, is easy to activate and setup. The Menus may be used to configure many of transceiver parameters, some of which have not been detailed previously. Use the following procedure to activate the Setup (Menu) mode: 1. - Page 33 Setup (Menu) Mode Menu Item Function Available Values Default SQL OFF Programming the function assigned to 16: PGM P1 SQL OFF Microphone [ P1 ] key. HOME WX CH CD SRCH Programming the function assigned to 17: PGM P2 HOME Microphone [ P2 ] key.
-
Page 34: Maintenance
Setup (Menu) Mode Menu Item Function Available Values Default 40: VOLT Indicates the DC Supply Voltage. 41: VER DISP Displays the transceiver software version CPU x.xx Reduction of the Microphone Gain/Devia- 42: WIDTH WIDE/NARROW WIDE tion and receiver bandwidth. Enables/Disables the Weather Alert fea- 43: WX ALERT ON/OFF ture. -
Page 35: Specifications
Specifications General Frequency Range: Tx 144 - 146MHz or 144 - 148MHz Rx 136 - 174MHz Channel Step: 5/6.25/10/12.5/15/20/25/50/100kHz Standard Repeater Shift: ±600kHz Frequency Stability: ±10 ppm [-4°F to +140°F (-20°C to +60°C)] Modes of Emission: F2D, F3E Antenna Impedance: 50 Ohms, unbalanced Supply voltage: 13.8V DC ±15%, negative ground... -
Page 36: Yaesu Limited Warranty
Limited Warranty is valid only in the country/region where this product was originally purchased. On-line Warranty Registration: Thank you for buying YAESU products! We are confident your new radio will serve your needs for many years! Please register your product at www.yaesu.com - Owner’s Corner... - Page 37 YAESU dealer/distributor from whom the product was originally purchased. 2. Include proof of original purchase from an authorized YAESU dealer/distributor, and ship the product, freight prepaid, to the address provided by the YAESU Service Center in your country/ region.
- Page 38 1. Changes or modifications to this device that are not expressly approved by YAESU MUSEN could void the user’s authorization to operate this device. 2. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference including received, interference that may cause undesired operation.
-
Page 39: Declaration Of Conformity
Telephone: (714) 827-7600 EU Declaration of Conformity We, Yaesu Musen Co. Ltd of Tokyo, Japan, hereby declare that this radio equipment FT-3165E is in full compliance with EU Radio Equipment Directive 2014/53/EU. The full text of the Declaration of Conformity for this product is available to view at http://www.yaesu.com/ jp/red ATTENTION –... - Page 40 Copyright 2024 YAESU MUSEN CO., LTD. All rights reserved. No portion of this manual may be reproduced without the permission of YAESU MUSEN CO., LTD. YAESU MUSEN CO., LTD. Omori Bellport Building D-3F 6-26-3 Minami-Oi, Shinagawa-ku, Tokyo, 140-0013, Japan YAESU USA...
