Assembly & Care

Assembly Instructions:

Step 1 - Place the parabolic dish on a soft, clean surface with the open end facing downward.

Step 2 - Install the rear (horizontal) handle "T" bar on the bottom connector with the remaining connectors

pointing outward, and the lettering facing toward the center of the collector dish.

Step 3 - Install the right-hand and left-hand handles by snapping them onto the horizontal "T" bar and the

appropriate dish connectors. (The connectors at the bottom of the handles will point toward the center of

the collector dish.) You may have to rotate the connectors on the dish slightly to get the handles to snap into

place.

Step 4 – Install the microphone into the mic yoke and snug the thumb screw against the mic. If you are using

a lapel microphone, thread the microphone through the adapter tube, snap the microphone into the mic clip,

and then slide the mic clip into the tapered end of the adapter tube. (We suggest wrapping the microphone

cable with the foam and sliding the foam into the opposite end of the adapter tube.)

Page 1

Need help?

Do you have a question about the MiK 26 and is the answer not in the manual?

Page 1 Assembly & Care Assembly Instructions: Step 1 - Place the parabolic dish on a soft, clean surface with the open end facing downward. Step 2 - Install the rear (horizontal) handle "T" bar on the bottom connector with the remaining connectors pointing outward, and the lettering facing toward the center of the collector dish.
Page 2: Handling Instructions
Moving the microphone in or out from the exact focus point can slightly alter the frequency response of the KLOVER MiK. Feel free to experiment with the mic location. You MUST see the printing on the end plates and the mic yoke hub from the front of the dish, AND the arrows on the end plate must point toward the targeting site features on the mic yoke hub.
Page 3: Cleaning Instructions
Troubleshooting: If you are having problems getting audio from your KLOVER MiK 26: 1) Verify that your microphone is facing toward the inside of the dish and located at the focus point.
Page 5 The inside surface of the dish is critical to this product's performance. DO NOT place or store anything inside the dish, or clean the dish with an ammonia- based cleaner.
