  • Page 2 GETTING STARTED GUIDE NI 9210 4-Channel, 14 S/s Aggregate, ±80 mV C Series Temperature Input Module hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 3: Safety Guidelines

    This document explains how to connect to the NI 9210. In this document, the NI 9210 with mini-TC and the NI 9210 with spring terminal are referred to inclusively as the NI 9210. Before you begin, complete the software and...
  • Page 4 60 V DC, Measurement Category I Withstand 1,000 V RMS, verified by a 5 s dielectric withstand test NI 9210 Getting Started Guide | © National Instruments | 3 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 5 Such voltage measurements include signal levels, special equipment, limited-energy parts of equipment, circuits powered by regulated low-voltage sources, and electronics. Do not connect the NI 9210 with mini-TC to Caution signals or use for measurements within Measurement Categories II, III, or IV.
  • Page 6 Do not connect the NI 9210 with spring Caution terminal to signals or use for measurements within Measurement Categories III or IV. NI 9210 Getting Started Guide | © National Instruments | 5 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 7: Safety Guidelines For Hazardous Locations

    Safety Guidelines for Hazardous Locations The NI 9210 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4 Gc and Ex nA IIC T4 Gc hazardous locations; and nonhazardous locations only.
  • Page 8 II 3G and is suitable for use in Zone 2 hazardous locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI 9210 in Gas Group IIC hazardous locations, you must use the device in an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
  • Page 9: Electromagnetic Compatibility Guidelines

    8 | ni.com | NI 9210 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 10 In order to meet the EMC requirements for Caution marine applications, install the product in a shielded NI 9210 Getting Started Guide | © National Instruments | 9 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 11: Preparing The Environment

    EMC performance is attained. Preparing the Environment Ensure that the environment in which you are using the NI 9210 meets the following specifications. Operating temperature -40 °C to 70 °C...
  • Page 12 NI 9210 with Mini TC Pinout NI 9210 Getting Started Guide | © National Instruments | 11 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 13 Table 1. Signal Descriptions Signal Description Common reference connection to isolated ground Thermocouple connection 12 | ni.com | NI 9210 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 14 NI 9210 with Spring Terminal Pinout TC0+ TC0– TC1+ TC1– TC2+ TC2– TC3+ TC3– NI 9210 Getting Started Guide | © National Instruments | 13 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 15: Thermocouple Connections

    A valid common-mode voltage reference is a voltage that is within ±1.5 V of the common-mode voltage of all the connected thermocouples 14 | ni.com | NI 9210 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 16: Minimizing Thermal Gradients

    Allow the thermal gradients to settle after a change in system power or in ambient temperature. A change in system power NI 9210 Getting Started Guide | © National Instruments | 15 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 17 Make sure that devices you connect to the NI 9210 are compatible with the module specifications. • For the NI 9210 with spring terminal, push the wire into the terminal when using a solid wire or a stranded wire with a ferrule.
  • Page 18: Overvoltage Protection

    The NI 9210 provides overvoltage protection for each channel. Refer to the device datasheet on ni.com/manuals Note for more information about overvoltage protection. NI 9210 Getting Started Guide | © National Instruments | 17 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 19: Where To Go Next

    LabVIEW Help RELATED INFORMATION C Series Documentation Services ni.com/services & Resources ni.com/info cseriesdoc Located at ni.com/manuals Installs with the software 18 | ni.com | NI 9210 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 20: Worldwide Support And Services

    If your product supports calibration, you can obtain the calibration certificate for your product at ni.com/calibration. NI 9210 Getting Started Guide | © National Instruments | 19 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 21 For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your software, file on your media, or the National Instruments Patent Notice at patents.txt ni.com/ . You can find information about end-user license agreements (EULAs) and third-party patents legal notices in the readme file for your NI product.
