- Page 1 DOM 6500 Owner’s manual and mounting instruction Mode d’emploi et manuel d’installation Bedienungs- und Einbauanleitung Gebruiksaanwijzing en inbouwhandleiding Istruzioni d’uso e d’installazione Instrucciones de manejo y de montaje Betjeningsvejledning og monteringsanvisning...
- Page 2 INPUT OUTPUT AV1 IN VIDEO AUDIO L/R white / blanche / weiß CONTROL blue / bleu / blau REMOTE 0.25 A max. red / rouge / rot 0.5 A + 12 V yellow / jaune / gelb 12 V black / noir / schwarz 30 °...
- Page 4 Illustrations Page 2 - 3 Installation instructions Page 9 Operating instructions Page 13 Illustrations Pages 2 - 3 Instructions de montage Page 35 Mode d’emploi Page 39 Abbildungen Seiten 2 - 3 Einbauanleitung Seite 61 Bedienungsanleitung Seite 65 Afbeeldingen Pagina’s 2 - 3 Inbouwaanwijzing Pagina 87 Gebruiksaanwijzing...
-
Page 5: Table Of Contents
CONTENTS Contents INSTALLATION INSTRUCTIONS ....... 9 Important Information....... . . 9 Scope of delivery . - Page 6 CONTENTS SETTINGS ......... . 27 Setup Menu .
-
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS Important Information Only trained specialists may install the system. Observe the automotive industry quality standards. Fire hazard. During drilling, be careful not to damage hidden cable harnesses, the fuel tank and fuel lines. Never drill into supporting or safety-relevant chassis parts. It is essential to observe the following when installing components in the passenger compartment: Ensure that the driver has a clear all-round view. -
Page 8: Taking Safety Precautions, Fig. 1
Connect the blue lead to the remote control output for additional devices (e.g. multimedia interface box). Interior lighting (white): The DOM 6500 has two built-in lamps that can be connected to the interior lighting system of the vehicle. Connect the white lead to a suitable connector for the interior lighting. -
Page 9: Installing The Dvd Multimedia System
INSTALLATION INSTRUCTIONS Audio/video output “OUTPUT” Connect the yellow Cinch/RCA plug to a suitable multimedia unit video input. Connect the white and red Cinch/RCA plugs to the left and right Line or AUX inputs of an available audio system. Installing the DVD multimedia system Only trained specialists may install the system. -
Page 10: Preparing The Remote Control
INSTALLATION INSTRUCTIONS Preparing the remote control Inserting the batteries Open the battery compartment on the – back of the remote control. Insert two new AAA size batteries. Pay attention to correct polarity (marked in – the compartment). Close the battery compartment. Initial operation 1. -
Page 11: General Information
GENERAL INFORMATION Features ❏ Folding and swivelling 8-inch TFT-LCD display ❏ Overhead installation ❏ PAL and NTSC DVD / Video CD compatible DVD Player (plays discs recorded in either PAL or NTSC format) ❏ Readable formats: DVD, Video CD, Super Video CD, audio CD, MP3 (CD-ROM) and JPEG image CD ❏... -
Page 12: Important Information For Safe Operation
GENERAL INFORMATION Important information for Copyright protection safe operation This product incorporates copyright protection technology that is protected by For traffic safety reasons, use the DVD method claims of certain U.S. patents and Players’ menus only before starting a journey or other intellectual property rights owned by when the vehicle is stationary. -
Page 13: Disc Notes
DISC NOTES ❏ Dirt, dust, scratches and warping discs Disc formats will cause malfunction. ❏ Do not place stickers or make scratches Supported formats on discs. The following 8 cm and 12 cm discs are ❏ Do not warp discs. supported: ❏... -
Page 14: Controls
CONTROLS 1 ... . Switch for interior lighting 2 ... . Reset button 3 ... . Interior lighting 4 V UP . - Page 15 CONTROLS 1 ... . Headphone socket 1 2 ... . Volume control for headphone socket 1 3 ... . 8-inch TFT display 4 .
-
Page 16: Remote Control
REMOTE CONTROL POWER DISP REPEAT SMART ANGLE ZOOM ENTER SUB-T AUDIO VOL + SETUP TITLE MODE MENU VOL – 1 O POWER . . . Turn multimedia system on / off 2 0 - 9 ..Numeric key buttons 3 SMART . - Page 17 REMOTE CONTROL w VOL - ..Reduce volume... . . In combination with “SEL”: adjusts display settings. e TITLE ..Display the DVD title menu (depending on the DVD disc) r SEL .
-
Page 18: Basic Operation
BASIC OPERATION Switching on/off TFT display To switch on the multimedia system: Opening the display Switch on the ignition. Press the unlocking button for the Press the POWER button on the display and pull the screen carefully multimedia system or the remote downwards. - Page 19 BASIC OPERATION SMART mode TV standard - “TV TYPE” Set the TV standard appropriate to the Press the SMART button on the remote connected AV source. The options are control to activate SMART mode. “AUTO”, “PAL” and “NTSC”. The TFT screen now always displays the picture from the DVD player, regardless Display mode - “DISPLAY MODE”...
-
Page 20: Starting/Stopping Playback
BASIC OPERATION Starting/stopping playback Skipping chapters/tracks Press the S button to stop playback. Press one of the 8 / 2 buttons during playback. The player stores the current disc Press the 8 button to jump to the next position. Press the P button to resume playback chapter (DVD) or track (VCD/CD). -
Page 21: Time Displays
BASIC OPERATION Press DISP for the fourth time: Time displays Press the DISP button during playback to display different time information of the CHAPTER REMAIN current disc on the screen. 00 : 03 : 56 Example: DVD: Press DISP once: The following information is shown on Press DISP for the fifth time: the screen:... -
Page 22: Menu Function
BASIC OPERATION MENU function Selecting subtitle language (DVD only) MENU button Press the SUB-T button once or several Press the MENU button during playback. times during playback to select the The root menu of the DVD is displayed. required language for subtitles. If different menu options are available, move the cursor to the desired menu Notes:... -
Page 23: Advanced Operation
ADVANCED OPERATION WITHOUT MENU MP3 disc playback When the SMART NAV function is set to This player supports the following CD “NO MENU”, only the track (file) number formats for MP3 playback: and the elapsed time for the current file are ❏... -
Page 24: Jpeg Image Cds
ADVANCED OPERATION Next / previous image JPEG image CDs During playback: Press 8 to select the next JPEG file. The DVD player supports the display of JPEG Press 2 to select the previous JPEG file. images. Ensure that the JPEG images have the “.jpg” file extension. -
Page 25: Settings
SETTINGS TV TYPE Setup Menu This player can play discs recorded in either Main page PAL or NTSC format. ❏ Select MULTI format, if the connected In STOP mode: TV supports PAL and NTSC. Press the SETUP button. ❏ Select NTSC format, if the connected TV The initial SETUP menu is displayed. - Page 26 SETTINGS Speaker setup menu Preferences setup menu DOWNMIX AUDIO Select the preferred initial audio This is to select the Dolby AC3 5.1 Downmix soundtrack language from the list. mode for the analog output. If you select LT/RT, the Dolby Digital SUBTITLE signal is converted to a Dolby Surround Select the preferred initial subtitle...
-
Page 27: Maintenance And Care
MAINTENANCE AND CARE Replacing batteries of the remote control You have to replace the batteries of the remote control, if the DVD Player does no longer respond to key presses. Open the battery compartment on the back of the remote control. –... -
Page 28: Troubleshooting
• With the disc removed, press the DISP button. Service If you cannot find a solution to your problem, contact an authorised VDO Dayton service agent or call our Customer Helpdesk. You will find the telephone number for your country on the Internet at: www.vdodayton.com... -
Page 29: Glossary & Internet Links
GLOSSARY & INTERNET LINKS Glossary Digital audio data compressed in MPEG1 Layer 3 Dolby Digital format. MP3 files are approximately ten times smaller than the uncompressed PCM data. Audio compression technology developed by Dolby Laboratories that allows to encode up to 6 channels (Right, Left, Center, Surround Right, On Screen Display. -
Page 30: Internet Links
GLOSSARY & INTERNET LINKS Internet links Video Compact Disc. A world wide standard for If you are interested in further information on digital video on a standard 12 cm CD. The data is DVD, Audio, Video, etc. try out the following stored in MPEG1 format. - Page 31 DOM 6500 IFU 09/2004 ri www.vdodayton.com...
