Lister STAR Manual

Frequently Asked Questions (FAQs)

Which blades are fitted to the STAR Clipper?

• The STAR clipper is fitted with A2F/AC (Fine) Blades as standard

How do I fit the blades to the clipper?

• Firstly, disconnect the clipper from the power source
• Turn the clipper upside down and carefully fit the top blade to the clipper head (the crank roller must be in-between the socket of the top blade)
• Fit the bottom blade, ensuring the two holes are fitting over the comb pegs and pins
• Insert the tension bolt through the central hole
• Fit the tension spring over the tension bolt and screw the tension nut down as far as it will comfortably go
• Set the tension – using the marker on the tension nut as a guide, turn the tension nut back 1½ turns

How do I set the tension?

• Fit the tension spring over the tension bolt and screw the tension nut down as far as it will comfortably go
• Using the marker on the tension nut as a guide, turn the tension nut back 1½ turns

Note: Excessive tension will blunt the and overheat the blades, while insufficient tension will reduce cutting performance and lead to clogged blades.

How and how often should I oil the blades?

• Before oiling, brush any excess hair from the blades, clipper head and clipper
• When in use, we recommend oiling the blades every 5-10 minutes, using Lister R15 Clipper Oil

NOTE: Oil between the cutter points, the surfaces between the clipper head and top blade, the cutter blade guide channel and heel of the cutter blade from both sides or via the two holes and the crank shaft and roller, via the central hole. Frequent oiling will help keep to the blades running smoothly by reducing friction and heat.
Please follow this link, which will show you how to correctly tension and oil your blades:
https://www.youtube.com/watch?v=iqR7QPBIkaY

Which brand of oil should I use with the STAR clipper?

• The STAR clipper should always be oiled with Lister R15 Clipper Oil


NOTE: Other lubricants may cause irritation to the animal's skin or may damage the appliance or blades.

Why won't the blades cut?

There are several reasons why the blades may not be cutting:

• The blades may be blunt and need sharpening
• The blades may have been incorrectly sharpened
• The blades may have been incorrectly tensioned
• The blades may not have been oiled as frequently as recommended
• The incorrect brand of oil may have been used

How do I clean the clipper and blades?

• Wipe the handle of the clipper clean with a soft cloth and use the brush provided to brush away any loose hair or dirt from both the blades and clipper head
• Remove the blades for cleaning – unscrew the tension nut and remove from the clipper, along with the tension spring and tension bolt

NOTE: Care should be taken not to lose the tension nut, tension spring or tension bolt.

• Remove the blades from the clipper head and wipe them clean with a soft cloth
• Oil the blades and wrap them in a clean, soft cloth
• The clipper and blades should always be stored in a clean, dry and safe place (inside the house ideally)
• It is also particularly important to keep the plug and clipper cable clean, dry and in good working order

How do I remove and clean the filter?

• Slide the filter out of the filter socket on the clipper
• Hold the filter up to the light to check the mesh for blockages
• Wash away any dirt and debris, ensuring the filter is clean and dry before refitting to the clipper


NOTE: The filter should be removed and cleaned after every clip.

Where is the reset button on my STAR Clipper?

• The reset button is located at the back of the clipper, under the cable grommet
• To reset the clipper, use the bottom end of brush to press the reset button in


NOTE: The rest button cannot be pressed in using just your finger, as it will not go in far enough.

How often should the STAR Clipper be serviced?

• We recommend sending your clipper in for a service annually

For further information, please refer to the STAR clipper instruction manual.
For more information, support or repairs, please contact the Customer Service department: info@lister-shearing.co.uk
