Inhalt
1
Important Safety Instructions ................................................................ 3
2
Conformity .......................................................................................... 10
3
Montage ............................................................................................. 11
3.1
Stand mounting ......................................................................................... 11
3.2
Wall mounting ........................................................................................... 12
4
Front and Rear Panel Illustration ......................................................... 13
4.1
The Device ................................................................................................ 13
4.2
Connections .............................................................................................. 14
4.3
CI/CI+ Slot ................................................................................................ 15
4.4
Remote Key Function ............................................................................... 17
4.3
Connecting to TV-Signal Input.................................................................. 19
4.3.1
Connection for DVB-T2 reception or cable TV .................................. 19
4.3.2
Connection for Satellite reception ...................................................... 21
5
First installation .................................................................................. 22
5.1
Basic Settings ........................................................................................... 22
5.2
Fernbedienung hinzufügen ....................................................................... 23
5.3
Setup via Android Smartphone ................................................................ 23
5.4
Internet Setup ........................................................................................... 24
Google User Agreement..................................................................................... 25
Location sharing and Android improvements .................................................... 25
5.5
Country Setup ........................................................................................... 26
General Android Password ................................................................................ 26
5.6
Chromecast............................................................................................... 27
5.7
Channel search ......................................................................................... 28
5.8
Satellite Search ......................................................................................... 28
5.9
Antenna settings ....................................................................................... 30
5.10 Cable TV setup ......................................................................................... 31
6
Menu-Settings .................................................................................... 35
6.1
Menu Input ................................................................................................ 35
6.2
Menu Picture ............................................................................................. 36
6.3
Menu Picture mode................................................................................... 38
6.4
Menu Speaker .......................................................................................... 38
6.5
Menu Energy ............................................................................................ 39
6.6
Menu CI-Card ........................................................................................... 39
6.7
Menu Advanced Options .......................................................................... 40
6.8
Menu Settings ........................................................................................... 40
7
Menu Sound ....................................................................................... 41
8
EPG (Electronic Program Guide) ........................................................ 42
9
Troubleshooting .................................................................................. 43
9.1
No sound /No Picture................................................................................ 43
9.2
Error Notes................................................................................................ 44
10 CI+ Information ................................................................................... 46
11 TELETEXT Function Keys .................................................................. 48
12 Selecting the input Source .................................................................. 49
50
DYON SMART 32 AD
V1.1.0
Advertisement
Related Manuals for Dyon SMART 32 AD
Summary of Contents for Dyon SMART 32 AD
-
Page 1: Table Of Contents
DYON SMART 32 AD V1.1.0 Inhalt Important Safety Instructions ..............3 Conformity ..................10 Montage ..................... 11 Stand mounting ..................11 Wall mounting ................... 12 Front and Rear Panel Illustration ............13 The Device ....................13 Connections ....................14 CI/CI+ Slot ....................15 Remote Key Function ................ - Page 2 DYON SMART 32 AD 13 Connecting USB Devices ..............50 14 Specifications ..................51 15 Glossar ....................53 16 Warranty Condition ................54...
-
Page 3: Important Safety Instructions
DYON SMART 32 AD Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, install in accordance with the instructions. - Page 4 DYON SMART 32 AD 13) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
- Page 5 DYON SMART 32 AD The symbol indicates that dangerous voltages constituting a risk of electric shock are present within this unit. The symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit. The symbol indicates that this product incorporates double insulation between hazardous mains voltage and user accessible parts.
- Page 6 DYON SMART 32 AD Caution Do not trap the power supply cord under the television receiver. Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it should fall.
- Page 7 DYON SMART 32 AD Tips regarding environmental protection At the end of its operating life, this product may not be disposed of by way of your normal household waste. Instead it must be delivered to a collection point for recycling electrical and electronic equipment. The icon on the product, in the operating instructions or on the packaging, indicates this.
-
Page 8: Service Address
DYON SMART 32 AD Support URL: http://www.dyonhilfe.de See our website for the latest information on this engine, on other products by our company and on our company itself. If you have questions or problems, please read the FAQs on our website or contact our customer support service support@axdia.de... -
Page 9: Appropriate Use
The manufacturer does not bear any liability for damages caused due to improper use. Visit our homepage (www.dyon.eu) to get more information about DVB-T2 HD in Germany. Caution The device turns off after 4 hours without pressing any key. -
Page 10: Conformity
DYON SMART 32 AD Conformity We, Axdia International GmbH, hereby declare that this device corresponds to the basic requirements and relevant regulations outlined in guidelines 2014/53/EU and 2009/125/EC. The CE declaration of conformity for this product may be found on the following link:... -
Page 11: Montage
DYON SMART 32 AD Montage Stand mounting Fix the feet in the device as described in the picture and fix them with the enclosed mounting screws... -
Page 12: Wall Mounting
DYON SMART 32 AD Wall mounting Fasten your wall bracket to the threads on the back and observe the hole spacing. -
Page 13: Front And Rear Panel Illustration
DYON SMART 32 AD Front and Rear Panel Illustration The Device Remote Sensor and Status indicator Im Stand-By Mode, the status indicator lights up red. Turn the TV on or off... -
Page 14: Connections
DYON SMART 32 AD Connections Connections from left to right and bottom up: 1. ETHERNET 8. RF (C/-T2) Antenna connection 2. Optical Audio Out (S-PDIF) 9. USB-Port (2.0) 3. USB-Port (2.0) 10. HDMI 1 (ARC) 4. HDMI 3 11. CI-Module 5. -
Page 15: Ci/Ci+ Slot
DYON SMART 32 AD CI/CI+ Slot Note: According the CI Slot: Please take care to insert the CI-Module (CAM) in the correct way. The Top side of the module must face against the wall behind. This device is equipped with a CI+ slot for use with cam modules and smart cards which allow for the viewing of encrypted Pay-TV channels. - Page 16 DYON SMART 32 AD Notice Module and smart card are not including in the packaging. Install the CI+ module after the channel scan has been accomplished and all other settings have been set. The activation of the card may take several minutes for the first time it is used.
-
Page 17: Remote Key Function
DYON SMART 32 AD Remote Key Function To switch the set device to on or standby. POWER: Select input source. INPUT: NETFLIX: Open Netflix App. YOUTUBE: Open YouTube App. Used to switch among different SUBTITLE: subtitles that are broadcasted in TV mode. - Page 18 DYON SMART 32 AD Notes on batteries If the remote control is not used for a long period of time, please remove the battery from the compartment. Do not heat batteries or dispose of them in fires. Do not dismantle, deform or modify batteries.
-
Page 19: Connecting To Tv-Signal Input
DYON SMART 32 AD Connecting to TV-Signal Input 4.3.1 Connection for DVB-T2 reception or cable TV Connect the signal cable (e.g. the antenna cable) to theantenna input (RF) on the back of the device. After connection, switch on the device. - Page 20 DYON SMART 32 AD Note on DVB-T Whether and how many transmitters can be received depends on the location of the device and the availability of DVB-T transmitters in this region. DVB-T radio stations are only available in very few regions.
-
Page 21: Connection For Satellite Reception
DYON SMART 32 AD 4.3.2 Connection for Satellite reception Connect the signal cable to the LNB IN input on the rear panel. After connection, switch on the unit. Perform the initial installation or press the Menu button , then press the ▲ button to enter the Channels menu. Now select "new channels available"... -
Page 22: First Installation
DYON SMART 32 AD First installation Note Before you proceed, please make sure that the receiver/antenna cable is connected. Basic Settings This screen is only displayed when the TV is turned on for the first time or reset to the factory default setting. -
Page 23: Fernbedienung Hinzufügen
To activate the Google Assistant Microphone on your remote control, press ◄ and the button simultaneously: You can find the remote control under the name DYON-TV RC in the Bluetooth connection list. Setup via Android Smartphone To make it easier to set up the TV, you can set it up on your... -
Page 24: Internet Setup
DYON SMART 32 AD Then follow the instructions on your TV or Android smartphone. Internet Setup To use functions that require an Internet connection, such as YouTube, Netflix, HbbTV, etc., you can connect your TV to the Internet via LAN or WLAN. If you want to connect via LAN, simply plug an Ethernet cable into the socket of your TV. -
Page 25: Google User Agreement
On the following page you will be asked to read and agree to the Google Terms of Use. This is necessary for the use of the Dyon Smart 32 AD, without this it cannot be used. Location sharing and Android improvements To improve Android, you can give Google access to location and diagnostic data. -
Page 26: Country Setup
DYON SMART 32 AD You will now receive a short introduction to the functions of your Android TV. You can confirm this with OK. Country Setup Please select your country in this selection page. You can select it with the ▲▼ keys and confirm with OK: General Android Password For Android a password is required to avoid unwanted access. -
Page 27: Chromecast
Chromecast If you want to mirror the display of your Android smartphone to your Dyon TV, you can activate Chromecast. The permanent activation offers the advantage that you can do this on your TV at any time without prior activation. -
Page 28: Channel Search
DYON SMART 32 AD Channel search NOTE: If you receive television for private use, DTV is usually the right choice for the reception mode. Then select the reception path available to you. Further settings are usually not necessary. Type of Reception Now select the desired reception mode with the arrow keys ▲... - Page 29 DYON SMART 32 AD Now select General for a complete channel search and choose your desired satellite in the now displayed menu "LNB List" and confirm with Next. Now perform the channel search with a confirmation with OK on the field "Scan".
-
Page 30: Antenna Settings
DYON SMART 32 AD Antenna settings Select Antenna/Cable with the ▼ key and confirm in the next step Antenna. Now perform the channel search with a confirmation with OK on the field "Scan". -
Page 31: Cable Tv Setup
DYON SMART 32 AD Cable TV setup 5.10 Select Antenna/Cable with the ▼ button and confirm Cable in the next step. Now the operator of your cable network must be selected. If the operator is in the predefined list, you can start the search in the next step. - Page 32 DYON SMART 32 AD ATTENTION! Press the EXIT or MENU button to cancel the channel scan. Please note that if you cancel, no stations may be stored and therefore no station picture is displayed. FIRST AID! No station is displayed after the initial installation - Check that the antenna cable is correctly connected to both the junction box and the device.
- Page 33 DYON SMART 32 AD 1) Channel edit: You can delete, move, skip or add programs to your favorites. To do so, please open the menu by pressing the Menu key. Select the settings with ▲ /▼ buttons. 1. Press the MENU button on the remote control.
- Page 34 DYON SMART 32 AD 2) Edit channels: If you want to delete programs, please follow steps 1 and 2 of "Sort Channel“. 3. Choose "Edit Channel" from the Channels menu. 4. Select the channels you want to delete one by one ▲...
-
Page 35: Menu-Settings
DYON SMART 32 AD Menu-Settings Press the Menu Button and/to select a submenu item. Press / to select between TV options, or channels Menu Input In the Input menu you can select the Source. Here you have the choice of TV, Composite, HDMI1 - 3. -
Page 36: Menu Picture
DYON SMART 32 AD Menu Picture The second menu item is the MENU PICTURE. Here you can select different preset image modes, or in user mode, adjust image settings such as contrast, brightness, etc. Press ▲▼ to select a setting, press ◄► to change the setting and OK to confirm. - Page 37 DYON SMART 32 AD Picture Mode Dynamic, Standard, Mild and Personal Contrast Setting 0 - 100 Brightness Setting 0 - 100 Colour Setting 0 - 100 Tint Setting 0 - 100 Sharpness Setting 0 - 100 Color Temp Cold, Normal, Warm...
-
Page 38: Menu Picture Mode
DYON SMART 32 AD Menu Picture mode The third menu item is the MENU Display Mode. Here you can select different predefined display modes. Menu Speaker In the Speakers menu you can set whether the internal speakers or external speakers should be used... -
Page 39: Menu Energy
DYON SMART 32 AD Menu Energy In the fifth Power Supply menu, the items "Sleep timer", "Timer to switch off", "Switch off device when no signal" and "Picture off" can be selected. Standby Timer The Stanby Timer, which is always active... -
Page 40: Menu Advanced Options
DYON SMART 32 AD Menu Advanced Options The seventh menu item is the Advanced Options menu. You can set the language of the audio track and subtitles, as well as settings for HbbTV, Automatic Standby, and Teletext. Press ▲▼ to select a setting, press OK to adjust it, press ▲... -
Page 41: Menu Sound
DYON SMART 32 AD Menu Sound Here you can adjust the sound (only if Sound Style is set to Personal). When Sound Style is set to Personal, press OK, then press ◄► to change the setting and OK to confirm. -
Page 42: Epg (Electronic Program Guide)
DYON SMART 32 AD EPG (Electronic Program Guide) Press the EPG button to display the electronic program guide of the active station. You will find the daily program below. Green Button Press the Green Button to show next Day. ▲▼►◄... -
Page 43: Troubleshooting
DYON SMART 32 AD Troubleshooting No sound /No Picture Trouble phenomenon Symptom Inspection Check Picture Audio antenna position, direction Snow Noise or connection antenna position, direction or connection Ghost Normal audio electronic equipment,car/ Interfere Noise motorcycle,fluorescent light Volume(check if mute is... -
Page 44: Error Notes
DYON SMART 32 AD Problem Potential Reasons What to do Remote The battery is Change new battery control exhausted unit is not Remote control Adjust the way of workable unit is not holding Problem in the right remote control unit... - Page 45 DYON SMART 32 AD - Check the input source using the SOURCE button. The reception is - Check the antenna disturbed, the antenna cable. cable is not - In TV mode, press the connected, an unused OK button to check if...
-
Page 46: Ci+ Information
DYON SMART 32 AD 10 CI+ Information The TV set contains a Common Interface CI+ Slot. Different CAM cards with smart card reader can be found at local dealers for different Pay-TV provider. • Set in: Turn off the TV. Now insert the module. - Page 47 DYON SMART 32 AD Important: Menu options and existing setting points depend on the CI+ module you are using. The CI+ module (not included in the scope of delivery) is necessary to be able to receive encrypted stations using a smart card (not supplied).
-
Page 48: Teletext Function Keys
DYON SMART 32 AD 11 TELETEXT Function Keys Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language(cable networks, satellite channels, etc.) -
Page 49: Selecting The Input Source
DYON SMART 32 AD 12 Selecting the input Source This unit includes a variety of input sources, which can be selected and selected using the SOURCE button on the TV or on the remote control. Press INPUT to enter the input source menu, the following screen appears: Navigation buttons ▲... -
Page 50: Connecting Usb Devices
DYON SMART 32 AD 13 Connecting USB Devices This device is equipped with a USB port to update the software and to play media files, see figure below: Please connect USB media directly to the USB interface of the device. -
Page 51: Specifications
DYON SMART 32 AD 14 Specifications Frequency Range 48.25MHz ~ 863.25MHz 75Ω Input impedance PAL, SECAM Video System Sound System BG, DK, I, L/L' NICAM/A2 (PAL, SECAM) 1000Pages Teletext Max. Number of 99CH channels VHF (50MHz ~ 230 MHz) Frequency Range UHF (474MHz ~ 862 MHz) 75Ω... - Page 52 DYON SMART 32 AD Important Notice The above information about the power consumption will be valid till the end of February 2021. Based on updated European Directives please refer to the below information afterwards. Product information about the energy efficiency of this device according to EU...
-
Page 53: Glossar
DYON SMART 32 AD 15 Glossar DiSEqC Digital Satellite Equipment Control Digital system, with which the receiver can control different components of the external unit. It is especially used for selecting from multiple satellite positions (for example Astra and Eutelsat). -
Page 54: Warranty Condition
We offer a warranty on our products in accordance with the following conditions: 1. DYON products are covered by a 12 month warranty. We will resolve damages or defects on DYON products free of charge within 12 months of the purchase date under the following warranty conditions. - Page 55 DYON SMART 32 AD IMPORTANT: AXDIA will only accept parcels that have an RMA number. Please observe the following when sending the product: 1. Send the product suitably packaged with carriage and insurance paid. Do not enclose any accessories with the products (no cables, CD's, memory cards, manuals, etc.), unless the AXDIA Service Centre specifies otherwise.
