Refrigerator
User manual
Free Standing Appliance
Untitled-10 1
2020-01-09 PM 4:43:41

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RF24BB6200QL/AA-00 and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung RF24BB6200QL/AA-00

Summary of Contents for Samsung RF24BB6200QL/AA-00

  • Page 1 Refrigerator User manual Free Standing Appliance Untitled-10 1 2020-01-09 PM 4:43:41...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about the safety instructions Important safety symbols and precautions: Important safety precautions Severe warning signs for transportation and site Critical installation warnings Installation cautions Critical usage warnings Usage cautions Cleaning cautions Critical disposal warnings Additional tips for proper usage Instructions about the WEEE Installation...

  • Page 3: Safety Information

    Safety information Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efficiently. What you need to know about the safety instructions •...

  • Page 4: Important Safety Symbols And Precautions

    Safety information • Refrigerant squirting out of the pipes could ignite or cause an eye injury. When refrigerant leaks from the pipe, avoid any naked flames and move anything flammable away from the product and ventilate the room immediately. - Failing to do so may result in fire or explosion. Important safety symbols and precautions: Please follow all safety instructions in this manual.

  • Page 5: Important Safety Precautions

    Important safety precautions Warning; Risk of fire / flammable materials WARNING • When positioning the appliance, ensure the supply cord is not trapped or damaged. • Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. •...
  • Page 6 • If the product is equipped with LED lamps, do not disassemble the Lamp Covers and LED lamps yourself. - Contact a Samsung service center. - Use only the LED Lamps provided by the manufacturer or its service agents.
  • Page 7 How to minimize the energy consumption • Install the appliance in a cool, dry room with adequate ventilation. • Ensure that it is not exposed to direct sunlight and never put it near a direct source of heat (radiator, for example). - Not to block any vents or grilles is recommended for energy efficiency.

  • Page 8: Severe Warning Signs For Transportation And Site

    Safety information This appliance is intended to be used in household and similar applications such as - staff kitchen areas in shops, offices and other working environments; - farm houses and by clients in hotels, motels and other residential type environments; - bed and breakfast type environments;...

  • Page 9: Critical Installation Warnings

    Critical installation warnings WARNING • Do not install the refrigerator in a damp location or place where it may come in contact with water. - Deteriorated insulation on electrical parts may cause an electric shock or fire. • Do not place this refrigerator in direct sunlight or expose it to the heat from stoves, room heaters, or other appliances.
  • Page 10 - Deteriorated insulation of electrical parts may cause an electric shock or fire. • If any dust or water is in the refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of fire. English...
  • Page 11 • Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in an electric shock, fire, problems with the product, or injury. •...

  • Page 12: Installation Cautions

    Safety information Installation cautions CAUTION • Allow sufficient space around the refrigerator and install it on a flat surface. - If your refrigerator is not level, cooling efficiency and durability can be declined. • Allow the appliance to stand for 2-3 hours before loading foods after installation and turning on.
  • Page 13 • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center. • If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center.
  • Page 14 Safety information • Do not let children step on a drawer. - The drawer may break and cause them to slip. • Do not leave the doors of the refrigerator open while the refrigerator is unattended and do not let children enter inside the refrigerator.
  • Page 15 • Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may result in an electric shock, fire, problems with the product, or injury. Do not put a container filled with water on the appliance.
  • Page 16 - Failing to do so may result in an electric shock, fire, problems with the product, or injury. • If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or fire hazards.

  • Page 17: Usage Cautions

    Usage cautions CAUTION • Do not refreeze thawed food. - Frozen and thawed food will develop harmful bacteria faster than fresh. - The second thaw will break down even more cells, leaching out moisture and changing the integrity of the product. •...
  • Page 18 - Any changes or modifications performed by a 3rd party on this finished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modifications. • Do not block the air vents inside the refrigerator.
  • Page 19 • Fill the water tank and ice cube trays with potable water only (tap water, mineral water, or purified water). - Do not fill the tank with tea or a sports drink. This may damage the refrigerator. • Be careful that your fingers are not caught in. •...

  • Page 20: Cleaning Cautions

    Safety information Cleaning cautions CAUTION • Do not spray water directly on the inside or outside the refrigerator. - There is a risk of fire or electric shock. • Do not use a hair dryer to dry the inside of the refrigerator. •...
  • Page 21 • Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, flammable fluids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets. - These can scratch or damage the material.

  • Page 22: Critical Disposal Warnings

    Safety information Critical disposal warnings WARNING • Please dispose of the packaging material from this product in an environmentally friendly manner. • Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal. • R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator.

  • Page 23: Additional Tips For Proper Usage

    Additional tips for proper usage • In the event of a power failure, call the local office of your electric company and ask how long the failure is going to last. - Most power failures that are corrected in an hour or two will not affect your refrigerator temperatures.

  • Page 24: Instructions About The Weee

    This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product specific regulatory obligations e.g. REACH, WEEE, Batteries, visit our sustainability page available via Samsung.com...

  • Page 25: Installation

    Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING • Use the refrigerator only for its intended purpose as described in this manual. • Any servicing must be performed by a qualified technician. •...
  • Page 26 Installation Type B 01 Auto Ice Maker (ICE MASTER) * A. Fridge 02 Fridge door bin B. Freezer 03 Fresh Vegetable & Fruit Drawers C. Cool Select+ 04 Sliding shelf 05 Freezer door bin 06 Quick space shelf 07 Egg tray 08 Water filter * 09 Ice cube tray * * applicable models only...
  • Page 27 • When the door opens, the interlock switch automatically disables the auger motor of the ice maker for safety reasons. • If the internal or external LED lamp is out of order, contact a local Samsung service center. To secure more room for storage in the freezer compartment Remove one or more optional accessories such as shelf or shelves, and their supports, all of which can be removed manually without a tool.
  • Page 28 Installation Door bins Your refrigerator ships with door bins of different types and sizes. If the door bins for your refrigerator were packaged separately, use the figure below to help you position the bins properly. The number of door bins provided may differ with the model. English Untitled-10 28 2020-01-09 PM 4:43:44...

  • Page 29: Door Removal For Entrance

    Door removal for entrance If the refrigerator cannot pass through the entrance due to its size, follow these instructions: Tools required (not provided) Phillips screwdriver Flat-heat screwdriver Socket spanner (10 mm) Pliers Allen spanner (4 mm) Allen spanner (5 mm) Detach the fridge doors 1.
  • Page 30 Installation 2. Disconnect the two connectors on the left door. The position of the connectors differs with the model. CAUTION • Do not remove both doors simultaneously. Make sure to remove one door at a time. Otherwise, any of the doors may fall and cause physical injury.
  • Page 31 6. Open the door by 90 degrees. While holding the door, remove the top hinge. 7. Gently pull up the door vertically to remove. Do not apply excessive force to the door. The door may fall, causing physical injury. 8. Lay the door down on a flat surface. 9.
  • Page 32 Installation 2. Then, disconnect the connectors. 3. Pull up to remove the middle hinge cap on the top of the freezer door. 4. Pull out the hinge shaft, and then push the door in the arrow direction to detach. 5. Tilt the door to the front, and then gently lift it up to remove.
  • Page 33 Reattach the freezer doors CAUTION • Before reattaching the doors, make sure all the electrical connectors are properly connected. • The freezer door must be reattached before the fridge door. • Be careful not to damage or step on the wires during this process. 1.
  • Page 34 Installation 4. Attach the levelling foot cover using a Phillips screwdriver. Use caution not to damage or step on the connectors. 5. Repeat the above steps for the other door. Reattach the fridge doors 1. While holding the door open by more than 90 degrees, reinsert it into the middle hinge.
  • Page 35 4. Draw back the clamp as shown. 5. Connect the wire connectors. CAUTION • Make sure the wire connectors are connected properly. Otherwise, the display does not operate. 6. Connect the water tube. CAUTION • To prevent water leaks, make sure the red clips tighten the coupler properly.

  • Page 36: Step-By-Step Installation

    Installation Step-by-step installation STEP 1 Select a site Site requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for opening and closing the door • Away from a heat source •...
  • Page 37 Clearance See the pictures and table below for space requirements for installation. Depth “A” Width “B” Height “C” 1797 Overall Height “D” 1825 (unit: mm) 01 50 mm 02 125° 03 1515 mm 04 303 mm 05 305 mm 06 908 mm 07 610 mm 08 70 mm 09 43 mm...
  • Page 38 Please check with your dealer for availability. CAUTION • The Samsung Smart Home Adapter comes in two types: one that is dedicated to Samsung smart TVs, and the other one that is dedicated to Samsung home appliances. • You must purchase the Samsung Smart Home Adapter dedicated to home appliances.
  • Page 39 STEP 3 Flooring • The surface to install the refrigerator must support a fully loaded refrigerator. • To protect the floor, put a large piece of cardboard on each leg of the refrigerator. • Once the refrigerator is in its final position, do not move it unless necessary to protect the floor.
  • Page 40 Installation STEP 5 Adjust the door height as well as the door gap Snap ring The height of a door can be adjusted using the provided snap rings, which come in 4 different sizes (1 mm, 1.5 mm, 2 mm, and 2.5 mm).
  • Page 41 To correct the door gap Door gaps can be corrected using the gap bolt on the top right corner of the refrigerator. 1. With the door closed, use a Phillips screwdriver to remove 3 screws on the top cover with the wire connectors. 2.
  • Page 42 • Samsung takes no responsibility for the water line installation. If water leaks occur, contact the installer of the water line.
  • Page 43 To repair the water line CAUTION The waterline must be repaired by a qualified professional. If you encounter a water leak, contact a local Samsung service centre or the installer of the waterline. English 43 Untitled-10 43 2020-01-09 PM 4:43:51...
  • Page 44 Installation STEP 7 Initial settings By completing the following steps, the refrigerator should be fully functioning. 1. Plug the power cord into the wall socket to turn the refrigerator on. 2. Open the door, and check if the interior light lights up. 3.

  • Page 45: Operations

    Operations Feature panel Type A Type B English 45 Untitled-10 45 2020-01-09 PM 4:43:52...
  • Page 46 Operations 01 Freezer / Power Freeze 02 Fridge / Power Cool 03 Cool Select+ / Cool Select 04 Door Alarm / °C  °F 05 Control Lock 06 Lighting 07 Cubed Ice / Filter Reset 08 Crushed Ice / Ice Maker Off 09 Network connection 01 Freezer / Power Freeze (3 sec) The Freezer button can be used to set the freezer temperature, or to...
  • Page 47 02 Fridge / Power Cool (3 sec) The Fridge button can be used to set the fridge temperature, or to activate/deactivate Power Cool. You can manually adjust the cooling temperature for the fridge. The Fridge temperature indicator informs you of the currently set or selected temperature.
  • Page 48 Operations 03 Cool Select+ / Cool Select With the Cool Select function, you can arrange food items in the Cool Select Room in an organized manner, which is located on the bottom right of the refrigerator. Press Cool Select, or press and hold Cool Select+ for 3 seconds, and then press to cycle through the modes.
  • Page 49 To deactivate, press and hold again for 3 seconds. The controls will be enabled as normal. When connecting the refrigerator to Samsung Smart Home App or Samsung smart devices such as Samsung Smart TVs, follow the app's Device or device's onscreen instructions and press and hold Control Lock for authentication 5 seconds.
  • Page 50 Operations 07 Cubed Ice / Filter Reset (3 sec) You can select an ice type. Cubed Ice Press Cubed Ice to dispense cubed ice. The corresponding indicator turns on. After about 6 months (approximately 1200 L) of using the original water filter, the Filter indicator blinks red to remind you that the filter needs to be replaced.

  • Page 51: Smartthings

    • Unauthorized Wi-Fi wireless routers may fail to connect to applicable Samsung Smart Refrigerators. Samsung account You are required to register with a Samsung account to use the app. If you don’t have a Samsung account, follow the app’s onscreen instructions to create a free Samsung account. Getting started 1.
  • Page 52 Operations 4. Follow the onscreen instructions to provide the necessary information about the router, and then tap Next. 5. Press and hold Fridge for more than 5 seconds until the "AP" message appears on the display. Your refrigerator will be registered with the app. 6.
  • Page 53 • Displays the product information including the current version, tutorial, Self Check, and Help Desk. The user manual is downloadable, and the contact information for customer support is also provided. About Device Self Check By referencing Self Check, you can check the diagnostic results of your refrigerator.

  • Page 54: Special Features

    Operations Special features The refrigerator has features convenient for you. Water dispenser (applicable models only) With the water dispenser, you can dispense water without opening the fridge door. The water dispenser offers 3 options: chilled water, cubed ice, and crushed ice. If you do not want to dispense ice, simply press water lever (B).
  • Page 55 CAUTION • If the ice making chime rings repeatedly, contact the waterline installer or a local Samsung service center. • Do not press the button repeatedly after the ice tray is filled with ice or water. Water may overflow or ice may jam.
  • Page 56 Operations • When reinserting the ice maker tray, make sure that the tray is properly centered at the entrance. Otherwise, the tray may be stuck. Ice Maker Off If you press Ice Maker to turn the ice maker off, make sure to remove all ice cubes from the ice bucket.
  • Page 57 Ice cube tray (applicable models only) 1. Remove the cover from the ice cube tray. 2. Fill the tray with water up to the maximum level marked on the inner rear of the tray. 3. Close the ice tray cover. To remove the ice, hold both ends of the ice tray and gently twist it.
  • Page 58 Operations Freezer shelf (ASSY SHELF FRE) (applicable models only) To secure more room in the freezer or the CoolSelect+ compartment, remove the middle drawer of the freezer or the CoolSelect+ compartment, and then insert the freezer shelf between the middle and bottom drawers.
  • Page 59 CAUTION • The freezer shelf (ASSY SHELF FRE) is specifically designed to replace the middle drawer for additional storage room. Do not put the freezer shelf over on the Sliding Shelf. • Make sure to insert the freezer shelf in the correct direction.

  • Page 60: Maintenance

    Maintenance Handle and care Ice bucket (applicable models only) If you do not dispense ice for an extended period, ice may form clumps inside the bucket. If this happens, remove and empty the ice bucket. 1. To remove the ice bucket, gently lift it up and pull out slowly while holding the bottom of the bucket with one hand and the side with the other hand.
  • Page 61 • Use only the provided ice bucket. Third-party ice buckets may cause a system failure. • Use only potable water that is connected to the water supply line. NOTE • The required water pressure for ice making is between 30 to 125 psi (206 to 861 kPa). •...
  • Page 62 Maintenance Door bins To remove the top door bin, hold the front sides of the bin, and then gently lift up to remove. To reinsert, insert the door bin to the end of the marked line. Hold the rear of the door bin with both hands, and then press down to fit into the marked line.
  • Page 63 2. Slide in the right-sided foldable shelf. (applicable models only) 3. While supporting the vegetable shelf with one hand, slide out with the other hand. NOTE Using the space that is revealed after removing the foldable shelf, take out the vegetable shelf.

  • Page 64: Cleaning

    Maintenance Cleaning Interior and exterior WARNING • Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning purposes. They may damage the surface of the refrigerator and cause a fire. • Do not spray water onto the refrigerator. This may cause electric shock. •...

  • Page 65: Replacement

    • Do not use third-party water filters. Use only Samsung-provided or -approved filters. • Unapproved filters may leak and damage the refrigerator, causing electric shock. Samsung holds no responsibility for any damage that may occur from use of third- party water filters.
  • Page 66 Maintenance 3. Insert a new filter cartridge. Use only Samsung-provided or -approved filters. 4. Turn the cartridge knob clockwise to lock into place. 5. Press and hold Cubed Ice on the feature panel for 3 seconds to reset the filter.
  • Page 67 To purchase a new water filter, contact a local Samsung service center. LED Lamps To replace the lamps of the refrigerator, contact a local Samsung service centre. WARNING The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can cause electric shock.

  • Page 68: Troubleshooting

    Troubleshooting Before calling for service, review the checkpoints below. Any service calls regarding normal situations (No Defect Cases) will be charged to users. General Temperature Symptom Possible causes Solution • Power cord is not plugged • Properly plug in the power in properly.
  • Page 69 Odors Symptom Possible causes Solution • Clean the refrigerator and • Spoiled food. remove any spoiled food. Refrigerator has odors. • Make sure strong smelling • Food with strong odors. food is wrapped airtight. Frost Symptom Possible causes Solution Frost around the •...
  • Page 70 Troubleshooting Water/ice (dispenser models only) Symptom Possible causes Solution • Make sure the water Water flow is weaker • Water Pressure is too low. pressure is between 30 to than normal. 125 psi. • The ice maker function is Ice maker makes a activated, but the water •...
  • Page 71 Water does not • Control Lock is activated. • Deactivate Control Lock. dispense. • Use only Samsung-provided or approved filters. • Do not use third-party • Unapproved filters may water filters. leak and damage the refrigerator.

  • Page 72: Do You Hear Abnormal Sounds From The Refrigerator

    Troubleshooting Do you hear abnormal sounds from the refrigerator? Before calling for service, review the checkpoints below. Any service calls related to normal sounds will be charged to the user. These sounds are normal. • When starting or ending an operation, the refrigerator may make sounds similar to a car engine igniting.
  • Page 73 • As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing bubbling sounds. Bubbling! • As the refrigerator temperature increases or decreases, plastic parts contract and expand, creating knocking noises. These noises occur during the defrosting cycle or when electronic parts are working.

  • Page 74: Smartthings

    • The old Samsung Smart Refrigerator app cannot connect with fails to operate. SmartThings models. • You must log into your Samsung account to use the app. • Make sure that your router is operating normally. The SmartThings app • Make sure that the Smart Home Adapter is inserted properly.
  • Page 75 Memo Untitled-10 75 2020-01-09 PM 4:43:59...
  • Page 76 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Contact Center Web Site U.A.E 800-SAMSUNG (800 - 726 7864) OMAN 800-SAM CS (800-72627) www.samsung.com/ae/support (English) KUWAIT 183-CALL (183-2255) www.samsung.com/ae_ar/support (Arabic)
