SIMATIC NET
PG/PC - PROFIBUS
CP 5623/CP 5623 A2/CP 5624
Operating Instructions
02/2025
C79000-G8976-C281-07
Preface
Description of the device
Software installation
Hardware installation
Configuration
Technical specifications
Approvals
Dimensional drawings
1
2
3
4
5
A
B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP 5623 A2 and is the answer not in the manual?

Questions and answers

Related Manuals for Siemens CP 5623 A2

Summary of Contents for Siemens CP 5623 A2

  • Page 1 Preface Description of the device Software installation SIMATIC NET Hardware installation PG/PC - PROFIBUS CP 5623/CP 5623 A2/CP 5624 Configuration Technical specifications Operating Instructions Approvals Dimensional drawings 02/2025 C79000-G8976-C281-07...

  • Page 2: Qualified Personnel

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    Preface What the consignment contains The following components are included in the scope of supply of the CP 5623 / CP 5623 A2 / CP 5624: • CP 5623 communications processor or CP 5623 A2 communications processor or CP 5624 communications processor •...
  • Page 4 HARDNET, SOFTNET, CP 5612, CP 5613, CP 5614, CP 5622 Industry Online Support In addition to the product documentation, the comprehensive online information platform of Siemens Industry Online Support offers support at the following Internet address: (https:// support.industry.siemens.com/cs/us/en/) CP 5623/CP 5623 A2/CP 5624...
  • Page 5 In order to protect plants, systems, machines, and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions form one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks.

  • Page 6: Recycling And Disposal

    RSS Feed under: (https://new.siemens.com/global/en/products/services/cert.html) SIMATIC NET glossary The SIMATIC NET glossary describes terms that may be used in this document. You will find the SIMATIC NET glossary in the Siemens Industry Online Support at the following address: Glossary (http://support.automation.siemens.com/WW/view/en/50305045) Recycling and disposal The products are low in harmful substances, can be recycled and meet the requirements of the Directive 2012/19/EU for disposal of waste electrical and electronic equipment (WEEE).

  • Page 7: Table Of Contents

    Configuration............................21 Technical specifications ........................23 Technical specifications of the CP 5623 / CP 5624 ............... 23 Technical specifications of the CP 5623 A2................25 Approvals ............................. 27 Dimensional drawings ......................... 31 Dimensional drawing CP 5623 / CP 5624 ................31 Dimension drawing CP 5623 A2 ..................
  • Page 8 Table of contents CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 9: Description Of The Device

    – Automatic linking of input and output data can be set by the user program. • Measurement of own operating temperature with temperature sensor. • Display of the total operating hours with operating hours counter. CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...
  • Page 10 Description of the device 1.1 Properties of the CP 5623 Appearance The following graphic shows the CP 5623 communications processor: LEDs PROFIBUS interface PB1 (DP master or DP device) CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 11: Properties Of The Cp 5624

    • Program-controlled data transfer between DP master and DP device module for setting up hierarchical PROFIBUS networks. Appearance The following graphic shows the CP 5624 communications processor: LEDs PROFIBUS interface PB1 (DP master only) PROFIBUS interface PB2 (DP device only) CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 12: Profibus Interface

    MPI cable is sending. M5EXT M5EXT return line (GND) of the 5 V power supply and reference Output potential for the signals RTSAS and RTS of the PROFIBUS interface. CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...
  • Page 13 RTS output signal of the CP. The control signal is "1" active when Output the device (PG or PC) is sending. Shield   The shield is connected to components of the connector housing.   CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 14: Meaning Of The Led Display

    Error during initialization of the CP flashes quickly Applies only to Yellow on Indicates polling by the higher-level DP master DP device operation Yellow off DP device connection is not addressed with the CP 5624 CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 15: Software Installation

    After installing the communications processor, your PG/PC automatically searches for a suitable driver. 1. Follow the instructions of the Hardware Wizard of Windows. 2. Do not activate the search for drivers on the Internet. CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 16: Uninstalling The "Simatic Net Pc Software

    "SIMATIC NET PC Software". You will find the installation manual on the "SIMATIC NET PC Software" DVD or on the Product Support pages under the following entry ID: 77377602 (https://support.industry.siemens.com/cs/ww/en/view/77377602) CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 17: Hardware Installation

    • The housing of the PC must meet the requirements for a fire protection enclosure according to EN 60950-1 or UL/IEC/EN 61010-2-201 • The CP 5623 A2 expansion board is only suitable for indoor use and may only be used in environments with pollution degree 1 or 2 (according to IEC60664-1, GB/T 16935.1).
  • Page 18 PG/PC. Note Oblique installation position is permitted Some PG/PC designs require oblique installation of the communications processor. This is permitted. CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 19: Installing Hardware

    The plug and play function of Windows automatically searches for a driver. 8. Follow the instructions of the Hardware Wizard of Windows. Do not activate the search for drivers on the Internet. CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 20: Hardware Compatibility

    You can adopt the configuration of the previous CP. To do this, you simply need to reload the configuration. Procedure for replacement When replacing a module, follow the steps described in the section "Hardware installation (Page 17)". CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 21: Configuration

    • For the CP 5623, select a configuration of: – CP 5613 A2 or – CP 5613 • For the CP 5623 A2, select a configuration of: – CP 5623 or – CP 5613 A3 or – CP 5613 A2 or –...
  • Page 22 Configuration CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 23: Technical Specifications

    750 mA at 3.3 V and 300 mA at 12 V • CP 5624 Effective power loss Typical   5.4 W • CP 5623 6.1 W • CP 5624 Permitted ambient conditions CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...
  • Page 24 1 kHz, at 2 MHz ... 2.7 GHz 10 V/m with 80% amplitude modulation with 1 kHz, at 80 MHz ... 2 GHz 10 V/m 80% amplitude modulation with 1 kHz, at • to EN 61000-4-6 10 kHz..80 MHz CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 25: Technical Specifications Of The Cp 5623 A2

    Technical specifications 5.2 Technical specifications of the CP 5623 A2 Technical specifications of the CP 5623 A2 Technical specifications of the CP 5623 A2   Connection to PROFIBUS   Amount Transmission speeds 9.6 kbps to 12 Mbps Design 9-pin D-sub female connector with screw locking...
  • Page 26 Technical specifications 5.2 Technical specifications of the CP 5623 A2 Technical specifications of the CP 5623 A2   Weight   88 g Dimensions (W x H x D) in mm   18 x 112 x 101 Degree of protection   IP00...

  • Page 27: Approvals

    You will find the declaration of conformity for this communications processor on the Product Support pages under the following entry ID: 58826997 (https://support.industry.siemens.com/cs/ww/en/view/58826997) C-TICK approval The communications processor meets the requirements of the Australian AS/NZS 3548 standard according to EN 61000-6-3. CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 28: Csa Approval

    The communications processors CP 5623 and CP 5624 have an approval in accordance with the Canadian standard CAN/CSA C22.2 No. 60950-1. The communications processor CP 5623 A2 has an approval in accordance with the Canadian standard CAN/CSA C22.2 No. 62368-1.
  • Page 29 Marking for the Eurasian customs union (valid for 6GK1562‑3AA00 and 6GK1562‑4AA00) EAC (Eurasian Conformity) Eurasian Economic Union of Russia, Belarus, Armenia, Kazakhstan and Kyrgyzstan Declaration of conformity according to the technical regulations of the customs union (TR ZU) CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...
  • Page 30 Approvals CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 31: Dimensional Drawings

    Dimensional drawings Dimensional drawing CP 5623 / CP 5624 Front view and side view of the CP 5623 and CP 5624 Figure B-1 All dimensions in millimeters. CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 32: Dimension Drawing Cp 5623 A2

    Dimensional drawings B.2 Dimension drawing CP 5623 A2 Dimension drawing CP 5623 A2 Front view and side view of the CP 5623 A2 Figure B-2 All dimensions in millimeters. CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

  • Page 33: Index

    Index Converting, 20 D-sub female connector, 12 Number of CPs, permitted, 19 PIN assignment, 12 PROFIBUS network, 12 Replacing, 20 CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...
  • Page 34 Index CP 5623/CP 5623 A2/CP 5624 Operating Instructions, 02/2025, C79000-G8976-C281-07...

This manual is also suitable for:

Cp 5623Cp 5624
