Kinhank SURPER CONSOLE X2 User Manual

Hide thumbs Also See for SURPER CONSOLE X2:

Advertisement

Quick Links

Download this manual
Model:
Super Console X2
CPU:Amlogic S905X2
GPU:Mail-G31 MP2
DC Power:12V/1A
WiFi:2.4G/5G
1. Product Information
Product size: 10cm*10cm*2cm
Product weight: 190g
Support HDMI-compatible
Support 2.4G/5G WiFi. 10/100M LAN
Support Download games
Support Multi-language
Dual System: EmuELEC4.5 Game Console & Android 9.0
2. Product Features
* Mini size, retro design, palm size, can be put in the pocket, it's the best choice for family,
travel, party, corporate entertainment.
SURPER CONSOLE X2
User Manual
Dual System: Game & TV
RAM:2GB DDR4
ROM:8GB FALSH
Bluetooth: BT5.0
Language:Multi-languages

Advertisement

loading
Need help?

Need help?

Do you have a question about the SURPER CONSOLE X2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kinhank SURPER CONSOLE X2

Summary of Contents for Kinhank SURPER CONSOLE X2

  • Page 1 SURPER CONSOLE X2 User Manual Model: Super Console X2 Dual System: Game & TV CPU:Amlogic S905X2 RAM:2GB DDR4 GPU:Mail-G31 MP2 ROM:8GB FALSH DC Power:12V/1A Bluetooth: BT5.0 WiFi:2.4G/5G Language:Multi-languages 1. Product Information Product size: 10cm*10cm*2cm Product weight: 190g Support HDMI-compatible Support 2.4G/5G WiFi. 10/100M LAN...

  • Page 2: Packing List

    * Open Linux source system, suitable for DIY. For the specific method of downloading the game, please refer to the instructions or consult our customer service. 3. PACKING LIST 1* SURPER CONSOLE X2 1*500G HDD 2* Controller 1*TV Remote Control...

  • Page 3: System Startup And Shutdown

    START---->Select to start from the built-in storage. TV system to game system: APPS---->>External System Launcher---->>OK (started once, if it is not changed to TV system, the next time it is started, it will automatically enter the game system) 6. Precautions The resolution of the game system is adaptive, do not change the resolution of the game system.

  • Page 4: More Settings

    A key (lower function key) Return or cancel START Key Set up SELECT Key Soft restart or soft shutdown setting L2/R2 Game menu page flip 9. More Settings （1）Language Setting System Settings-Language START---->>SYSTEM SETTINGS---->>LANGUAGE...
  • Page 6 (2) Controller Button Setting After the USB interface is connected to the handle, press the handle B (OK) button to enter the handle button setting.
  • Page 8 (3) WIFI Connection START---->>NETWORK SETTINGS---->>ENABLE WIFI, then select the wifi network as required and fill in the password;...
  • Page 10 (4) Game Console/TV Dual System TV system: When the card is not inserted, it is Android system, it supports watching TV, Youtube, Googleplay.TV system turn into game system: Follow the steps below to use the remote control My Application>>LiberELEC>>OK>>Allow Note: When its TV system turn into game system, it requires 2.4G HZ flying mouse remote control to operate.
  • Page 11 10. Adding Game Methods There are many ways to copy games: The First Type: (compatible with multiple win systems) Insert the game console memory card into the computer and use DiskGenius software: (1) Open DiskGenius, make sure DiskGenius has recognized the memory card ; (2) Find the rom folder and put the game in the corresponding folder ;...
  • Page 12 If prompted to enter a user name and password, the default user name: root, password: emuelec. (2) Open the Storage/Roms Folder: You can see many sub folders, each of which corresponds to a simulator game, and the corresponding game needs to be placed in the corresponding folder to be correctly identified (3) Example of the folder list corresponding to the simulator: Arcade-FBA format roms\arcade\fba...
  • Page 13 … … Note: The system distinguishes games by folder name, do not modify any directory structure, just copy the game files to the folder of the corresponding simulator. 11. Change Game Emulators: There may be multiple emulator files. If individual games cannot be opened or you want to try the effects of other simulators, please use the following methods to change the simulator: Choose to change the rom file of the simulator;...

  • Page 15: Tutorial Videos

    12. Q&A (1) Is the output screen of this game machine clear? SUPER CONSOLE X2 supports HDMI input, supports 1080P / 720P high-definition output, can be connected to display screens, projectors, TVs and other equipment, the big screen is clearer. (2) Can I add games by myself? SUPER CONSOLE X2 uses an open source Linux system and supports adding games by itself.
